• Action of the Function Keys
DSP MEM-IMG : If an image remains in memory on the
vision processing board then this image
will be displayed and will be vision
processed again.
ACQR INSPECT : Press to carry out the block skip mark
setting.
DSP REAL-IMG : Press to display the actual image of the
fiducial mark camera.
RETURN : Press to return to Page 522/100.
• First Status Area
B MARK
• First Display Area
ACQR INSPECT
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/131
To Page 522/132
To Page 522/100
Block Skip Mark Vision
Processing Check
Part 3
3 – 55
B_MARK
Page
522 130
DSP MEM-IMG ACQR INSPECT DSP REAL-IMG RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
▲ : Press to move the cursor upward on the vision
processing screen.
▼ : Press to move the cursor downward on the
vision processing screen.
ON/OFF : Press to select or cancel the item identified by
the cursor.
CLEAR : Press to cancel all of the trace mode settings.
THROUGH : Press to return the vision processing screen to
the actual image.
RETURN : Press to return Page 522/100.
• Vision Processing Trace Mode
The actual process and/or the results of the vision process can
be displayed on the screen for each trace mode setting (it is
possible to include several together). The trace mode can be
used to check the device description created by the user and if
there are any problems it can be used to visually inspect the
problem point to get an idea about what is wrong. However,
due to the additional graphic display processing, the vision
processing becomes extremely slow. The vision trace function
is intended for use as a debugging tool and is not normally
used. The use of this function during automatic operation
will cause problems.
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/100
Vision Processing Trace
Part 3
3 – 56
TRACE
Page
522 140
▲
▼
ON/OFF CLEAR THROUGH RETURN
Version 5.0
FCP IV-3 Operation
FCP IV-3 Operation
The details of the vision trace function are explained below.
1. No. 0 Result
A graphic display is carried out based on the results of inspection. When
either the [REINSPECT] or [ACQR INSPECT] vision command is carried
out this flag will automatically be set to ON.
Details of the Inspection Results Graphic Display
After vision processing is complete the recognized device center value is
displayed graphically. The amount of correction that is indicated by the
outline of the device shape and the nozzle position is then carried out. If
an error has occurred the details of the error will be displayed.
(1) Normal Display
Chapter 3 Description of Commands
Part 3
3 – 57
Version 5.0
