• Action of the Function Keys
BUFFER IMG1 : Press to display the most recent image in
memory on the vision processing board.
BUFFER IMG2 : Press to display the image prior to the
most recent image in memory on the
vision processing board.
ZOOM IN : Press this key to zoom in on the image
displayed on the vision processing
monitor.
ZOOM OUT : Press this key to zoom out the image
displayed on the vision processing
monitor. However the image cannot be
zoomed out farther than the original
image.
REINSPECT : Press to vision process the selected image
one more time.
RETURN : Press to return to Page 522/120.
There will be no display if there is nothing in memory on the
vision processing board. Even if the image in memory on the
vision processing board is something other than a fiducial
mark image this image will display if it is selected.
• First Display Area
F_MARK
DSP MEM-IMG
BUFFER IMG 1
BUFFER IMG 2
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/120
Displaying Memory of Fiducial
Marks
Part 3
3 – 65
DSP MEM-IMG
Page
522 121
BUFFER IMG 1 BUFFER IMG 2 ZOOM IN ZOOM OUT REINSPECT RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
INSPECT : Press to vision process the acquired image. The
results of vision processing will display on the
screen.
RETURN : Press to return to Page 522/120.
Execute these commands after moving the XY table to the
coordinates set in the mark sequences in order to acquire the
image and carry out vision processing under the same
conditions as during automatic operation.
• First Display Area
VISION PROCESSING
RESULT X: 10[um]
RESULT Y: 8[um]
RESULT A: 0.000[deg]
The results of vision processing will display inside the [ ]
brackets as shown above.
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/120
Acquiring Fiducial Mark Image
Part 3
3 – 66
ACQR INSPECT
Page
522 122
INSPECT RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
BUFFER IMG 1: Press to display the most recent image in
memory on the vision processing board.
BUFFER IMG 2: Press to display the image prior to the most
recent image in memory on the vision
processing board.
ZOOM IN : Press this key to zoom in on the image
displayed on the vision processing monitor.
ZOOM OUT : Press this key to zoom out the image
displayed on the vision processing monitor.
However the image cannot be zoomed out
farther than the original image.
REINSPECT : Press to vision process the selected image
one more time.
RETURN : Press to return to Page 522/130.
There will be no display if there is nothing in memory on the
vision processing board. Even if the image in memory on the
vision processing board is something other than a block skip
mark image this image will display if it is selected.
• First Display Area
B_MARK
DSP MEM-IMG
BUFFER IMG 1
BUFFER IMG 2
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/130
Displaying Memory of Block
Skip Marks
Part 3
3 – 67
DSP MEM-IMG
Page
522 131
BUFFER IMG 1 BUFFER IMG 2 ZOOM IN ZOOM OUT REINSPECT RETURN
Version 5.0
FCP IV-3 Operation
