• Action of the Function Keys CAMERA : Press to set camera r elated Proper data. X/Y : Press to set Pr oper data for the X and Y axes. D1/D2/Z : Pr ess to set Proper data for the D1, D2 and Z axes. RETURN : Press to r et…
• Action of the Function Keys
HT RESET : If the Handy Terminal hangs up for some
reason then this key can be pressed to reset or
reinitialize the Handy Terminal.
BC TEST : When this key is pressed it becomes possible
for the Handy Terminal to read bar codes.
When a code is read it will display as shown
below. If the type of bar code changes it is
possible to check to see if the new code can be
read.
RETURN : Press to return to Page 524/000.
• First Status Area
H T
• First Display Area
BAR CODE READ TEST
4965225400409
PLEASE READ BAR CODE
• Function Key Menu
Chapter 3 Description of Commands
To Page 524/000
Bar Code Read Test
Part 3
3 – 79
BC TEST
Page
524 200
HT RESET BC TEST RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
CAMERA : Press to set camera related Proper data.
X/Y : Press to set Proper data for the X and Y axes.
D1/D2/Z : Press to set Proper data for the D1, D2 and
Z axes.
RETURN : Press to return to Page 500/000.
• Function Key Menu
Chapter 3 Description of Commands
To Page 531/000
To Page 532/000
To Page 533/000
To Page 500/000
Setting Proper Data
Part 3
3 – 80
PROPER
Page
530 000
CAMERA X/Y D1/D2/Z RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
XC/YC : Press to measure the mark camera reading
position.
MARK : Press to measure the mark camera
resolution, tilt, and rotation.
WIDE : Press to measure the resolution, tilt, and
rotation of the wide view parts camera.
NARROW : Press to measure the resolution, tilt, and
rotation of the narrow view parts camera.
BRIGHT : Press to set the gain or offset level for the
parts cameras and the mark camera.
RETURN : Press to return to Page 530/000.
• First Status Area
CAMERA
• First Display Area
Mark Read Pos. XC: -403.18 mm YC: 296.27 mm
Mark Camera X: 18.5 um Y: 18.5 um
Standard Camera X: 80.0 um Y: 80.0 um
• Function Key Menu
Chapter 3 Description of Commands
To Page 531/100
To Page 531/200
To Page 531/300
To Page 531/400
To Page 531/500
To Page 530/000
Measuring Camera Proper Data
Part 3
3 – 81
CAMERA
Page
531 000
XC/YC MARK WIDE NARROW BRIGHT RETURN
Version 5.0
