• Action of the Function Keys MARK CAMERA : Press to set the mark camera gain and offset. WIDE : Press to set the parts camera (wide view) gain and offset. NARROW : Press to set the parts camera (narr ow view) gain and o…
FCP IV-3 Operation
• Action of the Function Keys
POSITION 2: Press to display the "Press START" message which enables the
Proper value measurement jig attached to Station 4 the vision
processing station to move to Station 7.
CHECK : Press to display the "Press START" message which enables
measurements to be carried out for the parts camera resolution
(with standard field of view), tilt in the X and direction, and
rotational orientation.
RETURN : Press to return to Page 531/000.
• START Button
If [START] is pressed after POSITION 2, the cam is rotated forward to move the
Proper value measurement jig at the Station 4 vision processing station to Station 7.
If [START] is pressed after pressing CHECK, the parts camera resolution (with
standard field of view), tilt in the X and Y direction, and rotational orientation are
measured.
Note: The cam angle must be set between 170° and 340° before the Proper data
measurement jig is attached.
Do not attempt to measure the parts camera resolution, tilt in the X and Y
direction, or rotational orientation unless the Proper value measurement jig is at
Station 4.
The camera should be adjusted so that the rotational orientation is as close as
possible to 0° since this orientation has a direct effect on placing accuracy.
Note that the above values are machine Proper data settings and thus it is
necessary to transmit Proper data to the MCS 30 computer once Proper data
measurement is completed.
For details on Proper data measurements refer to the FCP IV-3 Maintenance
Manual.
• Function Key Menu
Chapter 3 Description of Commands
Part 3
3 – 87
POSITION 2 CHECK RETURN
Version 5.0
• Action of the Function Keys
MARK CAMERA: Press to set the mark camera gain and
offset.
WIDE : Press to set the parts camera (wide view)
gain and offset.
NARROW : Press to set the parts camera (narrow
view) gain and offset.
RETURN : Press to return to Page 531/000.
• Function Key Menu
Chapter 3 Description of Commands
To Page 531/510
To Page 531/520
To Page 531/530
To Page 531/000
Setting Camera Brightness
Part 3
3 – 88
BRIGHT
Page
531 500
MARK CAMERA WIDE NARROW RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
▲ : Press to change the gain or offset level by +1.
■ : Press with ▲ or ▼ to change the gain or offset
level in increments of 10.
▼ : Press to change the gain or offset level by -1.
SELECT : Press to switch between the type of setting
(i.e. gain or offset).
RETURN : Press to return to Page 531/500.
The gain and offset levels set here are machine Proper data
settings and thus it is necessary to transmit Proper data to the
MCS 30 computer once Proper data measurement is
completed.
Note: The desired level can be set either by entering a number using
the numerical keypad, or by using the function keys.
• First Display Area
Mark Camera Level
Gain 128
Offset 8
• Function Key Menu
Chapter 3 Description of Commands
To Page 531/500
Setting Mark Camera
Brightness
Part 3
3 – 89
MARK CAMERA
Page
531 510
▲ ■ ▼
SELECT RETURN
Version 5.0
FCP IV-3 Operation
