• Action of the Function Keys COUNTER : Press to move the Y axis to the tar get position. PROGRAM : Press to move the Y axis to the position enter ed in Placing Position Y or Mark Read Position Y . RETURN : Press to retu…
• Action of the Function Keys
COUNTER : Press to move the X axis to the target position.
PROGRAM : Press to move the X axis to the position entered
in Placing Position X or Mark Read Position X.
RETURN : Press to return to Page 550/000.
• START Button
Press to move the axis to its target location.
• Second Status Area
DSTN:
• Input from Numerical Keypad
If the input position is not in the permissible range of
movement, the system waits for another value to be input.
Once a permissible value has been input, if all conditions to
start operation are satisfied, the system waits for the [START]
button to be pressed. Otherwise, an alarm is displayed in the
second status area and the [START] button is disabled.
Values must be input in the world coordinate system.
The permissible range is defined to lie between the Min Limit
Position X and Max Limit Position X as set in Proper data.
• Function Key Menu
Chapter 3 Description of Commands
To Page 550/000
Moving the X Axis
Part 3
3 – 108
X AXIS
Page
551 000
COUNTER PROGRAM RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
COUNTER : Press to move the Y axis to the target position.
PROGRAM : Press to move the Y axis to the position entered
in Placing Position Y or Mark Read Position Y.
RETURN : Press to return to page 550/000.
• START Button
Press to move the axis to its target location.
• Second Status Area
DSTN:
• Input from Numerical Keypad
If the input position is not in the permissible range of
movement, the system waits for another value to be input.
Once a permissible value has been input, if all conditions to
start operation are satisfied, the system waits for the [START]
button to be pressed. Otherwise, an alarm is displayed in the
second status area and the [START] button is disabled.
Values must be input in the world coordinate system.
The permissible range is defined to lie between the Min Limit
Position Y and Max Limit Position Y as set in Proper data.
• Function Key Menu
Chapter 3 Description of Commands
To Page 550/000
Moving the Y Axis
Part 3
3 – 109
Y AXIS
Page
552 000
COUNTER PROGRAM RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
RETURN : Press to return to page 550/000.
• START Button
Press to move to the target location.
• First Status Area
D AXIS
• Second Status Area
D No.
• Input from Numerical Keypad
If the input position is not in the permissible range of
movement, the system waits for another value to be input.
Once a permissible value has been input, the system waits for
the [START] button to be pressed if all other conditions to start
operation are satisfied. Otherwise, an alarm is displayed in the
second status area and the [START] button is disabled.
Values must be input in the world coordinate system.
The permissible range of movement in joint mode is 1 to 160;
otherwise it is 1 to 80.
• Function Key Menu
Chapter 3 Description of Commands
To Page 550/000
Moving to a Specified Device
Position
Part 3
3 – 110
D AXIS
Page
553 000
RETURN
Version 5.0
FCP IV-3 Operation
