Part Four Proper Data

• Action of the Function Keys

RETURN :Press to return to Page 550/000.

• Start Button

Pressing the [START] button discards all parts which are

currently being held. When all parts are discarded the screen

returns to Page 550/000.

• First Status Area

DUMP PARTS

• First Display Area

ST1. N 3 D 5 Er **** STATUS

ST2. N 3 D 5 Er **** P MOde Product

ST3. N 3 D 5 Er **** Recovery 3 times

ST4. N 3 D 5 Er **** T Mode Joint

ST5. N 3 D 5 Er 0

ST6. N 3 D 5 Er 0

ST7. N 3 D 5 Er 0

• Second Display Area

If start conditions are fulfilled, the message "Press START"

flashes. Otherwise an error displays.

• Cycle Stop Button

Press the [CYCLE STOP] button to interrupt operation and

return to Page 550/000.

• Function Key Menu

Chapter 3 Description of Commands

To Page 550/000

Discarding Parts in

Reject Parts Box

Part 3

3 – 112

DUMP PARTS

Page

555 000

RETURN

Version 5.0

FCP IV-3 Operation

Part Four

Proper Data

Chapter 1 Proper Data ListingPart 4

# 1: ID_Code [8] ASCII CODE = 0

# 2: Language = [English] Japanese French

# 3: Red_Light = 0000 0000 0000 0000

# 4: Yellow_Light = 0000 0000 0000 0000

# 5: Blue_Light = 0000 0000 0000 0000

# 6: Red_Flash = 0000 0000 0000 0000

# 7: Yellow_Flash = 0000 0000 0000 0000

# 8: Blue_Flash = 0000 0000 0000 0000

$# 9: User_Define A = 0000 0000 0000 0000

❈ 11: Machine_Status A = 0000 0000 0000 0000

❈ 12: Machine_Status B = 0000 0000 0000 0000

❈ 13: Machine_ID = 0000 0000 0000 0000

# 14: PCB_Location = [Corner] Pin

$ 20: Loader Status A = 0000 0000 0000 0000

$ 21: Loader Status B = 0000 0000 0000 0000

$ 22: Conveyor Type = [L->R] R->L

$ 23: Wait Signal = [Off] On

$# 24: Busy Invalid = [No] Yes

$# 25: Conveyor Control = [Manu] Auto

$# 26: Conveyor Adj. Limit ( 0.05 ~ 1.00 ) [mm] = 0.50

$# 27: Conveyor Stop Offset ( 0.00 ~ 2.00 ) [mm] = 0.30

$# 28: Conveyor adj. Timer ( 0 ~ 120000 ) [msec]= 000600

$❈ 29: Width Max Limit ( 0.00 ~ 655.35 ) [mm] = 460.00

4 – 1Version 2.0

DATA NAME

1. Proper Data Listing

The following symbols are used before the Proper data values.

✩: Varies from machine to machine. Must be measured.

❈: Cannot be changed by the user.

#: Can be changed by the user.

@: Machine automatically changes this. (Sometimes the user can also

change this.

$: Not currently in use.
