Chapter 1 Proper Data Listing Part 4 ✩❈ 103: Placing Position X (-100000~ 0 ) [pulse]= 000000 ✩❈ 104: Placing Position Y ( 0 ~ 100000 ) [pulse]= 000000 ✩❈ 105: Loading Position X (-100000~ 0 ) [pulse]= 000000 ✩❈ 106: Loa…

100%1 / 364
$❈ 30: Width Min Limit ( 0.00 ~ 655.35 ) [mm] = 050.00
$# 40: LMS Flag = [Off] On
$# 41: Cell Status = [Unit] Active Passive
$# 42: Change Over Mode ( 0 ~ 200 ) = 000
$# 43: Auto Start = [No] Yes
$# 44: Backup Plate Check = [No] Yes
$❈ 45: Command Line Status = [RS232C] LAN ETHERNET
$# 46: Command Line Port ( 0 ~ 4 ) = 0
$✳ 47: ID Station Type = [S_type] A_type
$# 48: Buzzer Warning = [On] Off
$# 49: Process Timer ( 1 ~ 120000 ) [msec]= 010000
$# 50: Reader Type ( 0 ~ 9 ) = 0
$# 51: Code Reader Timer ( 1 ~ 120000 ) [msec]= 010000
$# 52: Code Reader Retry ( 0 ~ 10 ) = 00
$# 53: Reader1 Port No. ( 0 ~ 30 ) = 0
$# 54: Reader2 Port No. ( 0 ~ 30 ) = 0
$# 55: PCB Code Terminal = [Non] Use
$ 56: Terminal Type = [CRX1200] VT-100
$# 57: Code Terminal Port ( 0 ~ 30 ) = 0
# 70: Device Check SW =[No] Parts Miss Error
# 71: Verifier Tool = [Non] Barcode Handy_term
# 72: Barcode Reader Type ( 0 ~ 9 ) = 0
# 73: Device Check Port ( 0 ~ 30 ) = 0
# 74: ESC Permission = [Non] Permit
# 75: MAN Permission = [Non] Permit
# 76: HT Comment Term. Code ASCII CODE =
# 77: HT Verify Term. Code ASCII CODE =
# 78: D Change Trigger = Error Parts Miss PD
✩❈ 100: Pickup Position T1 ( 0 ~50000 ) [pulse]= 00000
✩❈ 101: Pickup Position T2 (-50000~0 ) [pulse]= 00000
✩❈ 102: Origin Position Z (-65000~ 65000 ) [pulse]= 00000
DATA NAME
Chapter 1 Proper Data ListingPart 4
4 – 2Version 2.0
Chapter 1 Proper Data ListingPart 4
✩❈ 103: Placing Position X (-100000~ 0 ) [pulse]= 000000
✩❈ 104: Placing Position Y ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 105: Loading Position X (-100000~ 0 ) [pulse]= 000000
✩❈ 106: Loading Position Y (-65000~ 65000 ) [pulse]= 00000
✩❈ 107: Mark Read Position X (-100000~100000 ) [pulse]= 000000
✩❈ 108: Mark Read Position Y ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 109: PCB Check Position X (-100000~100000 ) [pulse]= 000000
✩❈ 110: PCB Check Position Y ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 111: D1 Original Position (-10000~ 10000 ) [pulse]= 000000
✩❈ 112: D2 Original Position (-10000~ 10000 ) [pulse]= 00000
✩❈ 113: Max Limit Position X ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 114: Max Limit Position Y ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 115: Max Limit Position D1 ( 0 ~ 100000 ) [pulse]= 000000
✩❈ 116: Max Limit Position D2 (-10000~ 500000 ) [pulse]= 000000
✩❈ 117: Max Limit Position Z (-65000~ 65000 ) [pulse]= 00000
✩❈ 118: Min Limit Position X (-100000~ 0 ) [pulse]= 000000
✩❈ 119: Min Limit Position Y (-100000~ 0 ) [pulse]= 000000
✩❈ 120: Min Limit Position D1 (-500000~ 10000 ) [pulse]= 000000
✩❈ 121: Min Limit Position D2 (-50000~ 50000 ) [pulse]= 000000
✩❈ 122: Min Limit Position Z (-65000~ 65000 ) [pulse]= 000000
# 130: Nozzle Check SW = [No] Yes
❈ 131: Narrow View Camera = [Non] Use
❈ 132: Front Light = [Non] Use
# 133: Cam Speed ( 0 ~ 100.0 ) [%] = 000.0
# 134: Skip Number ( 0 ~ 16 ) = 0
# 135: Skip Nozzle S ( 0 ~ 12 ) = 0
# 136: Skip Nozzle M ( 0 ~ 12 ) = 0
# 137: Skip Nozzle L ( 0 ~ 12 ) = 0
$ 138: M/C Size = [4000] 5000
4 – 3Version 2.0
DATA NAME
# 139: D ESC sw = [No] Yes
✩❈ 140: Rough Pulse X ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 141: Rough Pulse Y ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 142: Rough Pulse D1 ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 143: Rough Pulse D2 ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 144: Rough Pulse C ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 145: Rough Pulse FQ ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 146: Rough Pulse Z ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 147: Reach Pulse X ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 148: Reach Pulse Y ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 149: Reach Pulse D1 ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 150: Reach Pulse D2 ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 151: Reach Pulse C ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 152: Reach Pulse FQ ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 153: Reach Pulse Z ( 0 ~ 65535 ) [pulse]= 00000
✩❈ 160: SA Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 161: SB Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 162: SC Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 163: SD Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 164: SE Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 165: SF Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 166: SG Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 167: SH Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 168: SI Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 169: SJ Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 170: SK Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 171: SL Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
✩❈ 172: MA Place Offset X (-327.68~ 327.68 ) [mm] = 00.000
DATA NAME
Chapter 1 Proper Data ListingPart 4
4 – 4Version 2.0
