Appendix A I/O Map
Version 2.0 A – 2
B00 X010 F1 Function key F1
B01 X011 F2 Function key F2
B02 X012 F3 Function key F3
B03 X013 F4 Function key F4
B04 X014 F5 Function key F5
B05 X015 F6 Function key F6
B06 X016
B07 X017 - (MINUS KEY) Minus Key
B08 X018 E1 Extension Key 1
B09 X019 E2 Extension Key 2
B0A X01A E3 Extension Key 3
B0B X01B E4 Extension Key 4
B0C X01C TENKEY 1 Numerical input key 1
B0D X01D TENKEY 2 Numerical input key 2
B0E X01E TENKEY 4 Numerical input key 4
B0F X01F TENKEY 8 Numerical input key 8
LED No. Display Description
Appendix A I/O Map
A – 3Version 2.0
A00 X020 MACHINE READY Machine is ready
A01 X021 AIR OK Air pressure check switch
A02 X022 THERMAL OK Thermal sensors functional
A03 X023 SERVO READY Servos functional
A04 X024 TABLE READY Table movement permissible
A05 X025 Short circuit
A06 X026 Short circuit
A07 X027 Short circuit
A08 X028 FRONT DOOR OK Front door safety switch
A09 X029 REAR DOOR OK Rear door safety switch
A0A X02A LOADER PLC OK Board loader PLC functional
A0B X02B VACUUM OK Vacuum pressure check switch
A0C X02C CAM HANDLE CHK Cam handle switch
A0D X02D FEEDER CHK Feeder lifting check
A0E X02E FENCE1 CHECK Rear fence 1 check
A0F X02F FENCE2 CHK Rear fence 2 check
LED No. Display Description
Input 2 MX100 Address 0xEF0220
Appendix A I/O Map
Version 2.0 A - 4
B00 X030 TABLE UPCHK1 Board lifter upper limit check
B01 X031 TABLE DNCHK1 Board lifter lower limit check
B02 X032
B03 X033 PCB SET OK Reference pin check
B04 X034
B05 X035
B06 X036
B07 X037
B08 X038 CONV PLUS OT Conveyor width (+) overtravel
B09 X039 CONV MINUS OT Conveyor width (–) overtravel
B0A X03A CONV PCB CHK Board on conveyor check
B0B X03B REAR OPERATION Machine operated from rear panel
B0C X03C FEEDING FW POS Station 1 advance limit feeding lever
B0D X03D FEEDING BW POS Station 1 retract limit feeding lever
B0E X03E CAM ZERO POS Cam original position
B0F X03F R FENCE MODE Rear fence cycle stop mode
LED No. Display Description
