Appendix A I/O Map
A – 7Version 2.0
A00 LX000 LOADER STOP Board loader emergency stop
A01 LX001 PCB AVAIL IN Board available from previous stage signal
A02 LX002 PCB REQ IN Board request from next stage
A03 LX003 IN REDUCE POS In conveyor deceleration position
A04 LX004 IN PCB CONF In conveyor board arrival check
A05 LX005 IN STOPPER ON In conveyor stopper raised check
A06 LX006 IN STOPPER OFF In conveyor stopper lowered check
A07 LX007
A08 LX008 MAIN REDU POS Main conveyor deceleration position
A09 LX009 MAIN PCB CONF Main conveyor board arrival check
A0A LX00A MAIN STOP ON Main conveyor stopper in check
A0B LX00B MAIN STOP OFF Main conveyor stopper out check
A0C LX00C PCB OUT CHECK Out conveyor board unloading check
A0D LX00D OUT PCB CONF Out conveyor board arrival check
A0E LX00E
A0F LX00F
LED No. Display Description
Board Loader PLC Input 1
Appendix A I/O Map
Version 2.0 A – 8
B00 LX010 WAIT INPUT Awaiting input
B01 LX011 MCID CONV MC/ID in use
B02 LX012 (SPINE ON) SPINE conveyor in use
B03 LX013
B04 LX014
B05 LX015
B06 LX016
B07 LX017
B08 LX018
B09 LX019
B0A LX01A
B0B LX01B
B0C LX01C
B0D LX01D
B0E LX01E
B0F LX01F
LED No. Display Description
Appendix A I/O Map
A – 9Version 2.0
A00 LX020 ID DECEL PNT1 MCID forward rotation deceleration start pt
A01 LX021 ID ARRV CHK1 MCID forward rotation board arrive check
A02 LX022 ID DECEL PNT2 MCID reverse rotation deceleration start pt
A03 LX023 ID ARRV CHK2 MCID reverse rotation board arrive check
A04 LX024 ID W. CONV +OT MCID conveyor width overtravel (+)
A05 LX025 ID W. CONV -OT MCID conveyor width overtravel (-)
A06 LX026 ID INCHING + MCID inching (+)
A07 LX027 ID INCHING - MCID inching (-)
A08 LX028 ID +FOLLOW CHK MCID follow up check (+)
A09 LX029 ID -FOLLOW CHK MCID follow up check (-)
A0A LX02A ID STPR1 ON MCID forward rotation stopper engaged
A0B LX02B ID STPR1 OFF MCID forward rotation stopper disengaged
A0C LX02C ID STPR2 ON MCID reverse rotation stopper engaged
A0D LX02D ID STPR OFF MCID reverse rotation stopper disengaged
A0E LX02E ID PCB TRAN MCID board transport check
A0F LX02F FOLLOW PERMIT Follow up permission input
Board Loader PLC Input 2
LED No. Display Description
