Appendix A I/O Map A – 11 V ersion 2.0 A00 LX200 LOADER PLC OK Board loading sequence functional A01 LX201 LOADER ALARM1 Board loader alarm 1 A02 LX202 LOADER ALARM2 Board loader alarm 2 A03 LX203 LOADER CMPL T Board loa…
Appendix A I/O Map
Version 2.0 A – 10
B00 LX030 +FOLLOW CHK Follow up check (+)
B01 LX031 -FOLLOW CHK Follow up check (-)
B02 LX032
B03 LX033
B04 LX034
B05 LX035
B06 LX036
B07 LX037
B08 LX038
B09 LX039
B0A LX03A
B0B LX03B
B0C LX03C
B0D LX03D
B0E LX03E
BOF LX03F
LED No. Display Description
Appendix A I/O Map
A – 11Version 2.0
A00 LX200 LOADER PLC OK Board loading sequence functional
A01 LX201 LOADER ALARM1 Board loader alarm 1
A02 LX202 LOADER ALARM2 Board loader alarm 2
A03 LX203 LOADER CMPLT Board loading completed
A04 LX204 CLEAROFF CMPLT Board unloading operation completed
A05 LX205 PCB WAIT Awaiting next board
A06 LX206 NEXT WAIT Waiting for next process
A07 LX207 LOADER WORK Board loader in use
A08 LX208 MAIN PCB CHK Main conveyor board check
A09 LX209 IN PCB CHK In conveyor board check
A0A LX20A ID PCB OUT MCID board unloading completed
A0B LX20B ID PCB CHK1 MCID forward rotation board check
A0C LX20C ID PCB CHK2 MCID reverse rotation board check
A0D LX20D W. CONV PERMIT Conveyor width change permission
A0E LX20E LOADER ALARM3 Board loader alarm 3
A0F LX20F TABLE LOCK XY table lock check
OP Link Input 1 MX100 Address 0xEF0280
LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 12
B00 LX210
B01 LX211
B02 LX212
B03 LX213
B04 LX214
B05 LX215
B06 LX216
B07 LX217 DATA SET COMP Data set completed
B08 LX218 LD I/O DATA0 I/O data 0
B09 LX219 LD I/O DATA1 I/O data 1
B0A LX21A LD I/O DATA2 I/O data 2
B0B LX21B LD I/O DATA3 I/O data 3
B0C LX21C LD I/O DATA4 I/O data 4
B0D LX21D LD I/O DATA5 I/O data 5
B0E LX21E LD I/O DATA6 I/O data 6
B0F LX21F LD I/O DATA7 I/O data 7
LED No. Display Description
