Appendix A I/O Map A – 19 V ersion 2.0 B00 Y030 ST7 BLOW ON Station 7 blower on B01 Y031 B02 Y032 F_LIGHT OPEN Front light shutter open B03 Y033 F_LIGHT SHUT Front light shutter closed B04 Y034 FEED ON Station 1 feeding …
Appendix A I/O Map
Version 2.0 A – 18
A00 Y020 PICKUP SOL ON Station 1 pickup stopper solenoid off indicator
A01 Y021 PICKUP SOL OFF Station 1 pickup stopper solenoid on indicator
A02 Y022 PQ ROT SOL ON Station 3 pre theta rotation stopper solenoid
off indicator
A03 Y023 PQ ROT SOL OFF Station 3 pre theta rotation stopper solenoid
on indicator
A04 Y024 PQ ROT. 90DEG Station 3 pre theta rotation advance indicator
A05 Y025 PQ ROT. 270DEG Station 3 pre theta rotation return indicator
A06 Y026
A07 Y027
A08 Y028 PLACE SOL ON Station 7 placing stopper solenoid off indicator
A09 Y029 PLACE SOL OFF Station 7 placing stopper solenoid on indicator
A0A Y02A NOZ SOL ON Station 11 nozzle switch cam stopper solenoid
off
A0B Y02B NOZ SOL OFF Station 11 nozzle switch cam stopper solenoid
on
A0C Y02C NOZ S->L ADV Station 11 nozzle switch direction advance
indicator
A0D Y02D NOZ S->L RET Station 11 nozzle switch direction retract
indicator
A0E Y02E PITCH CYL ADV Station 11 nozzle switch 1 pitch advance
indicator
A0F Y02F PITCH CYL RET Station 11 nozzle switch 1 pitch retract
indicator
Output 2 MX100 Address 0xEF0320
LED No. Display Description
Appendix A I/O Map
A – 19Version 2.0
B00 Y030 ST7 BLOW ON Station 7 blower on
B01 Y031
B02 Y032 F_LIGHT OPEN Front light shutter open
B03 Y033 F_LIGHT SHUT Front light shutter closed
B04 Y034 FEED ON Station 1 feeding lever advance
B05 Y035
B06 Y036
B07 Y037
B08 Y038
B09 Y039
B0A Y03A
B0B Y03B
B0C Y03C
B0D Y03D
B0E Y03E
B0F Y03F
LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 20
A00 Y040
A01 Y041 OTVL CUT ON Overtravel control check
A02 Y042 FIDU LAMP ON Fiducial lamp on
A03 Y043 RINGBLOW ON Ringblow functional
A04 Y044 D1 SET LIGHT Device table 1 part set completed
A05 Y045 D1 SET FLASH Device table 1 part set incomplete
A06 Y046 D2 SET LIGHT Device table 2 part set completed
A07 Y047 D2 SET FLASH Device table 2 part set incomplete
A08 Y048 RED LIGHT Signal tower (red lamp)
A09 Y049 YELLOW LIGHT Signal tower (yellow lamp)
A0A Y04A BLUE LIGHT Signal tower (blue lamp)
A0B Y04B RED FLASH Signal tower (red flash)
A0C Y04C YELLOW FLASH Signal tower (yellow flash)
A0D Y04D BLUE FLASH Signal tower (blue flash)
A0E Y04E
A0F Y04F KEEP POWER ON Maining power
Output 3 MX100 Address OxEF0340
LED No. Display Description
