Appendix A I/O Map A – 21 V ersion 2.0 B00 Y050 B01 Y051 B02 Y052 B03 Y053 B04 Y054 B05 Y055 B06 Y056 B07 Y057 B08 Y058 B09 Y059 B0A Y05A B0B Y05B B0C Y05C B0D Y05D B0E Y05E B0F Y05F LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 20
A00 Y040
A01 Y041 OTVL CUT ON Overtravel control check
A02 Y042 FIDU LAMP ON Fiducial lamp on
A03 Y043 RINGBLOW ON Ringblow functional
A04 Y044 D1 SET LIGHT Device table 1 part set completed
A05 Y045 D1 SET FLASH Device table 1 part set incomplete
A06 Y046 D2 SET LIGHT Device table 2 part set completed
A07 Y047 D2 SET FLASH Device table 2 part set incomplete
A08 Y048 RED LIGHT Signal tower (red lamp)
A09 Y049 YELLOW LIGHT Signal tower (yellow lamp)
A0A Y04A BLUE LIGHT Signal tower (blue lamp)
A0B Y04B RED FLASH Signal tower (red flash)
A0C Y04C YELLOW FLASH Signal tower (yellow flash)
A0D Y04D BLUE FLASH Signal tower (blue flash)
A0E Y04E
A0F Y04F KEEP POWER ON Maining power
Output 3 MX100 Address OxEF0340
LED No. Display Description
Appendix A I/O Map
A – 21Version 2.0
B00 Y050
B01 Y051
B02 Y052
B03 Y053
B04 Y054
B05 Y055
B06 Y056
B07 Y057
B08 Y058
B09 Y059
B0A Y05A
B0B Y05B
B0C Y05C
B0D Y05D
B0E Y05E
B0F Y05F
LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 22
A00 LY000 PCB REQ OUT Board request signal sent to previous stage
A01 LY001 PCB AVAIL OUT Board available signal sent to next stage
A02 LY002 IN CONVEYOR In conveyor motor on
A03 LY003 IN REDUCE In conveyor motor decelerator indicator
A04 LY004 IN STOPPER In conveyor stopper on
A05 LY005 MAIN CONVEYOR Main conveyor motor on
A06 LY006 MAIN REDUCE Main conveyor motor decelerator indicator
A07 LY007 MAIN STOPPER Main conveyor stopper on
A08 LY008 OUT CONVEYOR Out conveyor motor on
A09 LY009
A0A LY00A
A0B LY00B
A0C LY00C
A0D LY00D
A0E LY00E
A0F LY00F
LED No. Display Description
Board Loader PLC Output 1
