Appendix A I/O Map V ersion 2.0 A – 24 A00 L Y200 LOADER AUTO Boar d loader in automatic operation A01 L Y201 LOADER EMG Loader emer gency A02 L Y202 PCB LD REQ1 Board loading request 1 A03 L Y203 PCB LD REQ2 Board loadi…
Appendix A I/O Map
A – 23Version 2.0
B00 LY010 ID CONV ON MCID conveyor motor on
B01 LY011 ID DECEL ON MCID conveyor motor deceleration indicator
B02 LY012 ID REVERSE ON MCID conveyor motor reverse indicator
B03 LY013 ID W. MOTOR ON MCID width adjustment motor operating
B04 LY014 ID W. MOTOR REV MCID width adjust motor reverse indicator
B05 LY015 ID STPR1 ON MCID forward rotation stopper engaged
B06 LY016 ID STPR2 ON MCID reverse rotation stopper engaged
B07 LY017
B08 LY018
B09 LY019
B0A LY01A
B0B LY01B
B0C LY01C
B0D LY01D
B0E LY01E
B0F LY01F
LED No. Display Description
Appendix A I/O Map
Version 2.0 A – 24
A00 LY200 LOADER AUTO Board loader in automatic operation
A01 LY201 LOADER EMG Loader emergency
A02 LY202 PCB LD REQ1 Board loading request 1
A03 LY203 PCB LD REQ2 Board loading request 2
A04 LY204 PCB LD REQ3 Board loading request 3
A05 LY205 CLEAR OFF REQ Board unload request
A06 LY206
A07 LY207
A08 LY208
A09 LY209
A0A LY20A
A0B LY20B
A0C LY20C
A0D LY20D
A0E LY20E
A0F LY20F DATA STROBE Data strobe
OP Link Output 1 MX100 Address 0xEF0380
LED No. Display Description
Appendix A I/O Map
A – 25Version 2.0
B00 LY210 LD STATUS1 Loader status 1
B01 LY211 LD STATUS2 Loader status 2
B02 LY212 LOADER R/W Read/Write bit
B03 LY213 LOADER I/O In/Out bit
B04 LY214 LOADER PORT0 Port number 0 bit (2
0
)
B05 LY215 LOADER PORT1 Port number 1 bit (2
1
)
B06 LY216 LOADER PORT2 Port number 2 bit (2
2
)
B07 LY217 LOADER PORT3 Port number 3 bit (2
3
)
B08 LY218 LOADER DATA0 Outport number 0 bit (2
0
)
B09 LY219 LOADER DATA1 Outport number 1 bit (2
1
)
B0A LY21A LOADER DATA2 Outport number 2 bit (2
2
)
B0B LY21B LOADER DATA3 Outport number 3 bit (2
3
)
B0C LY21C LOADER DATA4 Outport number 4 bit (2
4
)
B0D LY21D LOADER DATA5 Outport number 5 bit (2
5
)
B0E LY21E LOADER DATA6 Outport number 6 bit (2
6
)
B0F LY21F LOADER DATA7 Outport number 7 bit (2
7)
LED No. Display Description
