DEUKYX
2-6193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
11c02
Nozzle arrangement
conrmation
A nozzle cannot be stored. Please check the following. (Block 1)
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
11c03
Nozzle arrangement
conrmation
A nozzle cannot be stored. Please check the following. (Block 2)
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
11c04
Nozzle arrangement
conrmation
The nozzles to be used are insufcient. Please check the following. (Block 1)
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
11c05
Nozzle arrangement
conrmation
The nozzles to be used are insufcient. Please check the following. (Block 2)
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
11c06
Nozzle arrangement
conrmation
The nozzle placement of the head to assist for is different. (Head2)
11c07
Nozzle arrangement
conrmation
The nozzle placement of the head to assist for is different. (Head1)
11c08
Nozzle arrangement
conrmation
The Nozzle used is insufcient for assist. Please arrange the Nozzle used.
11c09
Nozzle arrangement
conrmation
Nozzle placement of Nozzle Stocker is short, the sequence that cannot change
a nozzle for exists. Please conrm nozzle stocker placement.
11c0a
Nozzle arrangement
conrmation
A nozzle exists on Nozzle Stocker, but the sequence that cannot change a
nozzle for by the limitation of the head exists. Please conrm nozzle stocker
placement.
12a01
Tray shortage Comp
(Block1)
Please supply Tray Cmpnt, close Tray Safety door and push Tray Ready SW
(Block1).
12a02
Tray shortage Comp
(Block1)
There is the shortage components. Please supply the components.
12b01
Tray shortage Comp
(Block2)
Please supply Tray Cmpnt, close Tray Safety door and push Tray Ready SW
(Block2).
12b02
Tray shortage Comp
(Block2)
There is the shortage components. Please supply the components.
12c01
Tray is not ready
(Block1)
Error signal of the unit is detected.\r\n(1) Please supply the components. (2)
Please close elevator loading door.\r\n(3) Please press a reset button. (4)
Please release Inhibit button.
12d01
Tray is not ready
(Block2)
Error signal of the unit is detected.\r\n(1) Please supply the components. (2)
Please close elevator loading door.\r\n(3) Please press a reset button. (4)
Please release Inhibit button.
13101 Feeder set Err
A pickup miss comp is detected. (Block1) Please open the safety door and
conrm whether pickup miss comp is dropped. If the comp is dropped, there is
a possibility of interference with Head. A detection state can be checked on a
control screen.
13102 Feeder set Err
The feeder latch worked off. (Block1)
Please close the hook of a feeder. A detection state can be checked on a
control screen.
13103 Feeder set Err
A pickup miss comp is detected. (Block2) Please open the safety door and
conrm whether pickup miss comp is dropped. If the comp is dropped, there is
a possibility of interference with Head. A detection state can be checked on a
control screen.
13104 Feeder set Err
Feeder Latch worked off. (Block2)
Please close the hook of a feeder. A detection state can be checked on a
control screen.
13105 Feeder set Err Not connect selected Feeder.
DEUKYX
2-7193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
13108 Feeder set Err
There is a feeder which is not extracted from machine after tape setting error
detection.
Please extract a feeder from machine once and set a tape to a joint detecting
sensor correctly.
13b01 Stage Ready SW Please wait Stage Ready on.
13c01 Feeder Ready SW Please wait Feeder Ready on
13c02 Feeder Ready SW Do not open Safety Cover while side view camera program is updating.
14101 Operation Parameter
Test mode of transfer set "Disable" in pass mode.
Check settings.
14102 Operation Parameter Operation Mode both Lane A, B is [STOP]. Please execute after reset it.
14103 Operation Parameter
Operation Mode is set except [Placement]. Please set [Placement when do 1
Cmpnt placement.
14201 Device System Setup Please set Input Machine Output Mode [SMEMA Mode].
14202 Device System Setup Please set Output Machine Output Mode [SMEMA Mode].
14b01
Nozzle Placement Data
Check
Current Program Data differs from Nozzle Arrangement Data of Nozzle
Stocker.
15001 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Set type "HA09" nozzle as
Nozzle1 on Head.
15002 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Set type "HA09" nozzle as
Nozzle1 on Head.
15003 Nozzle Location Check Not found tting nozzle for Teaching (Head1). Set type "HA09"nozzle on Head.
15004 Nozzle Location Check Not found tting nozzle for Teaching (Head2).Set type "HA09"nozzle on Head.
15005 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Set type "FF01"or "FF02" nozzle
on Head.
15006 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Set type "FF01"or "FF02" nozzle
on Head.
15007 Nozzle Location Check The different type nozzle is already set (Head1). Please remove it.
15008 Nozzle Location Check The different type nozzle is already set (Head2). Please remove it.
15009 Nozzle Location Check
Not found tting nozzle for Teaching (Head1).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
1500A Nozzle Location Check
Not found tting nozzle for Teaching (Head2).
Set type "FF01"or "FF02" nozzle as Nozzle2 on Head.
1500B Nozzle Location Check
Not found tting nozzle for Teaching (Head1).
Set type "VF02" nozzle on calibrate position.
1500C Nozzle Location Check Not found tting nozzle for Teaching (Head2). Set type "VF02" nozzle on Head.
1500D Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Set type "HA09"or "VF02" nozzle
on Head.
1500E Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Set type "HA09"or "VF02" nozzle
on Head.
1500F Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "HA09" nozzle in
the stocker position where nozzle can change.
15010 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "HA09" nozzle in
the stocker position where nozzle can change.
15011 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "FF01" or "FF02"
nozzle in the stocker position where nozzle can change.
15012 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "FF01" or "FF02"
nozzle in the stocker position where nozzle can change.
DEUKYX
2-8193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
15013 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" nozzle in
the stocker position where nozzle can change.
15014 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" nozzle in
the stocker position where nozzle can change.
15015 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "FA04" nozzle in
the stocker position where nozzle can change.
15016 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "FA04" nozzle in
the stocker position where nozzle can change.
15017 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" or
"HA09" nozzle in the stocker position where nozzle can change.
15018 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" or
"HA09" nozzle in the stocker position where nozzle can change.
15019 Nozzle Location Check
Not found tting nozzle for Teaching (Head1).
Set type "HA09" or "HV19" nozzle as Nozzle1 on Head.
1501A Nozzle Location Check
Not found tting nozzle for Teaching (Head2).
Set type "HA09" or "HV19" nozzle as Nozzle1 on Head.
1501B Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "HA09" or
"HV19" nozzle in the stocker position where nozzle can change.
1501C Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "HA09" or
"HV19" nozzle in the stocker position where nozzle can change.
1501D Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" or
"HA09" or "HV19" nozzle in the stocker position where nozzle can change.
1501E Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" or
"HA09" or "HV19" nozzle in the stocker position where nozzle can change.
1501F Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "PM01" nozzle in
the stocker position where nozzle can change.
15020 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "PM01" nozzle in
the stocker position where nozzle can change.
15101
Nozzle location
teaching, check the
position of nozzle on
head
No found nozzle (Head1). Or, the different Nozzle could be arranged.
15102
Nozzle location
teaching, check on the
position of nozzle on
head
No found nozzle (Head2). Or, the different Nozzle could be arranged.
15201
Teaching check the
conveyor
No PCB on Conveyor. Please put PCB in.
15202
Teaching check the
conveyor
Please set PCB positioning. Please set it again after cancel positioning if PCB
positioning is already done.
15203
Teaching check the
conveyor
Please push Conveyor Width Moving.
15301
ODD Head Nozzle
stocker check
There does not exist stocker that can replace nozzle (Block1).
15302
ODD Head Nozzle
stocker check
There does not exist stocker that can replace nozzle (Block2).
16001 Tray teaching Traverse of Tray is not drawn out (Block1). Draw out Traverse.
16002 Tray teaching Tray Traverse is not drawn out (Block2). Draw out Traverse.
16003 Tray teaching
The component of the specied number of matrices cannot be photoed with a
PEC recognition camera.
16004 Tray teaching The component is not drawn out (Block1). Draw out the component.
