DEUKYX
2-8193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
15013 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" nozzle in
the stocker position where nozzle can change.
15014 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" nozzle in
the stocker position where nozzle can change.
15015 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "FA04" nozzle in
the stocker position where nozzle can change.
15016 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "FA04" nozzle in
the stocker position where nozzle can change.
15017 Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" or
"HA09" nozzle in the stocker position where nozzle can change.
15018 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" or
"HA09" nozzle in the stocker position where nozzle can change.
15019 Nozzle Location Check
Not found tting nozzle for Teaching (Head1).
Set type "HA09" or "HV19" nozzle as Nozzle1 on Head.
1501A Nozzle Location Check
Not found tting nozzle for Teaching (Head2).
Set type "HA09" or "HV19" nozzle as Nozzle1 on Head.
1501B Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "HA09" or
"HV19" nozzle in the stocker position where nozzle can change.
1501C Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "HA09" or
"HV19" nozzle in the stocker position where nozzle can change.
1501D Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "BF02" or
"HA09" or "HV19" nozzle in the stocker position where nozzle can change.
1501E Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "BF02" or
"HA09" or "HV19" nozzle in the stocker position where nozzle can change.
1501F Nozzle Location Check
Not found tting nozzle for Teaching (Head1). Please set type "PM01" nozzle in
the stocker position where nozzle can change.
15020 Nozzle Location Check
Not found tting nozzle for Teaching (Head2). Please set type "PM01" nozzle in
the stocker position where nozzle can change.
15101
Nozzle location
teaching, check the
position of nozzle on
head
No found nozzle (Head1). Or, the different Nozzle could be arranged.
15102
Nozzle location
teaching, check on the
position of nozzle on
head
No found nozzle (Head2). Or, the different Nozzle could be arranged.
15201
Teaching check the
conveyor
No PCB on Conveyor. Please put PCB in.
15202
Teaching check the
conveyor
Please set PCB positioning. Please set it again after cancel positioning if PCB
positioning is already done.
15203
Teaching check the
conveyor
Please push Conveyor Width Moving.
15301
ODD Head Nozzle
stocker check
There does not exist stocker that can replace nozzle (Block1).
15302
ODD Head Nozzle
stocker check
There does not exist stocker that can replace nozzle (Block2).
16001 Tray teaching Traverse of Tray is not drawn out (Block1). Draw out Traverse.
16002 Tray teaching Tray Traverse is not drawn out (Block2). Draw out Traverse.
16003 Tray teaching
The component of the specied number of matrices cannot be photoed with a
PEC recognition camera.
16004 Tray teaching The component is not drawn out (Block1). Draw out the component.
DEUKYX
2-9193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
16005 Tray teaching The component is not drawn out (Block2). Draw out the component.
16101 Coplanarity Teaching
"Coplanarity Detection" of Test Operation Mode is set "No". Execute it after
cancelling Test Operation Mode.
16201 Coplanarity Test Please pickup part.
17009
Teaching Check on the
position of Glass jig
Not found Glass Jig for Teaching. Please check that Glass Jig is set in its
position.
17201 Nozzle set-up (Block1)
Nozzle Placement/Store mode of Stocker (Block2) is not possible to operate.
Please specify Stocker (Block1).
17202 Nozzle set-up (Block1)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
17203 Nozzle set-up (Block1)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
17204 Nozzle set-up (Block1)
Because of interference with Nozzle which is already placed, it cannot be
placed. Do not place Nozzle in the front and rear of two Odd nozzle placed.
17205 Nozzle set-up (Block1) Placement/Store is impossible in the position for the specied stocker.
17206 Nozzle set-up (Block1)
It is impossible to place it because of interfering in the placed nozzle. Please
do not place a nozzle before or after placing ODD nozzle.
17301 Nozzle set-up (Block2)
Nozzle Placement/Store mode of Stocker (Block1) is not possible. Please set
Stocker (Block2).
17302 Nozzle set-up (Block2)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
17303 Nozzle set-up (Block2)
High nozzle cannot be stored while Odd nozzle is placed. Please restart after
returning all Odd Nozzle.
17304 Nozzle set-up (Block2)
Because of interference with Nozzle which is already placed, it cannot be
placed. Do not place Nozzle in the front and rear of two Odd nozzle placed.
17305 Nozzle set-up (Block2) Placement/Store is impossible in the position for the specied stocker.
17306 Nozzle set-up (Block2)
It is impossible to place it because of interfering in the placed nozzle. Please
do not place a nozzle before or after placing ODD nozzle.
17401
Button for inserting
power
Can not supply power while Side view camera program is on writing. Operate it
after writing completely.
17501
Operation mode set
conrmation
"Feeder Connection" or "Feeder Serial Communication" of Test Operation
Mode is set. Execute it after reset Operation Mode.
17502
Operation mode set
conrmation
"Component Feed" of Test Operation Mode is set. Execute it after reset
Operation Mode.
17601 Inching movement Perform zeroing.
17602 Inching movement Please push the Feeder Base Ready SW.
17603 Inching movement Close the safety door of Tray, and press the Ready button.
17604 Inching movement The range is out of movable Range.
17605 Inching movement
HL-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of HL-axis or move it to origin position.
17606 Inching movement
L1-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L1-axis or move it to origin position.
17607 Inching movement
L2-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L2-axis or move it to origin position.
17608 Inching movement
L3-axis is fallen. There is a possibility of collision between Noz and axis.
Please perform zeroing of L3-axis or move it to origin position.
17701 Zeroing (set axis) Push Ready SW of Feeder Base.
17702 Zeroing (set axis) Close the safety door of Tray, and press the Ready button.
DEUKYX
2-10193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
18001
Recycling Conveyor
(Block1)
Recycle Conveyor (Block1) is lled up.
18002
Recycling Conveyor
(Block1)
The connection of Recycling Conveyor (Block1) differs from Cmpnt Arranging
Data. Or, it has multi-connection.
18003
Recycling Conveyor
(Block1)
Recycling Conveyor (Block1) is on ready. Please remove parts and resume
production after completion of operation.
18004
Recycling Conveyor
(Block1)
Recycling conveyer is connected to F159. Please be connected to the range of
F105-F157 or F205-F257 again.
18101
Recycling Conveyor
(Block2)
Recycling Conveyor (Block2) is lled up.
18102
Recycling Conveyor
(Block2)
The connection of Recycling Conveyor (Block2) differs from Cmpnt Arranging
Data. Or, it has multi-connection.
18103
Recycling Conveyor
(Block2)
Recycling Conveyor (Block2) is on ready. Please remove parts and resume
production after completion of operation.
18104
Recycling Conveyor
(Block2)
Recycling conveyer is connected to F259. Please be connected to the range of
F105-F157 or F205-F257 again.
18201 Tray (Block1)
Close the safety door of Tray, and press a button [READY] of it. When Tray
[READY] does not change to [ON], press the button [READY] of Feeder.
18202 Tray (Block1) Pallet of Tray is drawn out. Execute zeroing all, and store the pallet.
18203 Tray (Block1) Tray breaking out was detected. Execute zeroing all, and store the pallet.
18204 Tray (Block1) Press [READY] button of Feeder base, and supply the power of Tray.
18205 Tray (Block1) Close the safety door (Center) of Tray, and press [READY] button.
18206 Tray (Block1) Close the safety door (Lower) of Tray, and press [READY] button.
18207 Tray (Block1) Close the safety door (Upper) of Tray, and press [READY] button.
18208 Tray (Block1) Zeroing of Traverse-axis is not nished. Perform zeroing of Tray.
18209 Tray (Block1) Zeroing of Elevator1-axis is not nished. Perform zeroing of Tray.
1820a Tray (Block1) Zeroing of Elevator2-axis is not nished. Perform zeroing of Tray.
1820b Tray (Block1) Pickup miss cmpnt (8 mm) is detected.[B15417]
1820c Tray (Block1) Pickup miss cmpnt (14 mm) is detected.[B15418]
1820d Tray (Block1) Pickup miss cmpnt (28 mm) is detected.[B15419]
1820e Tray (Block1) Pallet Chuck Claw is open.
1820f Tray (Block1) Pallet Error is detected.
18210 Tray (Block1) Magazine 1 (Lower) Shutter on Traverse side is open.
18211 Tray (Block1) Magazine 2 (Upper) Shutter on Traverse side is open.
18212 Tray (Block1) Access detecting Sensor (Right) : Cannot detect Elevator Unit
18213 Tray (Block1) Access detecting Sensor (Left) : Cannot detect Elevator Unit
18214 Tray (Block1) Pick-up miss cmpnt is detected.
18215 Tray (Block1) Traverse axis is not on origin. Please perform zeroing of Tray.
18216 Tray (Block1) Tray is running. Please operate it after completion.
18217 Tray (Block1) Please supply Tray Cmpnt after all zeroing.
18218 Tray (Block1) The supply area magazine has an unsettled palette. Please remove it.
18219 Tray (Block1) A head and a traverse axis interfere it. Please evacuate in a head.
