DEUKYX
2-11193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
18301 Tray (Block2)
Close the safety door of Tray, and press a button [READY] of it. When Tray
[READY] does not change to [ON], press the button [READY] of Feeder.
18302 Tray (Block2) Pallet of Tray is drawn out. Execute zeroing all, and store the pallet.
18303 Tray (Block2) Pallet Error of Tray is detected. Execute zeroing all, and store the pallet.
18304 Tray (Block2) Press [READY] button of Feeder base, and supply the power of Tray.
18305 Tray (Block2) Close the safety door (Center) of Tray, and press [READY] button.
18306 Tray (Block2) Close the safety door (Lower) of Tray, and press [READY] button.
18307 Tray (Block2) Close the safety door (Upper) of Tray, and press [READY] button.
18308 Tray (Block2) Zeroing of Traverse-axis is not nished. Perform zeroing of Tray.
18309 Tray (Block2) Zeroing of Elevator1-axis is not nished. Perform zeroing of Tray.
1830a Tray (Block2) Zeroing of Elevator2-axis is not nished. Perform zeroing of Tray.
1830b Tray (Block2) Pickup miss cmpnt (8 mm) is detected.[B15417]
1830c Tray (Block2) Pickup miss cmpnt (14 mm) is detected.[B15418]
1830d Tray (Block2) Pickup miss cmpnt (28 mm) is detected.[B15419]
1830e Tray (Block2) Pallet Chuck Claw is open.
1830f Tray (Block2) Pallet Error is detected.
18310 Tray (Block2) Magazine1 (Lower) Shutter on Traverse side is open.
18311 Tray (Block2) Magazine2 (Upper) Shutter on Traverse side is open.
18312 Tray (Block2) Access detecting Sensor (Right) : Cannot detect Elevator Unit
18313 Tray (Block2) Access detecting Sensor (Left) : Cannot detect Elevator Unit
18314 Tray (Block2) Pick-up miss cmpnt is detected.
18315 Tray (Block2) Traverse axis is not on origin. Please perform zeroing of Tray.
18316 Tray (Block2) Tray is running. Please operate it after completion.
18317 Tray (Block2) Please supply Tray Cmpnt after all zeroing.
18318 Tray (Block2) The supply area magazine has an unsettled palette. Please remove it.
18319 Tray (Block2) A head and a traverse axis interfere it. Please evacuate in a head.
18401
Tray is not ready to
zeroing (Block1)
Execute all zeroing.
18501
Tray is not ready to
zeroing (Block2)
Execute all zeroing.
18601 Warning of wiring error Vacuum Pump 1CB Error
18602 Warning of wiring error Monitor Error of DC load power
18603 Warning of wiring error Beam 1 CB Error Monitor Error
18604 Warning of wiring error Beam 2 CB Error Monitor Error
18701 Feeder Alternate Illegal alternate setup of pattern program. Check the settings.
18702 Feeder Alternate Invalid feeder in alternating. Set feeder valid
18801 XY Origin Offset
Since the data transfer of XY-Origin offset is not completed, please perform
again after waiting for a while (Beam 1).
18802 XY Origin Offset
Since the data transfer of XY-Origin offset is not completed, please perform
again after waiting for a while (Beam 2).
DEUKYX
2-12193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
18901 Feeder communication
Feeder (Block1) is on communication. Please wait for a second, and then
operate again.
18902 Feeder communication
Feeder (Block2) is on communication. Please wait for a second, and then
operate again.
18a01
Library Feed Pitch
check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
(Block1)
18a02
Library Feed Pitch
check
Library Feed Pitch differs from Feeder. Please check Library and Feeder.
(Block2)
18b01
Library Tape Width
check
Library Tape Width differs from Feeder. Please check Library and Feeder.
(Block1)
18b02
Library Tape Width
check
Library Tape Width differs from Feeder. Please check Library and Feeder.
(Block2)
19001 Support Pin Please move exchange position of support pin.
19002 Support Pin
There is no available nozzle for backup pin exchange. In the case of a multi
function head, please set a Nozzle to No.1 - No.5 of the stocker, and secure a
Nozzle storage space to No.1 - No.5 of the stocker.
19003 Support Pin
Arranging data in current differs from it of Support Pin of current pattern
program. Please set-up the support pin.
19004 Support Pin
When PCB size 216 mm is exceeded, it is impossible to operate if Support pins
of Lane A remain. Please exchange Lane A, or take out it from machine.
19005 Support Pin
It is impossible to do operation for only Lane B because Support Pins of Lane
A remain. Please exchange Lane A, or take out it from machine.
19006 Support Pin
Operation for Lane A is impossible because Support Pins of Lane A have not
been installed. Please exchange Support pins or store them.
19007 Support Pin
It is impossible to do Operation for only Lane A because Support Pins of Lane
B remain. Please exchange Lane B, or take out it from machine.
19008 Support Pin
Support pins of Lane B remain on the base for Support pins of Lane A, so that
it is impossible to do Conveyor width. Please exchange Support pins or store
them.
19009 Support Pin Arrangement of Support Pins interferes in Conveyor. Please retry to arrange it.
1900A Support Pin
“Vacuum/Blower” of Test Operation Mode is set “Disable”. Execute it after
cancelling Test Operation Mode.
1900B Support Pin
An unsettled component or a Support pin was detected (Head1). Please check
the state of Head, and discard the component.
1900C Support Pin
An unsettled component or a Support pin was detected (Head2). Please check
the state of Head, and discard the component.
1900D Support Pin Please exchange Support pins or store them.
1900E Support Pin
PCB Y size and Conveyor Width in Current Program are not equal. Please
change Current Program.
19101 Single-Tray (Block1)
The connection of Single-Tray differs from Cmpnt Arranging Data. Please
connect Single-Tray to Lane No.25 and No.55 Of Feeder cart.
19102 Single-Tray (Block1) Pallet Error of Single-Tray is detected. Please set Pallet to the inside.
19201 Single-Tray (Block2)
The connection of Single-Tray differs from Cmpnt Arranging Data. Please
connect Single-Tray to Lane No.25 and No.55 Of Feeder cart.
19202 Single-Tray (Block2) Pallet Error of Single-Tray is detected. Please set Pallet to the inside.
3012c Operation Requirement Please change enable mode into disable mode. (serial out mode)
30162 Operation Requirement The pattern cannot be switched
30413 Operation Requirement Specify the order No.
DEUKYX
2-13193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
30416 Operation Requirement
ACV server does not pass the authorization. Please retry to connect to server
on a screen [UNIT ADJ]-[ACV Set].
3041C Operation Requirement
ACV Check Error. Component ID on the feeder is not same as one specied by
current program.
30420 Operation Requirement
Communications with the ACV server is impossible. After conrming the ACV
server, please retry to perform it. [MAINT]-[UNIT ADJ]-[ACV ADJ].
30421 Operation Requirement
ACV server is out of condition. Check the ACV server. Check HDD capacity,
database breakage, the condition of each module and communication between
severs.
30430 Operation Requirement
Can not detect Feeder cart (Block1). Please set Feeder cart to the inside.
[B0910, B0911]
30431 Operation Requirement
Can not detect Feeder cart (Block2). Please set Feeder cart to the inside.
[B0910, B0911]
30432 Operation Requirement
The connector of the feeder base (Block1) is not connected to the main body,
so that please connect it. [B0916]
30433 Operation Requirement
The connector of the feeder base (Block2) is not connected to the main body,
so that please connect it. [B0916]
30440 Operation Requirement The Safety cover is open. Please close it.
30441 Operation Requirement
It is impossible to do Pass Operation without Cart because func of Traceability
is valid. Please restart after setting Option invalid.
30442 Operation Requirement
It cannot run because a simple Cover locked. First, set Stage ready OFF, then
set Stage ready ON.
30450 Operation Requirement To run is impossible by start protect.
30451 Operation Requirement
Cannot start to run because the output folder on server is disconnected. Please
check output folder setting and the server status of output folder.
30452 Operation Requirement
When “”Lne Operatin System”” is specied besides [LISA], the[Enable (In
Order)] setting cannot be done to “”B.C.D.PpChg-P.P.Chng.Func set””.
30453 Operation Requirement
When “”Lne Operatin System”” is specied besides [LISA], the[Enable (BS)]
setting cannot be done to “”B.C.D.PpChg-P.P.Chng.Func set””.
30454 Operation Requirement
To run is impossible by shortage of components. (Component Remain Stop
Mode: PCB) Please supply the components.
30455 Operation Requirement
To run is impossible by shortage of components. (Component Remain Stop
Mode: Product PCB) Please supply the components.
30456 Operation Requirement
Since the [PCB Finishing Position] data of a Crnt.Prgm is a nish setup
[Sequence], it cannot start (Component Remain Stop Mode). Please set to the
[Output] or the [Input]
30457 Operation Requirement Please start Auto Opn after Comp library data updating.
30458 Operation Requirement The component skip is set up. Please choose other steps.
30459 Operation Requirement
Cannot start to run because the machine event output server is disconnected.
Please check machine event output setting and the server status of output.
30460 Operation Requirement
Moisture deadline of component has passed.
Please replace the component in the moisture deadline.
30461 Operation Requirement
Customer system cooperation: The machine is communicating the non-output
information of the traceability information. Please wait for a second, and then
operate again.
30462 Operation Requirement
AOI feedforward function: The machine is communicating the non-output
information of the Inspection information. Please wait for a second, and then
operate again.
30463 Operation Requirement
Cannot start to run because a LCR check is uncompleted. Please check a
target component in a LCR check screen.
