2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
30501
Misidentication a type
of Tray
The connected Tray unit (Block1) doesn’t match settings of Device. Please
conrm a type of tray unit, and set it on unit exchange screen.
30502
Misidentication a type
of Tray
The connected Tray unit (Block2) doesn’t match setup of Device. Please
conrm a type of tray unit, and set it on Unit Exchange Screen.
30601
Conrmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block1) on Unit exchange
Screen.
30602
Conrmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please set the location of Noz stocker of Device (Block2) on Unit exchange
Screen.
30603
Conrmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please conrm the location of Noz stocker of Device (Block1).
30604
Conrmation of the
position of Noz Stocker
Cannot use Noz stocker from the second to the forth line when full tray is used.
Please conrm the location of Noz stocker of Device (Block2).
30701
Conrmation of 2D Bar
code Data
Mark No. of Operating Parameter/2D Bar Code data is specied as All Skip (0).
Please specify proper Mark No.
30801
Detect nozzle coming
off multi-functional
stocker
Machine (Block1) Detected that nozzle has come off the multi-functional
stocker of the 1st line.
30802
Detect nozzle coming
off multi-functional
stocker
Machine (Block1) Detected that nozzle has come off the multi-functional
stocker of the 4th line.
30803
Detect nozzle coming
off multi-functional
stocker
Machine (Block2) Detected that nozzle has come off the multi-functional
stocker of the 1st line.
30804
Detect nozzle coming
off multi-functional
stocker
Machine (Block2) Detected that nozzle has come off the multi-functional
stocker of the 4th line.
30901
Head nozzle dropped
detect
Please lock the main safety cover. Please perform all-zeroing when the main
safety cover has already been locked.
50201
Conrmation of PCB
existence
Remove PCB from the conveyor. Please delete the PCB memory information
on the edit screen if it remains.
50202
Conrmation of PCB
existence
PCB is detected from Input position when Finish mode is set [Output]. Please
PCB from conveyor.
50203
Conrmation of PCB
existence
PCB is detected from Output position when Finish mode is set [Input]. Please
PCB from conveyor.
50204
Conrmation of PCB
existence
PCB is detected from Inlet sensor of input conveyor. Please remove PCB.
50205
Conrmation of PCB
existence
The operation mode of Lane A is set [STOP]. Please remove PCB when not
transferred.
50206
Conrmation of PCB
existence
The operation mode of Lane B is set [STOP]. Please remove PCB when not
transferred.
50207
Conrmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the input conveyor.
Please remove PCB from Deceleration Sensor, or move it to Stop sensor, or
delete the PCB memory information.
50208
Conrmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the input conveyor
in Lane A. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
50209
Conrmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the output conveyor
in Lane B. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
DEUKYX
2-15193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
5020a
Conrmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
input side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
5020b
Conrmation of PCB
existence
There is a possibility that there are 2 sheets of PCB on the shuttle conveyor in
output side. Please remove PCB from Deceleration Sensor, or move it to Stop
sensor, or delete the PCB memory information.
5020c
Conrmation of PCB
existence
There is PCB on the input sensor of Lane A. Please return PCB to the input
conveyor and run it.
5020d
Conrmation of PCB
existence
There is PCB on the input sensor of Lane B. Please return PCB to the input
conveyor and run it.
5020e
Conrmation of PCB
existence
There is PCB on the input sensor. Please return PCB to the input conveyor and
run it.
5020f
Conrmation of PCB
existence
There is no PCB in the machine. Please position a PCB.
50210
Conrmation of PCB
existence
Please put PCB on the positioning conveyor, and start it.
50211
Conrmation of PCB
existence
Please remove PCB from input position. Cutout PCB cannot be transferred
from input position.
50212
Conrmation of PCB
existence
Please remove the substrate at the upstream position. The substrate for weight
to exceed 2.5 kg cannot be transported simultaneously.
50213
Conrmation of PCB
existence
Please remove the substrate at A lane upstream position. The substrate for
weight to exceed 2.5 kg cannot be transported simultaneously.
50214
Conrmation of PCB
existence
Please remove the substrate at B lane upstream position. The substrate for
weight to exceed 2.5 kg cannot be transported simultaneously.
50215
Conrmation of PCB
existence
After a PCB disappears from the input conveyor of output machine, please
perform (PCB clip lump prevention).
Please switch on a power supply, when the power supply of output machine is
not on.
50216
Conrmation of PCB
existence
Please cancel positioning of a PCB and perform in the state where there is no
PCB.
50220
Conrmation of PCB
existence
2 PCB are between the input conveyor and the upstream position. Take PCB in
a one side.
50221
Conrmation of PCB
existence
A stop place of a PCB is unsettled. Please establish PCB memory information.
50222
Conrmation of PCB
existence
A PCB is on the upstream position stop sensor. Please put a PCB in the
location an upstream stop sensor doesn’t turn on.
50223
Conrmation of PCB
existence
It is not possible to operate, because there is a PCB in the upstream position.
50224
Conrmation of PCB
existence
Please put a P.C.B. in the location a deceleration sensor of a input conveyor
turns on.
50301
Conrmation of
Firmware version
Firmware of transfer driver is not the latest version. Please update it.
50401 Manual transfer
PCB (X > 260 mm) which is set by PP data is unable to be taken in Input
Position.
50402 Manual transfer
Please operate after removing PCB from output conveyor. There is a possibility
of pushing and rising with Stopper.
50403 Manual transfer
It is impossible to take from Sensor Detection of Input Position. Please put
PCB on Input Conveyor, or move it to Output position in Recovery Menu.
50404 Manual transfer
PCB (X > 260 mm) which is set by PP data is unable to be taken in Input
Conveyor.
50405 Manual transfer
There is PCB on Deceleration Sensor of Input Conveyor. There is a possibility
that PCB is inserted.
DEUKYX
2-16193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
50406 Manual transfer
There is PCB on Deceleration Sensor of Shuttle Conveyor in Output side.
There is a possibility that PCB is inserted.
50407 Manual transfer
Lane A is not able to be set in Current Program. Please change Current
Program or change to Lane B.
50408 Manual transfer
Lane B is not able to be set in Current Program. Please change Current
Program or change to Lane A.
50409 Manual transfer
PCB Y size and Conveyor Width in Current Program are not equal. Please
change Current Program.
5040a Manual transfer Cutout PCB cannot be taken in input position.
5040b Manual transfer
Please remove PCB from input position. Cutout PCB cannot be transferred
from input position.
5040c Manual transfer It is not possible to transport it to the specied position.
5040d Manual transfer
It is not possible to operate because it interferes in the adsorption treatment
device.
5040e Manual transfer It composes the device, and it is not possible to operate.
5040f Manual transfer
PCB (X > 280 mm) which is set by PP data is unable to be taken in Input
Position.
50410 Manual transfer Output a PCB after interrupting operation.
50411 Manual transfer
It is not possible to operate, because there is a PCB in the upstream position.
Please take a PCB from upstream position.
50412 Manual transfer
It is not possible to operate, because there is a P.C.B. in the input conveyor.
Please take a P.C.B. in the input conveyor.
50501 Convert Width Setup
Please set conveyor width 49.5 ~ 461.5 mm. The total of PCB size/offset/
clearance is over movable range.
50502 Convert Width Setup
Please set conveyor width 49.5 ~ 382.5 mm. The total of PCB size/offset/
clearance is over movable range.
50503 Convert Width Setup
Movable Range for the destination of W1 is set. Please check PCB size/offset/
clearance of Lane A.
50504 Convert Width Setup
Movable Range for the destination of W1 is set. Please check PCB size/offset/
clearance of Lane A.
50505 Convert Width Setup
Movable Range for the destination of W2 is set. Please check PCB size/offset/
clearance of Lane A
50506 Convert Width Setup
Movable Range for the destination of W2 is set. Please check PCB size/offset/
clearance of Lane A.
50507 Convert Width Setup
Movable Range for the destination of W3 is set. Please check PCB size/offset/
clearance of Lane B.
50508 Convert Width Setup
Movable Range for the destination of W3 is set. Please check PCB size/offset/
clearance of Lane B.
50509 Convert Width Setup
These is a possibility of the interference with W1 and W2. Please check PCB
size/offset/clearance of Lane A.
5050a Convert Width Setup
There is a possibility of the interference with W2 and W3. Please Check PCB
size/offset/clearance of Lane A/B.
5050b Convert Width Setup
There is an interference between object position of Conveyor and Support Pin.
Please exchange Support Pin.
50510 Convert Width Setup Zeroing of W1 axis is not nished. Please perform zeroing of W1 axis.
50511 Convert Width Setup Zeroing of W2 axis is not nished. Please perform zeroing of W2 axis.
50512 Convert Width Setup Zeroing of W3 axis is not nished. Please perform zeroing of W3 axis.
50513 Convert Width Setup
The set value of W1 axis exceeds the soft limit. Please determine the value
within the range from 300.5 mm to 468.5 mm.
