DEUKYX
2-17193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
50514 Convert Width Setup
The set value of W1 axis exceeds the soft limit. Please determine the value
within the range from 368.5 mm to 536.5 mm.
50515 Convert Width Setup
The set value of W2 axis exceeds the soft limit. Please determine the value
within the range from 250.5 mm to 418.0 mm.
50516 Convert Width Setup
The set value of W2 axis exceeds the soft limit. Please determine the value
within the range from 284.5 mm to 452.0 mm.
50517 Convert Width Setup
The set value of W3 axis exceeds the soft limit. Please determine the value
within the range from 49.5 mm to 382.5 mm.
50518 Convert Width Setup
The set value of W3 axis exceeds the soft limit. Please determine the value
within the range from 83.5 mm to 416.5 mm.
50519 Convert Width Setup
There is an interference between W1 axis and W2 axis. Please change the
value or separate the interfering axis.
5051a Convert Width Setup
There is an interference between W2 axis and W3 axis. Please change the
value or separate the interfering axis.
5051b Convert Width Setup
Please set conveyor width 83.5~511.5 mm. The total of PCB size/offset/
clearance is over movable range.
5051c Convert Width Setup
Please set conveyor width 49.5~511.5 mm. The total of PCB size/offset/
clearance is over movable range.
50601 Convert Width Setup
Rotation Direction set of Middle Conveyor in supply side differs from Main
Device transfer direction. Please change the rotation direction of Middle
conveyor.
50602 Convert Width Setup
Emergency Stop switch of middle conveyor in supply side is pressed. Please
cancel it.
50603 Convert Width Setup Safety Cover of middle conveyor in supply side is open. Please close it.
50604 Convert Width Setup
Input Machine communication mode is set [PUSHER]. Cannot use [PUSHER]
mode when Middle Conveyor is contacted.
50611 Convert Width Setup
Rotation Direction set of Middle Conveyor in output side differs from Main
Device transfer direction. Please change the rotation direction of Middle
conveyor.
50612 Convert Width Setup
Emergency Stop switch of middle conveyor in output side is pressed. Please
cancel it.
50613 Convert Width Setup The Safety Cover of middle conveyor in output side is open. Please close it.
050701 Convert Width Setup
Emergency Stop Switch of Shuttle Conveyor in Input side is pressed. Please
cancel it.
050702 Convert Width Setup The safety cover of Shuttle Conveyor in Input side is open. Please close it.
050703 Convert Width Setup
Deceleration sensor of Shuttle Conveyor in Input side is detected. Please
remove PCB because there is a possibility that it is inserted.
050704 Convert Width Setup
Deceleration Sensor of Input Conveyor is detected. Please remove PCB
because there is a possibility that it is inserted.
050705 Convert Width Setup
Deceleration Sensor of Input Conveyor in Lane A is detected. Please remove
PCB because there is a possibility that it is inserted.
050706 Convert Width Setup
Deceleration Sensor of Input Conveyor in Lane B is detected. Please remove
PCB because there is a possibility that it is inserted.
050707 Convert Width Setup
Set Value of Delivery Position of Device System/Input Machine PCB is not in
the Movable Range. Please set the value 467 mm and less whose value is the
sum with Y size of PCB.
050708 Convert Width Setup
Please set [SMEMA] Mode for Device System/Input Machine Output. And,
Please conrm that Inp/Outp Machine Signal is set as [Enable].
050709 Convert Width Setup
Please set the same value in Lane A / Lane B of Delivery Position of Device
System/Input Machine PCB.
DEUKYX
2-18193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
050711 Convert Width Setup
Emergency Stop Switch of Shuttle Conveyor in Output side is pressed. Please
cancel it.
050712 Convert Width Setup The safety cover of Shuttle Conveyor in Output side is open. Please close it.
050713 Convert Width Setup
Deceleration Sensor of Shuttle Conveyor in Output side is detected. Please
remove PCB there is a possibility that it is inserted.
050714 Convert Width Setup
Stop Sensor of Output Conveyor is detected. Please remove PCB there is a
possibility that it is inserted.
050715 Convert Width Setup
Stop Sensor of Output Conveyor in Lane A is detected. Please remove PCB
there is a possibility that it is inserted.
050716 Convert Width Setup
Stop Sensor of Output Conveyor in Lane B is detected. Please remove PCB
there is a possibility that it is inserted.
050717 Convert Width Setup
Set Value of Delivery Position of Device System/Output Machine PCB is not in
the Movable Range. Please set the value 467 mm and less whose value is the
sum with Y size of PCB.
050718 Convert Width Setup
Please set [SMEMA] Mode for Device System/Output Machine Output. And,
Please conrm that Inp/Outp Machine Signal is set as [Enable].
050801
Warning about
Maintenance
It is time to perform the feeder maintenance.
60101
Feeder communication
Error
Can not communicate with Feeder. Please conrm that selected Feeder is put
in.
60201 Feeder type Error Library and Feeder are inconsistent.
60301
Feeder preparation
Error
Please drop Feeder base once. Then, rise it again.
60401 Feeder No. Error Cannot Pick-up The Feeder. Please select another one.
60501 Nozzle Check Nozzle is placed. Please Store it, and then retry to execute.
60601 Cart Check
Safety cover was not locked by following reasons. 1. Feeder Cart position
[S151F,S151B] 2. Safety circuit (Safety Relay [K3,K4], Safe cover lock
[S131,S132], Emergency stop [S105F,S105B], Magnetic contractor
[K33A,K33B], Relay [K11], Cable condition)
60602 Cart Check Cart (Block1) is not at upper position. Please put it up.
60603 Cart Check Cart (Block2) is not at upper position. Please put it up.
60604 Cart Check
Cannot operate it because Cart (Block1) is not at upper position or its
connector is off.
( It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
60605 Cart Check
Cannot operate it because Cart (Block2) is not at upper position or its
connector is off.
(It is dangerous to put the hand into a space between the Cart and the Safety
Cover.)
60606 Cart Check Please operate it after shutting the feeder area cover (Blocks 1 and 2).
60701
Error in Carrier
supplying Cmpnt
It is impossible to pick-up this cmpnt from specied Feeder. Please change the
Placement mode as [By Hand].
60702
Error in Carrier
supplying Cmpnt
Feeder location in equipment is not in agreement with a current pattern
program.
Please check feeder location in a FEEDER LOCATION screen.
60801 Cutter Please close and lock the safety cover, and then operate it (Block1).
60802 Cutter Please close and lock the safety cover, and then operate it (Block2).
DEUKYX
2-19193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
070101 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Enable]. Please set Pattern program [Disable]. Or,
set up Jig and select [Jig] on the unit replace screen.
070102 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Disable]. Please set Pattern program [Enable]. Or,
take off Jig and select [None] on the unit replace screen.
070103 Data matching Input machine differs from Crnt. PP. Please match the Crnt. PP.
070104 Data matching
Failed to consistency check of input machine. Please checking LAN
connection.
070105 Data matching
Output machine differs from Crnt. PP. Please match the Crnt. PP of the Output
machine. Please set P.C.B. counter of the Output machine.
0d0a01 Nozzle position Nozzle is fallen. Please perform the all zeroing.
0d0b01
Conrmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove or x it.
0d0b02
Conrmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove it.
0d0c01
Pickup miss comp,
Disengaged Latch
Check
Please open the safety door and conrm whether pickup miss comp is dropped
or no disengaged Latch is exist. If the comp is dropped, there is a possibility of
interference with Head. A detection state can be checked on a control screen.
0d0d01 Conrm bending Noz Open the safety door, and then conrm whether Noz placed in head is bent.
0d0e01
Zeroing of Cutter is not
completed
Perform All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head1).
Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head2).
Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching Tray’s Pallet is not pulled out (Block1). Please pull it out.
0d0f04 Height Teaching Tray’s Pallet is not pulled out (Block2). Please pull it out.
0d0f05 Height Teaching
Cannot teach Stocker Master height of the third and forth line for Stocker 2 of
One side Machine.
0d0f06 Height Teaching
There is no place for Glass Jig in the Head, so that could not teach the height
of Glass Jig.
0d1001 Stop Command Interlock is detected. Please retry to execute after removing the factor.
0d1101
Flux dispensing unit
squeegee error detect
Please put down squeegee not to separate from ux dispensing unit.
0d1201
Flux dispensing unit
motor warning detect
Please take out/in ux dispensing and then restart to run.
0d1301
Uninstalled Flux
dispensing unit
Please set ux dispensing unit to use in pattern program data.
0d1401 Head type error Please restart it after setting the head type properly.
0d1501 Keep large nozzle
Please remove the large nozzle on the head1 by hand. Please retry to operate
it after editing nozzle arrangement data
0d1502 Keep large nozzle
Please remove the large nozzle on the head2 by hand. Please retry to operate
it after editing nozzle arrangement data
0d1601
Large nozzle
interference
The large nozzle is set positioning in the interfering position. Please set
positioning in the not interfering position, or perform all zeroing.
0d1602
Large nozzle
interference
Operation is impossible because large nozzles are placed in 2 axes adjacent
to the head1. Please take off one of them by hand, and then edit the nozzle
arrangement data.
