DEUKYX 2-20 193-41 10 2.2 Management-Informationsliste Code Anzeigebereich A Anzeigebereich B 0d1603 Large nozzle interference Operation is impossible because large nozzles are placed in 2 axes adjacent to the head2. Ple…
DEUKYX
2-19193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
070101 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Enable]. Please set Pattern program [Disable]. Or,
set up Jig and select [Jig] on the unit replace screen.
070102 Data matching
Backup Jig to support vacuum of [Pattern program/PCB positioning/PCB
positioning sequence] is set [Disable]. Please set Pattern program [Enable]. Or,
take off Jig and select [None] on the unit replace screen.
070103 Data matching Input machine differs from Crnt. PP. Please match the Crnt. PP.
070104 Data matching
Failed to consistency check of input machine. Please checking LAN
connection.
070105 Data matching
Output machine differs from Crnt. PP. Please match the Crnt. PP of the Output
machine. Please set P.C.B. counter of the Output machine.
0d0a01 Nozzle position Nozzle is fallen. Please perform the all zeroing.
0d0b01
Conrmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove or x it.
0d0b02
Conrmation of press
missing Cmpnt
Open the safety cover, then check the cmpnt on PCB. Please remove it.
0d0c01
Pickup miss comp,
Disengaged Latch
Check
Please open the safety door and conrm whether pickup miss comp is dropped
or no disengaged Latch is exist. If the comp is dropped, there is a possibility of
interference with Head. A detection state can be checked on a control screen.
0d0d01 Conrm bending Noz Open the safety door, and then conrm whether Noz placed in head is bent.
0d0e01
Zeroing of Cutter is not
completed
Perform All zeroing
0d0f01 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head1).
Please remove the cmpnt, and turn off the Valve.
0d0f02 Height Teaching
Cmpnt is picked-up, or there is a nozzle which has turned on the Valve (Head2).
Please remove the cmpnt, and turn off the Valve.
0d0f03 Height Teaching Tray’s Pallet is not pulled out (Block1). Please pull it out.
0d0f04 Height Teaching Tray’s Pallet is not pulled out (Block2). Please pull it out.
0d0f05 Height Teaching
Cannot teach Stocker Master height of the third and forth line for Stocker 2 of
One side Machine.
0d0f06 Height Teaching
There is no place for Glass Jig in the Head, so that could not teach the height
of Glass Jig.
0d1001 Stop Command Interlock is detected. Please retry to execute after removing the factor.
0d1101
Flux dispensing unit
squeegee error detect
Please put down squeegee not to separate from ux dispensing unit.
0d1201
Flux dispensing unit
motor warning detect
Please take out/in ux dispensing and then restart to run.
0d1301
Uninstalled Flux
dispensing unit
Please set ux dispensing unit to use in pattern program data.
0d1401 Head type error Please restart it after setting the head type properly.
0d1501 Keep large nozzle
Please remove the large nozzle on the head1 by hand. Please retry to operate
it after editing nozzle arrangement data
0d1502 Keep large nozzle
Please remove the large nozzle on the head2 by hand. Please retry to operate
it after editing nozzle arrangement data
0d1601
Large nozzle
interference
The large nozzle is set positioning in the interfering position. Please set
positioning in the not interfering position, or perform all zeroing.
0d1602
Large nozzle
interference
Operation is impossible because large nozzles are placed in 2 axes adjacent
to the head1. Please take off one of them by hand, and then edit the nozzle
arrangement data.
DEUKYX
2-20193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
0d1603
Large nozzle
interference
Operation is impossible because large nozzles are placed in 2 axes adjacent
to the head2. Please take off one of them by hand, and then edit the nozzle
arrangement data.
0d1604
Large nozzle
interference
It cannot run because a large nozzle runs to the interfering position.
0d1701
Non-applied function of
the long board
The function is not applied to PCB which is longer than 610 mm.
0d1801 Transfer conrmation The machine has not stopped.
0d1901 Bowl Feeder
Bowl feeder cart (Block1) has not been set. Please check a type of the cart.
And, Please check the setting for unit exchange screen.
0d1902 Bowl Feeder
Bowl feeder cart (Block2) has not been set. Please check a type of cart. And,
Please check the setting for unit exchange screen.
0d2001
Non-applied function of
backup jig support to
vacuum
The function is not available if backup jig to support vacuum is applied.
0d2101
Independent /
alternation production
mode
The alternation production mode cannot run during an independent production
mode run. Please start again after stopping a machine.
0d2102
Independent /
alternation production
mode
By the state of the PCB in the machine, I do not come in a startup. Please start
again after I remove a PCB, or stopping it.
0d2201 Selection at any time
Please push the abandonment button of the control screen and specify the
place where parts are abandoned. (head1) The parts which have set up “at-
any-time selection” or “after-interlock recovery” are adsorbed states.
0d2202 Selection at any time
Please push the abandonment button of the control screen and specify the
place where parts are abandoned. (head2) The parts which have set up “at-
any-time selection” or “after-interlock recovery” are adsorbed states.
0d2301
Conveyor safety sensor
detection
The conveyor safety sensor (input side) is detected.
0d2302
Conveyor safety sensor
detection
The conveyor safety sensor (output side) is detected.
0d2401
Feeder safety sensor
detection (Block1)
The feeder safety sensor (Block1) is detected.
0d2402
Feeder safety sensor
detection (Block2)
The feeder safety sensor (Block2) is detected.
0d3001
PCB position
restoration check
Please open a safety door and return PCB to the specied position of recovery
guidance. If operations are resumed without returning PCB to the specied
position, it may discharge by un-mounting.
0d3101
Component storage
box without emission
(Block1) Component storage boxes are not detected. Please install component
storage boxes.
0d3102
Component storage
box without emission
(Block2) Component storage boxes are not detected. Please install component
storage boxes.
0d3201
Feeder Base Up/Down
Operation Restrictions
(Block1)
In order to make a feeder base go up and down, please remove the stock stick
unit on a base.
0d3202
Feeder Base Up/Down
Operation Restrictions
(Block1)
Please check that the stock stick unit is not carried on a feeder base, and
perform UP/DOWN operation of a base again.
0d3203
Feeder Base Up/Down
Operation Restrictions
(Block1)
Please set “a feeder connection check / feeder serial communication” of test
operation as “Disable” for a unit check.
DEUKYX
2-21193-4110
2.2 Management-Informationsliste
Code Anzeigebereich A Anzeigebereich B
0d3204
Feeder Base Up/Down
Operation Restrictions
(Block1)
Please check that Recycle Conveyor is not carried on a feeder base, and
perform UP operation of a base again.
0d3301
Feeder Base Up/Down
Operation Restrictions
(Block2)
In order to make a feeder base go up and down, please remove the stock stick
unit on a base.
0d3302
Feeder Base Up/Down
Operation Restrictions
(Block2)
Please check that the stock stick unit is not carried on a feeder base, and
perform UP/DOWN operation of a base again.
0d3303
Feeder Base Up/Down
Operation Restrictions
(Block2)
Please set “a feeder connection check / feeder serial communication” of test
operation as “Disable” for a unit check.
0d3304
Feeder Base Up/Down
Operation Restrictions
(Block2)
Please check that Recycle Conveyor is not carried on a feeder base, and
perform UP operation of a base again.
0d3401
And without substrate
transfer step without
mounting
Because there is no step installed, that does not provide a substrate transfer,
can not operate.
Simple or cancel the skip, please go to the substrate transfer.
0d3501
High Speed Head ux
coating impossible
Because you do not want to use the side view camera, can not high speed dip.
Verify the following settings, please change.
System setting : Side view camera : Use
Test run :No parts : Detected
0d3601
The appointed external
communication
Please clear the P-OUT mode.
0d3701 VM Data Error Abnormalities occurred in data expansion. Please inspect with a tester again.
0d3801
The cart for
independent production
(Block1) Test operation When you do not carry out a feeder connection check,
please raise the feeder base which carries out production use.
0d3802
The cart for
independent production
(Block2) Test operation When you do not carry out a feeder connection check,
please raise the feeder base which carries out production use.
0d3901
Unit exchange of Tray
Feeder
Please restart.
0d3a01 Comp. existence check Please turn off the Valve.
0d3b01 Check for a function The nozzle is not applicable to this operation.
0d3901
Uninstalled Brush Unit
(Block1)
Please put a brush unit on F107-F153.
0d3902
Uninstalled Brush Unit
(Block1)
Please put a brush unit on F107-F119.
0d3903
Uninstalled Brush Unit
(Block1)
Please put a brush unit on F107.
0d3904
Uninstalled Brush Unit
(Block2)
Please put a brush unit on F207-F253.
0d3905
Uninstalled Brush Unit
(Block2)
Please put a brush unit on F207-F219.
0d3906
Uninstalled Brush Unit
(Block2)
Please put a brush unit on F207.
0d3c01 Pin Recog Light (head1) The high speed head cannot move to the pin recog light.
0d3c02 Pin Recog Light (head2) The high speed head cannot move to the pin recog light.
0d3c03 Pin Recog Light (head1) The comp size is over the pin recog light spec.
0d3c04 Pin Recog Light (head2) The comp size is over the pin recog light spec.
