DEUKYX 2-31 193-41 10 3.2 Maschinen-Informationsliste Fehler-Code (HEX) Anzeigebereich A Anzeigebereich B 80c505 Overall Setup (Exchange support pin) Support pins is not inserted correctly . Check the insertion of suppor…
DEUKYX
2-30193-4110
3.2 Maschinen-Informationsliste
Fehler-Code
(HEX)
Anzeigebereich A Anzeigebereich B
80c004 Tray turning on
Failed in turning on Driver power of Tray (Block2) Magazine2 (Upper).
Please conrm the wiring of Machine
80c101
Tray ACV miss-
placement error (Step)
Error of miss-placement : Tray (Block1) Magazine1 (Lower)
80c102
Tray ACV miss-
placement error (Step)
Error of miss-placement : Tray (Block1) Magazine2 (Upper)
80c103
Tray ACV miss-
placement error (Step)
Error of miss-placement : Tray (Block2) Magazine1 (Lower)
80c104
Tray ACV miss-
placement error (Step)
Error of miss-placement : Tray (Block2) Magazine2 (Upper)
80c201
Tray ACV miss-
placement error
(Magazine)
Tray (Block1) Magazine1 (Lower) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
80c202
Tray ACV miss-
placement error
(Magazine)
Tray (Block1) Magazine2 (Upper) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
80c203
Tray ACV miss-
placement error
(Magazine)
Tray (Block2) Magazine1 (Lower) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
80c204
Tray ACV miss-
placement error
(Magazine)
Tray (Block2) Magazine2 (Upper) Cannot use it in AUTO OPN MODE
(PLACEMENT) because of miss-placement.
80c301
Tray Safety Cover
Lock cleared (Auto
Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray (Block1)
Magazine1 (Lower).
80c302
Tray Safety Cover
Lock cleared (Auto
Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray (Block1)
Magazine2 (Upper).
80c303
Tray Safety Cover
Lock cleared (Auto
Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray (Block2)
Magazine1 (Lower).
80c304
Tray Safety Cover
Lock cleared (Auto
Run)
Cannot clear Lock because Cmpnt shortage is not found on Tray (Block2)
Magazine2 (Upper).
80c401 Nozzle Exchange
There is no nozzle required for production. Please check the following.
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
80c402 Nozzle Exchange
A nozzle cannot be stored. Please check the following.
1. Existence of Nozzle Stocker, Clamp Condition
2. Nozzle Conguration Data
80c403 Nozzle Exchange ODD Noz of Head is stored for storing high-speed Noz.
80c404 Nozzle Exchange Noz is stored due to error in teaching Noz Position.
80c405 Nozzle Exchange Please take down the nozzle stocker.
80c406 Nozzle Exchange
A necessary nozzle is installed in the head that has not been selected.
Please select the back and forth block, and execute the nozzle exchange.
80c501
Overall Setup
(Exchange support pin)
Pattern Program data set the support pin as [No exchange], so that skipped it.
80c502
Overall Setup
(Exchange support pin)
Noz is not for Support Pin Exchange, so that it is stored.
80c503
Overall Setup
(Exchange support pin)
There is no available nozzle for backup pin exchange. In the case of a multi
function head, please set a nozzle to No.1 - No.7 of the stocker.
80c504
Overall Setup
(Exchange support
pin)
Conveyor Width is stopped at the position for exchanging support pins
because the Support pins of Lane A are stored. Please take out Support
pins from machine, or install Conveyor Width after setting them at production
position.
DEUKYX
2-31193-4110
3.2 Maschinen-Informationsliste
Fehler-Code
(HEX)
Anzeigebereich A Anzeigebereich B
80c505
Overall Setup
(Exchange support pin)
Support pins is not inserted correctly. Check the insertion of support pins at
"Setup"-"Sprt-Pins"-"Sup.Pins Insert Check", please insert normally.
80c601
Overall Setup
(Conveyor width setup)
Pattern Program data set the conveyor width as [No Setup]. So that skipped
it.
80c701
Nozzle Level Offset
Teaching
All E/NR from side view camera sensor is detected. Please conrm it
because there is a possibility that ODD Noz is placed.
80c702
Nozzle Level Offset
Teaching
Could not do Teaching because Noz for measurement on Head1 is not set.
80c703
Nozzle Level Offset
Teaching
Could not do Teaching because Noz for measurement on Head2 is not set.
80c704
Nozzle Level Offset
Teaching
The Length of measured Noz is out of Allowable Range. Please conrm the
Noz of Head.
80c801 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 1st)
80c802 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 1st)
80c803 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 2nd)
80c804 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 2nd)
80c805 Cutter Auto Reset Cutter Auto Reset of Device (Block1) is executed. (The 3rd)
80c806 Cutter Auto Reset Cutter Auto Reset of Device (Block2) is executed. (The 3rd)
80c901
Recycling Conveyor
(Block1)
Recycling Conveyor (Block1) is on ready. Please remove parts and resume
production after completion of operation.
80ca01
Recycling Conveyor
(Block2)
Recycling Conveyor (Block2) is on ready. Please remove parts and resume
production after completion of operation.
80cb01
Undetermined Tray
Comp. (Block1)
An undetermined component is detected.
80cc01
Undetermined Tray
Comp. (Block2)
An undetermined component is detected.
80d001
Counter Board
synchronization gap
detection (Head1)
The synchronization gap of Counter Board was detected (X-axis).
80d002
Counter Board
synchronization gap
detection (Head1)
The synchronization gap of Counter Board was detected (Y-axis).
80d101
Counter Board
synchronization gap
detection (Head2)
The synchronization gap of Counter Board was detected (X-axis).
80d102
Counter Board
synchronization gap
detection (Head2)
The synchronization gap of Counter Board was detected (Y-axis).
80d201
Side view camera
synchronization gap
detection (Head1)
The synchronization gap of Side view camera was detected. Please conrm
the connector of the encoder cable.
80d301
Side view camera
synchronization gap
detection (Head2)
The synchronization gap of Side view camera was detected. Please conrm
the connector of the encoder cable.
80e001
Noz Selection
axis position offset
teaching
The 1st Re-trial for Noz Selection axis position offset teaching started.
80e002
Noz Selection
axis position offset
teaching
The 2nd Re-trial for Noz Selection axis position offset teaching started.
80f001 Auto Opn.Mode Start Auto Opn.Mode.
DEUKYX
2-32193-4110
3.2 Maschinen-Informationsliste
Fehler-Code
(HEX)
Anzeigebereich A Anzeigebereich B
80f002 Auto Opn.Mode Stop Auto Opn.Mode.
80f003 Auto Opn.Mode Stop Auto Opn.Mode. (Error stop)
80f101 ACV Registration Comp.Reld. execution.
80f102 ACV Registration Splicing execution.
80f201 Auto Cover Locked
The safety door is locked for pass running. Please stop the machine and
move the head if there is a head on the conveyor. There is an interference
with PCB if a head is on the conveyor.
80f202 Auto Cover Locked
Connector (Block1) of Feeder Base is taken off. Do not take it off when
Feeder Base is rising up. Please go on if it’s on operating.
80f203 Auto Cover Locked
Connector (Block2) of Feeder Base is taken off. Do not take it off when
Feeder Base is rising up. Please go on if it’s on operating.
80f204 Auto Cover Locked
Manual Movement and Load. This operation will be done while [START]
button is pushed. Please push the button continuously before PCB moves to
the proposal position.
80f301 Barcode Detection The bar code data is not read. Bar code ID is generated automatically.
80f302 Barcode Detection Illegal bar code ID. Bar code ID is generated automatically.
80f401
FF func. for Print Pos
Correction
Standard PCB Mounting will be executed without Print Pos. Correction
because the standard of Device’s Coordinates for PP data in Printer differs
from it in Mounter.
80f402
FF func. for Print Pos
Correction
Standard PCB Mounting will be executed without Print Pos. Correction
because Global Recognition of PP Data does not have 2 points.
80f403
FF func. for Print Pos
Correction
Standard PCB Mounting will be executed without Print Pos. Correction
because Unit PCB Recog or Local PCB Recog of PP Data is being used.
80f404
FF func. for Print Pos
Correction
Standard PCB Mounting will be executed without Print Pos. Correction
because could not receive Print Pos. Correction values normally.
80f405
FF func. for Print Pos
Correction
Standard PCB Mounting will be executed without Print Pos. Correction
because of time-out of receiving Print Pos. Correction values.
80f501
Auto Cover Locked
Start
After Auto Cover Locked, it is stopped because NG Items are found by Free
Check before product opreation. Please conrm the guide for start-up.
80f601 Feeder Base Connector for Feeder Cart is not connected.
80f602 Feeder Base Not turned Feeder Cart on yet.
80f603 Feeder Base Communicating with Feeder.
80f701
Library Tape feeding
High-speed
It is necessary to take out and in a feeder if tape high-speed feeding is set
enable.
80f801
Unit PCB recognition
data transfer func.
There is a possibility that the operation changed to PCB recog. manual
alignment during data processing, or PCB which is being data processing is
taken off. Please change the same current program in the head mounter (Unit
1). Or, set unit PCB recog. data communication of operation mode [Disable]
for a moment, and then set [Enable] in the head mounter (Unit 1).
80f901 Nozzle auto. Replace Nozzle is replaced automatically because of a lowering of pick-up rate.
80f902 Nozzle auto. Replace
Pick-up rate of nozzle went down, and nozzle was replaced automatically.
But nozzle position teaching failed.
80f903 Nozzle auto. Replace
Pick-up rate of nozzle went down, but it is interrupted to replace nozzle
automatically.
80f904 Nozzle auto. Replace
Pick-up rate of nozzle went down. It planned to replace nozzle automatically,
but there was no place to store it.
80f905 Nozzle auto. Replace
Pick-up rate of nozzle went down. It planned to replace nozzle automatically,
but there was no spare nozzle.
