DEUKYX
3-57193-4110
3.4 Tray-Feeder (Block1)
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
431102 Tray Pallet Returning Error (Block1)
Elevator movement position error
-----
431103 Tray Pallet Returning Error (Block1)
Elevator wave form setting error
-----
431104 Tray Pallet Returning Error (Block1)
Elevator operating error
-----
431201 Tray Pallet Returning Error (Block1)
Traverse pre-check error
-----
431202 Tray Pallet Returning Error (Block1)
Traverse movement position error
-----
431203 Tray Pallet Returning Error (Block1)
Traverse wave form setting error
-----
431204 Tray Pallet Returning Error (Block1)
Traverse operating error
-----
431206 Tray Pallet Returning Error (Block1)
No palette when the return begins.(B15411)
-----
431301 Tray Pallet Draw out Error (Block1)
Elevator pre-check error
-----
431302 Tray Pallet Draw out Error (Block1)
Elevator movement position error
-----
431303 Tray Pallet Draw out Error (Block1)
Elevator wave form setting error
-----
431304 Tray Pallet Draw out Error (Block1)
Elevator operating error
-----
431305 Tray Pallet Draw out Error (Block1)
Elevator abnormal stop
-----
431401 Tray Pallet Draw out Error (Block1)
Traverse pre-check error
-----
431402 Tray Pallet Draw out Error (Block1)
Traverse movement position error
-----
DEUKYX
3-58193-4110
3.4 Tray-Feeder (Block1)
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
431403 Tray Pallet Draw out Error (Block1)
Traverse wave form setting error
-----
431404 Tray Pallet Draw out Error (Block1)
Traverse operating error
-----
431405 Tray Pallet Draw out Error (Block1)
Traverse operating error
-----
431406 Tray Pallet Draw out Error (Block1)
No palette when drawing out begins.(B15411)
-----
431407 Tray Pallet Draw out Error (Block1)
Cannot detect the pallet to draw out(B15505, B15506)
Prüfen Sie, ob die Palette im Magazin richtig eingerichtet ist. Wenn dies der Fall
ist, prüfen Sie den Sensor.
431501 Move to Tray Elevator supply/exchange position error (Block1)
Elevator pre-check error
-----
431502 Move to Tray Elevator supply/exchange position error (Block1)
Elevator movement position error
-----
431504 Move to Tray Elevator supply/exchange position error (Block1)
Elevator operating error
-----
431602 Tray Feeder Zeroing Error (Block1)
Tray feeder zeroing Servo ON error
-----
431603 Tray Feeder Zeroing Error (Block1)
Traverse pallet search error
-----
431604 Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
431605 Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
431606 Tray Feeder Zeroing Error (Block1)
The palette was detected though there was no draw out history.
Öffnen Sie die Abdeckung und entnehmen Sie die Palette.
431607 Tray Feeder Zeroing Error (Block1)
Elevator return steps movement error
-----
DEUKYX
3-59193-4110
3.4 Tray-Feeder (Block1)
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
431608 Tray Feeder Zeroing Error (Block1)
Traverse pallet store error
-----
431609 Tray Feeder Zeroing Error (Block1)
Elevator zeroing pre-check error
-----
43160a Tray Feeder Zeroing Error (Block1)
Pallet chuck close error
-----
43160b Tray Feeder Zeroing Error (Block1)
Rack shutter CLOSE error
-----
43160c Tray Feeder Zeroing Error (Block1)
Elevator zeroing error
-----
43160d Tray Feeder Zeroing Error (Block1)
EV1 step logs and step movement error
-----
43160e Tray Feeder Zeroing Error (Block1)
Ev2 step logs and step movement error
-----
43160f Tray Feeder Zeroing Error (Block1)
Traverse zeroing error
-----
431610 Tray Feeder Zeroing Error (Block1)
Traverse zeroing pre-check error
-----
431611 Tray Feeder Zeroing Error (Block1)
Pallet chuck CLOSE error
-----
431613 Tray Feeder Zeroing Error (Block1)
Pallet chuck OPEN error
-----
431614 Tray Feeder Zeroing Error (Block1)
Traverse recede operation error
-----
431615 Tray Feeder Zeroing Error (Block1)
The palette was not detected though there was a draw out history.
-----
431616 Tray Feeder Zeroing Error (Block1)
Rack shutter OPEN error(Upper Magazine)
-----
431617 Tray Feeder Zeroing Error (Block1)
Rack shutter OPEN error(Lower Magazine)
-----
