DEUKYX
3-109193-4110
3.10 Andere Fehler
3.10 Andere Fehler
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
4b0201 Feeder communication Error.
Communication with the feeder has an error.
Prüfen Sie die Anzahl der verbleibenden Bauteile.
4b0204 Feeder communication Error.
Communication with feeder was not completed within predetermined time. (Please
take out and insert feeder.)
-----
4b0205 Feeder communication Error.
Failed in processing information read.
Fahren Sie den Wagen herunter oder ziehen Sie den Feeder und stecken ihn
danach wieder ein.
4b0206 Feeder communication Error.
Failed in Program-changed.
Fahren Sie den Wagen herunter oder ziehen Sie den Feeder und stecken ihn
danach wieder ein.
4b0207 Feeder communication Error.
Failed in Splicing survey setup.
Fahren Sie den Wagen herunter oder ziehen Sie den Feeder und stecken ihn
danach wieder ein.
4b0208 Feeder communication Error.
Cannot send it because of Error of Serial Communication process.
Fahren Sie den Wagen herunter oder ziehen Sie den Feeder und stecken ihn
danach wieder ein.
4b0209 Feeder communication Error.
-----
Ziehen Sie den Feeder und stecken Sie ihn wieder ein.
4b0302 Feeder-Basis
The feeder unclamp operation was not completed within predetermined time.
-----
4b0304 Feeder-Basis
The feeder clamp operation was not completed within predetermined time.
-----
4b0305 Feeder-Basis
The feeder base ascent operation was not completed within predetermined time.
Prüfen Sie die Obere Endposition der Feeder-Basis [B0614][B0914].
4b0306 Feeder-Basis
The feeder base descent operation was not completed within predetermined time.
Prüfen Sie die untere Endposition der Feeder-Basis.
4b0307 Feeder-Basis
The connector (Block1) for the feeder base worked off. Do not remove the
connector during feeder base ascent.[B0916]
Verbinden Sie den Anschluss (Block1) der Feeder-Basis mit der Maschine.
4b0308 Feeder-Basis
The connector (Block2) for the feeder base worked off. Do not remove the
connector during feeder base ascent.[B0916]
Verbinden Sie den Anschluss (Block2) der Feeder-Basis mit der Maschine.
DEUKYX
3-110193-4110
3.10 Andere Fehler
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
4b0310 Feeder-Basis
The power was not turned on, or emergency stop was detected.
Prüfen Sie, dass der Not-Aus-Schalter nicht gedrückt ist und schalten Sie die
Maschine ein.
4b0311 Feeder-Basis
Feeder Cart could not be detected.
Setzen Sie den Feeder-Wagen an den vorgesehenen Platz und versuchen Sie es
erneut. Wenn er sich bereits dort bendet, prüfen Sie, ob er guten Kontakt hat.
4b0312 Feeder-Basis
Connector of Feeder Cart is not connected
Starten Sie neu, nachdem Sie die Feeder-Wagen angeschlossen haben.
4b0313 Feeder-Basis
NL-axis interlock was detected
Fahren Sie die NL-Achse in die Nullposition.
4b0314 Feeder-Basis
Error in Feeder Base movement
----
4b0315 Feeder-Basis
Time-out in Clamp Movement of Elevator Unit
----
4b0316 Feeder-Basis
Time-out in Unclamp Movement of Elevator Unit
----
4b0317 Feeder-Basis
Illegal current position of Feeder base (Block1)
Prüfen Sie die Feeder-Basis und die Sensoren für den oberen Zylindergranzwert
[B0614] und für dn unteren Zylindergrenzwert[B0615].
4b0318 Feeder-Basis
Illegal current position of Feeder base (Block2)
Prüfen Sie die Feeder-Basis und die Sensoren für den oberen
Zylindergranzwert[B0614] und für dn unteren Zylindergrenzwert[B0615].
4b0319 Feeder-Basis
Positioning dropping prevention stopper (Block1) cannot cancel lock.
Prüfen Sie die Feeder-Basis und den Sensor für die Positionsverriegelung [B0912]
[B0913].
4b031A Feeder-Basis
Positioning dropping prevention stopper (Block2) cannot cancel lock.
Prüfen Sie die Feeder-Basis und den Sensor für die Positionsverriegelung [B0612]
[B0613]
4b031B Feeder-Basis
Positioning dropping prevention stopper (Block1) cannot lock.
Prüfen Sie die Feeder-Basis und den Sensor für die Positionsverriegelung [B0912]
[B0913].
DEUKYX
3-111193-4110
3.10 Andere Fehler
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
4b031C Feeder-Basis
Positioning dropping prevention stopper (Block2) cannot lock.
Prüfen Sie die Feeder-Basis und den Sensor für die Positionsverriegelung [B0612]
[B0613]
4b031D Feeder-Basis
Cart rising stopped (Block1).
Cannot release the safety cover for the cart in the opposite side is in process.
The process stopped because there is a possibility that something is placed
between Cart and the safety cover.
-----
4b031E Feeder-Basis
Cart rising stopped (Block2).
Cannot release the safety cover for the cart in the opposite side is in process.
The process is stopped because there is a possibility that something is placed
between Cart and the safety cover.
-----
4b031F Feeder-Basis
Failed that Automatic safety cover opening starts up. The process is stopped
because there is a possibility that something is placed between Cart and the
safety cover.
-----
4b0320 Feeder-Basis
Automatic safety cover opening is not completed in predetermined time. The
process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0321 Feeder-Basis
Failed in Automatic safety cover opening (Release Lock).
The process is stopped because there is a possibility that something is placed
between cart and the safety cover.
-----
4b0322 Feeder-Basis
Cannot distinguish a cart (Block1). Please operate it again.
-----
4b0323 Feeder-Basis
Cannot distinguish a cart (Block2). Please operate it again.
-----
4b0501 Manual alignment Error
Operation was not completed within predetermined time.
-----
4b050f Manual alignment Error
Error was detected during operation.
-----
