DEUKYX
3-135193-4110
3.13 Autom. Teaching
3.13 Autom. Teaching
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
600101 P.C.B. recog camera & beam offset teach.
-----
-----
600102 P.C.B. recog camera & beam offset teach.
Error of Recognition Command response.
-----
600103 P.C.B. recog camera & beam offset teach.
Error of coordinates calculation.
-----
600104 P.C.B. recog camera & beam offset teach.
Error of Data set for XY Beam.
-----
600105 P.C.B. recog camera & beam offset teach.
Error of moving for XY Beam.
-----
600106 P.C.B. recog camera & beam offset teach.
Time-out in XY Beam
-----
600107 P.C.B. recog camera & beam offset teach.
Time-out of communication with recognition.
-----
600108 P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on parts recognition camera.
-----
600109 P.C.B. recog camera & beam offset teach.
Recognition failure of checker on reference pin.
-----
60010a P.C.B. recog camera & beam offset teach.
Recognition failure of checker mark on glass jig.
-----
600201 Comp. Recog. Camera offset teach.
Could not recognize the glass Jig.
Prüfen Sie, ob sich der Glasrahmen an der richtigen Position bendet (Es besteht
die Möglichkeit, dass sich der Aufnehmer nicht im Kopf bendet oder kein Vakuum
anliegt.)
600202 Comp. Recog. Camera offset teach.
The result of Teaching is out of permission values.
Prüfen Sie, ob die Aufnahme korrekt erfolgte. Ist dies nicht der Fall, teachen Sie
den Offset neu.
600203 Comp. Recog. Camera offset teach.
Error of Recognition command response.
-----
600204 Comp. Recog. Camera offset teach.
Error of coordinates calculation.
-----
DEUKYX
3-136193-4110
3.13 Autom. Teaching
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
600205 Comp. Recog. Camera offset teach.
Error when Jig pickup started
-----
600206 Comp. Recog. Camera offset teach.
Error in the movement of Jig pickup
-----
600207 Comp. Recog. Camera offset teach.
Error when Jig began to be stored
-----
600208 Comp. Recog. Camera offset teach.
Error in the movement of Jig stored
-----
600209 Comp. Recog. Camera offset teach.
Error when HL-axis began to drop.
-----
60.020a Comp. Recog. Camera offset teach.
Error when HL-axis began to rise.
-----
60020b Comp. Recog. Camera offset teach.
Error of Data set for XY Beam.
-----
60020c Comp. Recog. Camera offset teach.
Error of moving for XY Beam.
-----
60020d Comp. Recog. Camera offset teach.
Time-out of moving for XY Beam.
-----
60020e Comp. Recog. Camera offset teach.
Time-out of communication with recognition.
-----
600301 Head Rotate Theta Axis offset
Could not recognize Nozzle
Prüfen Sie, ob der Aufnehmer korrekt eingesetzt ist und die Anordnungsdaten der
Aufnehmer korrekt sind.
600302 Head Rotate Theta Axis offset
Error of Recognition Command response.
-----
600303 Head Rotate Theta Axis offset
Could not recognize the section of nozzle shaft
-----
600304 Head Rotate Theta Axis offset
Error of coordinates calculation.
-----
600305 Head Rotate Theta Axis offset
Error when DD-axis began to rotate.
-----
DEUKYX
3-137193-4110
3.13 Autom. Teaching
Error ID Fehlername, Beschreibung, Ursache und Wiederherstellung
600306 Head Rotate Theta Axis offset
Error during rotation of DD-axis
-----
600307 Head Rotate Theta Axis offset
Error when HL-axis and NL-axis began zeroing
-----
600308 Head Rotate Theta Axis offset
Error while HL-axis and NL-axis on zeroing movement
-----
600309 Head Rotate Theta Axis offset
Error of Data set for XY Beam.
-----
60030a Head Rotate Theta Axis offset
Error of moving for XY Beam.
-----
60030b Head Rotate Theta Axis offset
Time-out in XY Beam movement
-----
60030c Head Rotate Theta Axis offset
Time-out of communication with recognition.
-----
60030d Head Rotate Theta Axis offset
Error when L-axis began zeroing
-----
60030e Head Rotate Theta Axis offset
Error of L-axis on zeroing
-----
60030f Head Rotate Theta Axis offset
Error when L-axis began to drop
-----
600310 Head Rotate Theta Axis offset
Error in L-axis dropped
-----
600311 Head Rotate Theta Axis offset
Time-out of the movement of L-axis, Z-axis
-----
600312 Head Rotate Theta Axis offset
Error when Z-axis began to move
-----
600313 Head Rotate Theta Axis offset
Error while Z-axis is moving
-----
600314 Head Rotate Theta Axis offset
Error in Head rotate Theta axis Offset.
-----
