ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
18
Error types 2-5 are sent from stations with station software as of version 605.
Error types 11-16 are sent from stations with station software as of version 701.
The track number may contain the value -1. This indicates that the track is unknown and
Definition of lGantry and ucHead
With introduction of the lGantry column, the semantic of the ucHead column has changed. The
content of ucHead column has moved into the lGantry column.
The ucHead now relates to the head position where the head is mounted on the gantry.
I.e., a gantry may carry one or two heads. For gantries with only one head, the head value is
always "1". For gantries, which are able to carry two heads, the following definition of ucHead is
used:
Definition of ucHead values
1: head is located on the right position of the gantry
2: head is located on the left position of the gantry
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
19
4.5.1.7 USEDCOMPONENTS Table
USEDCOMPONENTS OIS name Data
type
Byte CI I P
Identification number of the station
(reference to STATION table)
lId int 4
Date/time at which the data record was created.
Station time
dtTime datetime 8
Serial number of manufactured PCB lBoardNumber int 4
Number of attempts to access this track sAccessTotal smallint 2
Number of rejected parts because of ident error sRejectIdent smallint 2
Number of TrackEmpty pickup attempts sTrackEmpty smallint 2
Table/location from which the component was retrieved ucTable tinyint 1
Track number sTrack smallint 2
Tower (MTC only, otherwise dummy) ucTower tinyint 1
Level (WPC or MTC only, otherwise dummy)
sLevel smallint 2
Division sReceptacle smallint 2
Number of rejected parts because of vacuum error sRejectVacuum smallint 2
Time when the data is written. Server Time dtCreated datetime 8
Identification number of the component name (available
with station software version 701 and higher)
lPartNumber int 4
Identification number of the component shape name
(available with station software version 701 and higher)
lComponentShape int 4
SIPLACE Pro number for feeder type (available with
station software version 701 and higher
lFeederType long 4
Number of successfully placed components on this
track
sPlacedComponents smallint 2
4.5.1.8 PARTNUMBER Table
PARTNUMBER OIS name Data type Byte CI I P
Identification number of the component name lPartNumber int 4
Name of the component, including path strPartNumber nvarchar(128) 256
Time when the data is written. Server Time dtCreated datetime 8
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
20
4.5.1.9 COMPONENTSHAPE Table
COMPONENTSHAPE OIS name Data type Byte CI I P
Identification number of the component shape
name
lComponentShape int 4
Name of the component shape, including path strComponentShape nvarchar(128) 256
Time when the data is written. Server Time dtCreated datetime 8
4.5.1.10 STATION Table
STATION OIS name Data type Byte I P
Name of the line strLine nvarchar(1024) 2048
Name of the station strStation nvarchar(128) 256
Number of placement areas ucProcessingArea tinyint 1
Text for the user strText nvarchar(32) 64
TCP/IP address or computer name of station strComputer nvarchar(255) 510
Identification number of the station lId int 4
Position of the stations within the line lOrder int 4
Machine identification MID strMid nvarchar(50) 100
Is a machine identification available? bMid bit 1
Full path of the line strLineFullPath nvarchar(1024) 2048
Full path of the station strStationFullPath nvarchar(1024) 2046
Station software version as a string strSWVersion nvarchar(128) 256
Station type name as a string. The available
station types are maintained and displayed in
SIPLACE Pro.
strTypeName nvarchar(128) 256
Type of the station (printer or station) Species int 4
Host name of the station strComputerName nvarchar(255) 510
Time when the data is written. Server time dtCreated datetime 8
Definition of Species values
0: Place
1: Print
