ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
21
4.5.1.11 STATE Table
STATE OIS name Data type Byte I P
8 user-defined states (T
1
– T
8
), availability (T
b
) and
the definition "show table states" (T
9
)
strTimeShare nvarchar(32) 64
Name of share of time strName nvarchar(32) 64
Color of share of time lColor int 4
Show share of time bDefined bit 1
4.5.1.12 STATESHARE Table
STATESHARE OIS name Data type Byte I P
8 user-defined states (T
1
– T
8
), availability (T
b
) and
the definition "show table states" (T
9
)
strTimeShare nvarchar(32) 64
Machine state, individual states of the state
machine
lState int 4
Share of time lPercent int 4
4.5.1.13 DATAMODEL Table
DATAMODEL OIS name Data type Byte I P
Name of the entry strName nvarchar(32) 64
Value 1 of data type int lLong int 4
Value 2 of data type string strString nvarchar(255) 510
Value 3 of data type datetime dtTime datetime 8
Value 4 of data type double e dDouble float 8
4.5.1.14 SHIFTWORK Table
SHIFTWORK OIS name Data type Byte I P
Name of shift strName nvarchar(32) 64
Starting time of shift dtStart datetime 8
4.5.1.15 EVENTTEXT Table
EVENTTEXT OIS name Data type Byte I P
Event number sEvent smallint 2
Event name strName nvarchar(32) 64
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
22
4.5.1.16 STATETRANSITION Table
STATETRANSITION OIS name Data type Byte CI I P
Identification number of the station
(reference to STATION table)
lId int 4
Conveyor belt 1 / 2 ucConveyor tinyint 1
Processing area 1 / 2 ucProcessingArea tinyint 1
State based on events sState smallint 2
Date/time at which this event occurred.
Station time
dtTime datetime 8
Time when the data is written. Server time dtCreated datetime 8
Event number sEvent smallint 2
Processing mode usProcessingMode tinyint 1
Sequence ID (internal use) lIdSequence int 4
State history (internal use) IHistory int 4
Definition of ucConveyor
The current implementation is processing area specific, i.e. one state machine is available for each
processing area. Future improvements may use a state machine for each processing area and
each conveyor. As long as this improvement is not implemented, the ucConveyor is always set to
"0".
Definition of ucProcessingMode
The ucProcessingMode indicates whether the "Alternating" or "I-Placement" mode was used to
process the board.
Possible values of ucProcessingMode:
0: Undefined
1: Alternating mode
2: I-Placement mode
Definition of sState values
The following table contains the state definitions as well as a short description of the state
semantics.
State Value Description
STATE_PCB_BEGIN
1
Production has been started (Conveyor 1)
STATE_PCB_BEGIN2
31
Production has been started (Conveyor 2)
STATE_PCB_END
2
Production has been ended (Conveyor 1)
STATE_PCB_END2
32
Production has been ended (Conveyor 2)
STATE_BREAK_BEGIN
3
Machine reported break mode s
STATE_EMERGENCY_STOP
4
Emergency stop has been
pressed
STATE_AIR
5
Not enough air
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
23
STATE_STOP
6
Machine has been stopped
STATE_WAIT_PCB_IN
9
PCB is waiting in input conveyor
STATE_WAIT_PCB_INSIDE
10
PCB is waiting in center conveyor
STATE_WAIT_PCB_OUT
11
PCB is waiting in output conveyor
STATE_WAIT_DATA
12
Machine is waiting for data
STATE_FIDUCIAL_ERROR
14
A fiducial error has been reported from the station
STATE_TRACK_ERROR
15
A track error has been reported from the station
STATE_MACHINE_ERROR
16
A fatal machine error occurred
STATE_TRANSPORT_ERROR
17
A transport error occurred
STATE_BARCODE_ERROR
18
A barcode error has been reported from the station
STATE_HEAD_STEP
20
Machine entered the head step mode
STATE_KEY_SLOW
21
Machine entered the key slow mode
STATE_VISION
22
Machine entered the Vision mode
STATE_FUNCTION
23
Machine resumed the functional mode
STATE_INIT
24
Machine entered the init normal operation mode
STATE_HOLIDAY
25
Operator entered the works holiday mode
STATE_MAINTENANCE
26
Operator entered the
preventive maintenance mode
STATE_SETUP
27
Operator entered the setup mode
STATE_DOWN_PLAN
28
Operator entered the scheduled downtime mode
STATE_DOWN_ILL
29
Operator entered the unscheduled downtime mode
STATE_PROTOTYPE
30
Operator entered the load
product mode
STATE_STAND_ALONE_BEGIN
49
Stand alone mode has been entered
STATE_STAND_ALONE_END
50
Stand alone mode has been left
STATE_DISPENSING
70
Printer entered the dispensing mode
STATE_KNEADING
71
Printer entered the kneading mode
STATE_PRINTING
72
Printer entered the printing mode
STATE_INSPECTION
73
Printer entered the inspection mode
STATE_CLEANING
74
Printer entered the cleaning mode
