ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition

4.5.1.21 CompBlock Table

CompBlock OIS name Data type Byte CI I P

Identification number of the station

(reference to STATION table)

lId int 4 

Date/time at which the data record was created.

Station time

dtTime datetime 8 

Serial number of manufactured PCB lBoardNumber int 4

Time when the data is written. Server time dtCreated datetime 8 

Reference number of the entry. lIdBlock int 4

Unique number of the BoardComposite lBoardCompositeId int 4

4.5.1.22 CompDetail Table

CompDetail OIS name Data type Byte CI I P

Number of attempts to access this track sAccessTotal smallint 2

Sum of all reject attempts on this track after

Vision error messages

sRejectIdent smallint 2

Sum of all reject attempts on this track after

other error messages

sRejectVacuum smallint 2

Number of rejected parts because of ident error sRejectIdent smallint 2

Number of rejected parts because of vacuum

error

sRejectVacuum smallint 2

Number of TrackEmpty pickup attempts sTrackEmpty smallint 2

Reference into CompBlock table lIdBlock int 2 

Reference into CompPosition table lIdPosition int 2

Number of successfully placed components on

this track

sPlacedComponents smallint 2

Number of reject attempts on this track because

of missing components after pickup

sAbsenceAfterPick smallint 2

Number of pickup attempts on this track

because of missing components before

placement

sAbsenceBefore

Placement

smallint 2

Number of rejects on this track because of

Coplan or material errors reported by Vision

sMaterialDefect smallint 2

Number of rejects on this track because of

erroneous special procedures (dipping, gluing

etc.)

sTreatmentError smallint 2

Number of rejects on this track because of an

interrupted placement process (i.e. canceled

board)

sDroppedError smallint 2

Number of rejects on this track because of

pickup tolerances checked by Vision

sIdentError smallint 2

Number of (incorrect) placement attempts on

this track because of gluey components

sPresenceAfter

Placement

smallint 2

ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition

Number of consecutive pickup attempts that

does not cause an track-empty error.

sPickupRetries smallint 2

Version of the information source for the reject

data

sAttritionInfoVersion smallint 2

Definition of sRejectVacuum

sRejectVacuum = SUM(sAbsenceAfterPick, sComponentAbsenceBeforePlacement,

sTreatmentError, sDroppedError, sComponentAbsenceAfterPlacement,

sPickupRetries)

Definition of sRejectIdent

sRejectIdent = SUM(sComponentMaterialDefect, sIdentError)

Definition of sPlacedComponents values

-1: Undefined for all data records issued by a station with a station software version < 708

0: No successful placement (i. e. pass-through mode, canceled board etc.)

n: n successful placements

Definition of sAttritionInfoVersion values

0: Reject data comes from a station software version < 708

1: Reject data comes from astation software version >= 708

ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition

4.5.1.23 CompPosition Table

CompPosition OIS name Data type Byte CI I P

Identification number of the station

(reference to STATION table)

lId int 4

Reference number of the entry lIdPosition int 4

Table/location from which the component was

retrieved

ucTable tinyint 1

Track number sTrack smallint 2

Tower (MTC only, otherwise dummy) ucTower tinyint 1

Level (WPC or MTC only, otherwise dummy) sLevel smallint 2

Division sReceptacle smallint 2

Identification number of the component name

(available with station software version 701 and

higher)

lPartNumber int 4

Identification number of the component shape

name (available with station software version

701 and higher)

lComponentShape int 4

SIPLACE Pro number for feeder type (available

with station software version 701 and higher)

lFeederType long 4

Time when the data is written. Server time dtCreated datetime 8

Unique feeder ID strFeederId nvarchar(128) 256

4.5.1.24 Panel Table

Panel OIS name Data type Byte CI I P

Reference (from BOARD table).

Note: This reference may occur several times

since a board may have several panel groups.

lIdPanel int 4

Count of produced panels lCountProduced int 4

Count of omitted panels lCountOmitted int 1

Encoding whether the panel entry is intended to

be counted as assembled PCB (based on

SIPLACE Pro setting)

CountAsAssembledPCB tinyint 2

Name of the concerned placement list strPlacementListName nvarchar(256) 512

Definition of CountAsAssembledPCB values

0: Undefined

1: True

2: False
