ASM OIS/SIS Databases 15.1 ( R18 - 1) / Interface De scription 05/2018 Edition 28 4.5.1.23 C ompPosition Table CompPositio n OIS name Data type Byte CI I P Identificati on number of the s tation (reference t o STATION ta…
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
27
Number of consecutive pickup attempts that
does not cause an track-empty error.
sPickupRetries smallint 2
Version of the information source for the reject
data
sAttritionInfoVersion smallint 2
Definition of sRejectVacuum
sRejectVacuum = SUM(sAbsenceAfterPick, sComponentAbsenceBeforePlacement,
sTreatmentError, sDroppedError, sComponentAbsenceAfterPlacement,
sPickupRetries)
Definition of sRejectIdent
sRejectIdent = SUM(sComponentMaterialDefect, sIdentError)
Definition of sPlacedComponents values
-1: Undefined for all data records issued by a station with a station software version < 708
0: No successful placement (i. e. pass-through mode, canceled board etc.)
n: n successful placements
Definition of sAttritionInfoVersion values
0: Reject data comes from a station software version < 708
1: Reject data comes from astation software version >= 708
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
28
4.5.1.23 CompPosition Table
CompPosition OIS name Data type Byte CI I P
Identification number of the station
(reference to STATION table)
lId int 4
Reference number of the entry lIdPosition int 4
Table/location from which the component was
retrieved
ucTable tinyint 1
Track number sTrack smallint 2
Tower (MTC only, otherwise dummy) ucTower tinyint 1
Level (WPC or MTC only, otherwise dummy) sLevel smallint 2
Division sReceptacle smallint 2
Identification number of the component name
(available with station software version 701 and
higher)
lPartNumber int 4
Identification number of the component shape
name (available with station software version
701 and higher)
lComponentShape int 4
SIPLACE Pro number for feeder type (available
with station software version 701 and higher)
lFeederType long 4
Time when the data is written. Server time dtCreated datetime 8
Unique feeder ID strFeederId nvarchar(128) 256
4.5.1.24 Panel Table
Panel OIS name Data type Byte CI I P
Reference (from BOARD table).
Note: This reference may occur several times
since a board may have several panel groups.
lIdPanel int 4
Count of produced panels lCountProduced int 4
Count of omitted panels lCountOmitted int 1
Encoding whether the panel entry is intended to
be counted as assembled PCB (based on
SIPLACE Pro setting)
CountAsAssembledPCB tinyint 2
Name of the concerned placement list strPlacementListName nvarchar(256) 512
Definition of CountAsAssembledPCB values
0: Undefined
1: True
2: False
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
29
4.5.1.25 SpliceEvent Table
SpliceEvent OIS name Data type Byte CI I P
Identification number of the station
(reference to STATION table)
lId int 4
Table/location from which the component was
retrieved
ucTable tinyint 1
Track number sTrack smallint 2
Division sDivision smallint 2
Identification number of the component name lPartNumber int 4
Date/time at which the data record was created.
Station time
dtTime datetime 8
Time when the splice occurred at the station dtSpliceTime datetime 8
Time when the data is written. Server Time dtCreated datetime 8
Sequence ID (internal use) lIdSequence int 4
