ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
65
2053
Position: evaluation not possible (Grid)
2054
Position: evaluation not possible (Ball)
2055
Dimension: evaluation not possible
2056
Dimension: evaluation not possible (Size)
2057
Dimension: evaluation not possible (Row)
2058
Dimension: evaluation not possible (Corner)
2059
Dimension: evaluation not possible (Lead)
2060
Dimension: evaluation not possible (Grid)
2061
Dimension: evaluation not possible (Ball)
2062
No. of pins: evaluation not possible
2063
No. of pins: evaluation not possible (Corner)
2064
No. of pins: evaluation not possible (Lead)
2065
Colinearity: evaluation not possible
2066
Colinearity: evaluation not possible (Corner)
2067
Colinearity: evaluation not possible (Lead)
2068
Spacing: evaluation not possible
2069
Spacing: evaluation not possible (Corner)
2070
Spacing: evaluation not possible (Lead)
2071
Position: no result
2072
Position: no result (Size)
2073
Position: no result (Row)
2074
Position: no result (Corner)
2075
Position: no result (Lead)
2076
Position: no result (Grid)
2077
Position: no result (Ball)
2078
Dimension: no result
2079
Dimension: no result (Size)
2080
Dimension: no result (Row)
2081
Dimension: no result (Corner)
2082
Dimension: no result (Lead)
2083
Dimension: no result (Grid)
2084
Dimension: no result (Ball)
2085
No. of pins: no result
2086
No. of pins: no result (Corner)
2087
No. of pins: no result (Lead)
2088
Colinearity: no result
2089
Colinearity: no result (Corner)
2090
Colinearity: no result (Lead)
2091
Spacing: no result
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
66
2092
Spacing: no result (Corner)
2093
Spacing: no result (Lead)
2094
Position: component outside feed tolerance
2095
Position: component outside feed tolerance (Size)
2096
Position: component outside feed tolerance (Row)
2097
Position: component outside feed tolerance (Corner)
2098
Position: component outside feed tolerance (Lead)
2099
Position: component outside feed tolerance (Grid)
2100
Position: component outside feed tolerance (Ball)
2101
Dimension: component outside feed tolerance
2102
Dimension: component outside feed tolerance (Size)
2103
Dimension: component outside feed tolerance (Row)
2104
Dimension: component outside feed tolerance (Corner)
2105
Dimension: component outside feed tolerance (Lead)
2106
Dimension: component outside feed tolerance (Grid)
2107
Dimension: component outside feed tolerance (Ball)
2108
No. of pins: component outside feed tolerance. Sequential error
2109
No. of pins: component outside feed tolerance (Corner)
2110
No. of pins: component outside feed tolerance (Lead)
2111
Colinearity: component outside feed tolerance. Sequential error
2112
Colinearity: component outside feed tolerance (Corner)
2113
Colinearity: component outside feed tolerance (Lead)
2114
Spacing: component outside feed tolerance. Sequential error
2115
Spacing: component outside feed tolerance (Corner)
2116
Pitch: Component outside feeding tolerance (Lead)
2277
The difference between open and closed vacuum values is too small
2424
Coplanarity: Bad component, to be returned
2451 Coplanarity: Component cannot be measured (excessive offset in lead
direction)
2452
RV-head: Segment not airtight after placement
2453
IC-head: Segment not airtight after placement
2454
Nozzle contaminated or worn out
2455
Vacuum value of segment too low with valve closed
2516
Warning: Nozzle is slightly soiled
3475
Difference in vacuum too great between placement and pick-up
3513
Vision system: Flipped component detected
3553
Component not on nozzle prior to dipping
3556
Spur von Rüstkontrolle gesperrt
3570
Component on the nozzle before pickup pr nozzle dirty
ASM OIS/SIS Databases 15.1 (R18-1) / Interface Description 05/2018 Edition
67
3573
Nozzle dirty or obstruction during pickup
3575
Warning: Early vaccuum setting not enabled
13005
Coplanarity module: Component faulty
15265
Cover foil on tape feeder damaged
15266
Cover foil not removed from tape feeder
17410
Coplanarity module: Component faulty
18109
Cover foil on tape feeder damaged
18132
Cover foil not removed from tape feeder
18133
Coplanarity module: Component faulty
18134
Cover foil on tape feeder damaged
18135
Cover foil not removed from tape feeder
18136
Nozzle worn
18137
Track empty error detected by component sensor
18138
Nozzle missing
18139
Nozzle soiled before pick-up
18509
Vacuum not achieved (no component on the nozzle)
18510
Vacuum not achieved (component not located securely on the nozzle)
18517
The difference between open and closed vacuum values is too small
18554
Component not at nozzle after pick-up
18555
Component not on nozzle prior to placement
18557
Nozzle not empty prior to pick-up
18558
Nozzle not empty after placement
18560
Error in feeder on pick-up
18565
Component not at nozzle after pick-up
18566
Component not at nozzle before placement
18567
Component not on nozzle during dipping
18570
Component not on nozzle prior to dipping
18916
Component cannot be picked up with the selected head type
18921
(Bauelement wird abgeholt bevor die Abholposition erreicht wird)
19112
Component not seated on nozzle correctly on pickup
21017
Component picked up at wrong angle
21424
Component description for measurement with SIPLACE Vision incomplete
21802
Component outside feed tolerance
21803
Component rotation angle outside tolerance
21804
Measured offset in X and Y outside presentation tolerance
21805
Measured offset in X outside presentation tolerance
21806
Measured offset in Y outside presentation tolerance
21808
Measured blob area outside tolerance
21811
Position cannot be determined
