TM-300 Addendum 61170710.fm Page 1 of 1
This software modification allows additional
tape PITCH
es to be used (36, 40, 44, 48, 52
& 56mm).
To use this extended capability, the program,
‘TM300EXT.A01’, must be downloaded to the
TM-300 controller.
Follow the Software Download procedure on
page 15 of the Operator’s Manual.
Page 13 of the TM-300 Operator’s Manual
shows the index/seal capability of the current
factory default program ‘TM300.A01’
The modified program, ‘TM300EXT.A01’,
allows extended
index/seal capability (shown
below in boldface)
Substitute this extended table below for the
one located on page 13 of the Operator’s
Manual.
Example sequence of events for PITCH=56.
1. Tape sprocket advances 28mm.
2. Seal is issued.
3. Tape sprocket advances another 28mm.
4. Add one count to the counter.
5. Final Seal is issued.
Addendum
TM-300 Extended Software Modification
751 Summit Avenue
Mankato, MN 56002
(507) 387-2039 FAX: (507) 387-2257
www.VTEKUSA.com
E-Mail: Info@VTEKUSA.com
