9 E by DEK Machine S t andard C onf igurati on Services Specification Voltage 115 Volts to 230 Volts ± 10%. Single phase 50/60 Hz Maximum Curr ent at 11 5V 6 Am ps Maximum Curr ent at 23 0V 3 Amps Over Current Protection…
8
E by DEK
Machine Standard Configuration
Vision
Specification
Camera
DEK HawkEye 750 digital camera with 2-way LED
illumination
Fiducials
3
Fiducial Types
Synthetic fiducial library or unique pattern recognition
Fiducial Size
0.3mm to 3mm*
Fiducial Locations
Anywhere on substrate
Camera Lighting
Software controlled programmable LED lighting
*0.1mm to 3mm available via RFQ
Standard C Chase
Specification
Stencil Frame Size (maximum)
736mm x 736mm (29” x 29”)
Stencil Frame Thickness
25mm to 38mm (1” to 1.5”)
Image Position
Front
Centre
Custom
Operating Environment*
Specification
Temperature
10° to 35°C (50° to 95°F)
Humidity
30% to 70% relative humidity (non-condensing)
Altitude
Maximum 2,000 metres (6,500 feet)
Location
Internal only, not suitable for wet locations
*as described in the IPC Standard J-STD-001G-Reqirements for Soldered Electrical and Electronic
Assemblies Section 4 with respect to the following:
• Facilities - Cleanliness and ambient environments in all work areas be maintained at levels that
prevent contamination or deterioration of tools, materials, and surfaces to be soldered or
conformally coated. Eating, drinking, smoking, including use of e-cigarettes, and/or use of
tobacco products be prohibited in the work area.
• Environmental Controls - The soldering facility (controlled work area) be enclosed, temperature
and humidity controlled, and maintained at a positive pressure.
• Controlled Work Area (CWA) For the purpose of this statement, a Controlled Work Area
(CWA) is defined as an enclosed assembly / processing area maintained to a high degree of
shop cleanliness, environmental control, and foreign object debris (FOD) mitigation, either by
process or procedure, to limit the entry of contamination.
9
E by DEK
Machine Standard Configuration
Services
Specification
Voltage
115 Volts to 230 Volts ±10%. Single phase 50/60 Hz
Maximum Current at 115V
6 Amps
Maximum Current at 230V
3 Amps
Over Current Protection
An external circuit breaker ≤20 Amps is required to be
fitted in line with the machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
Shipping Information
Specification
Approximate Weight
810kg boxed (dependent upon configured options
selected with machine)
654kg unboxed (dependent upon configured options
selected with machine)
Approximate Dimensions
1342mm x 1624mm x 1472mm High
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
10
E by DEK
Machine Productivity Options
Process
Specification
Print Method
Paste Dispenser (APDII or Jar Dispenser)
Paste Roll Height Monitor
Stinger
Stencil Positioning
Semi auto loading incorporating squeegee drip tray
Semi auto loading without squeegee drip tray
Stencil Frame and Thickness
Frame variants – Fully adjustable to accommodate
frame sizes in the range of 381mm to 736mm by 38mm
frame thickness
Handling & Cleaner Options
Specification
Cycle Time Upgrade
11 seconds to 8 seconds
Substrate Handling Size (maximum)
620mm (X) x 508.5mm (Y) – Long Board Option
Under Stencil Cleaning
Blue long board Cleaner (600mm)
Software & Communications
Specification
Substrate Handling
Flexible boards
Selective print pass through
Dual speed motor (DSM)
Statistical Process Control
On board, reported via operator interface (QC-CALC)
