Page 5 2. When o rdering t he cable , fin d its No. from the wirin g diagra m. There are two method s of finding th e part No. for order pl acem ent. <Ex ample of or der> <Case 1> W hen orderin g the ca ble, …
Page 4
2.
How to issue order.
Adopt the following step in issuing order in accordance with article No. of parts for issued order.
1. Search for the required wiring diagram from the drawing No. on the contents.
(Contents)
(Wiring diagram)
See contents.
Article No. of perti-
nent parts for issued
EJM8A-E-WDB00-A01-00
EJM1A-902E
EJM1A-901E
N610001696AA - E0040-01
See wiring diagram.
Page 5
2. When ordering the cable, find its No. from the wiring diagram.
There are two methods of finding the part No. for order placement.
<Example of order>
<Case 1>
When ordering the cable, find the No. enclosed within or in the wiring dia-
gram.
Order No.
Example c
Example d
(Alphanumeric) No. shown in the wiring diagram
EJM8A-E-WDB00-A01-00
EJM1A-905E
KXF
P6ER7
c
KXF P6ER7
d
N51 0006032 AA
N51000
6032AA
Page 6
<Case 2>
When ordering the cable, find the lower No. enclosed within or in the wiring
diagram and add “KXF” to that No.
Order No.
Example e
Lower 5-digit (alphanumeric) No. starting with “KXF + P”
EJM8A-E-WDB00-A01-00
EJM1A-906E
e
KXF P6EP0
K001D
P6EP0
