TRS Advanced Maintenance
118
Issue 2, Nov 14
a. Remove and retain both the camera safety guard securing screws.
b. Rotate the camera safety guard 180°, and secure using the retained screws.
c. Ensure the height of the red safety screw (measured from the bottom of the camera safety
guard to the top of the safety screw) is 40mm +/-0.5mm.
TRP Jig (POJ) with Safety Guard in Extended Position
40mm
(+/-0.5mm)
Red Safety Screw
Rear Locating Block (2 off)
Issue 2,
22. Inst
a
are
refe
r
mo
v
Wh
e
this
Nov 14
a
ll the PO
J
against th
e
rence plat
e
v
ement fro
m
e
n the POJ
will lead to
J
jig on top
e
rear face
e
s (front an
d
m
the refere
jig is fitted,
damage to
of the TR
P
of the TRP
d
back) of t
h
n
ce plates,
the TRP
m
the camer
a
P
. Lower th
e
P
, then car
e
h
e depth g
a
remove an
m
ust not be
a
and also
t
e
rear of th
e
fully lower
a
uges are
f
d re-sit the
s
ent to ho
m
t
he TRP as
s
T
R
e POJ jig
u
the front o
f
f
lush to the
POJ jig.
m
e position
s
embly.
R
S Advanc
e
u
ntil the re
a
f
the POJ j
TRP surfa
c
under any
c
e
d Maintena
11
9
a
r locating
b
i
g. Check t
h
c
e. If there
c
ircumstan
c
nce
9
b
locks
h
at all
is any
c
es as
TRS Advanced Maintenance
120
Issue 2, Nov 14
23. Switch on and zero out the four outer gauges (not the central pair):
a. Press the Data button to switch on.
b. Zero the gauge by pressing the Set button.
c. Check that the measurement unit shown on the screen is “mm”. If it is showing “in” press the
Mode button and check the screen has changed to display “mm”.
24. Close the printhead front cover.
25. Press the System button.
26. Select Back.
27. Select Back.
28. Select Back.
29. Navigate to the Tooling Setup Page and in the Rising Table section select Vision Height.
30. Select Open Cover Commands.
31. Open the printhead front cover.
in
.
mm
MODE
SET
DATA
ON
OFF
.
mm
in
mm
MODE
.
Data Button (On/Off)
Set Button (Zero)Mode Button (in/mm)
Measurement Unit
Indicator
