Using Tooling Setup Page:
Visually check the vacuum adaptor plate before fitting for any damage or
contamination
Fit vacuum adaptor plate and check that is sits against the vacuum seal with no
rocking
Visually chack the tooling before fitting for any damage or contamination
Check that tooling is fastened correctly and no rocking can be observed in the tooling
base
Check with Z-Lock off that all towers move freely in Z
With Z-Lock ON check that no towers move in Z without considerable force
Visual check only that all tower caps rotate and return to centre
Warning; Small movements only: over stressing this system will cause damage
Z-Lock Pressure
Aim: To measure the force needed to overcome the Z-Lock pressure
Method: In Diagnostics drive table to Vision Height and lock the Z-Lock in position. Do not
set TRP position. Drive the table to Print Reference Height. Position the Co-Planarity Bars
over the tooling.
Jog the table down using jog buttons until a gap of 3mm to 5mm can be observed between
the bottom of the force meter and the top of the Bars when positioned over the tower.
Apply pressure until the tower moves and the force meter contacts the bars.
Take reading and record in to table below, take 4 reading per tower.
Note: Looking for more than 2Kg per tower. Spring Pressure
Aim: To measure the spring force for per tower, looking for consistency.
Method: In Diagnostics drive table to vision height: Do not set TRP position.
Turn Z-Lock off and make sure the towers move in Z height.
Drive table to print reference height
Position the Co-Planarity bars over the tooling
Jog the table down using jog buttons until a gap of 3mm to 5mm can be observed between
the bottom of the force meter and the top of the bars when positioned over the tower
Apply pressure until the tower moves and the force meter contacts the bars
Take reading and record in to table
Issue 2, Nov 14
TRS Advanced Maintenance
127
Board Stop and Surround Installation and Setup
Board Stop Setup
Complete board stop setup
Checking the repeatability of the board stop setting to the tower pass through the tray
without contacting the side walls.
Soft Lift/Land Setup
Does the movement and distance offer a smooth/slow approach to pick up the
substrates from the tray?
Does the movement and distance offer a smooth/slow approach to lowering the
package into the tray?
When vacuum is applied does this course any adverse effects to the pickup and
lowering of the substrates?
Surround Installation
Visually check that surround is clean and no damage can be found on top or bottom
plate
Check that the surround has been fitted correct, that all screws and dowels are located
in the bearings
With active surround fitted, Z-Lock off and label at vision height do all towers sit above
the active surround by more than 100µm but no more than 1mm?
TRS Advanced Maintenance
128
Issue 2, Nov 14
Pitch Adjustment: Follow the procedure from Pre-Production setup “Pitch and Level
Adjustment”
OutstandingIssue ProbableCause(s) SuggestedAction
TRAjointsloos ening.
Wor kthroughprocedures3&4.Ifthe
problemis notresolvedorworsens,
contactDEKcustomersupport.
Railcapnotcorrectlysupported.
Railcappadsnotplanar.
Gapbecomesirregularor
asymmetricalwithload
applied.
Fro ntorreargapbecom es
muchlarg eraftertooling
changeover.
Pressuredistribution
isnot
appropriateforcurrenttoolloading .
Performdetailedindependentsurface
ins pections ofbothpartsandsumlocal
deviations.Comparetoprocesslimits.
ContactDEKcustomersupporttodiscuss
specifictooling requirements.
Gapincreasesafterextended
machineoperation.
SeeTRSmodulesetupdocum entationfor
ins tructions onhowtocheckandreset
therail
ca ptobaseheight.
TRPstandoffscrewsset
correctlyonsurfacetablebut
willnotlevelonfourpoints
torailcap.
SupportsarenotplanarandtheTRPis
beingdistortedbythetwisting
momentapplied.
Wor kthroughprocedures3&4.
Gapistooincons is tenteven
whennoloadisappliedto
anyparts.
TRPandSurroundplatesurfacesare
irregularrelativetoeac hother.
(Objective 43, Page 123)
