Installation Manual, Station Software Version 603.01 Issue 11/2006
8 of 62
2.4 Languages
User interface for station computer and SIPLACE Vision:
The standard package contains German and English versions. Other languages contained in the
languages package are optional and available under item number 00383490-01.
The following table indicates which languages are available for the station software and SIPLACE Vision:
Language Station software /
SIPLACE Vision
French x
Italian x
Spanish (Mexico) x
Portuguese (Brazil) x
Hungarian x
Czech x
Polish x
Russian x
Estonian x
Chinese (simplified) x
Chinese (traditional) x
Korean x
Japanese x
Thai *) x
*) Only available for GUIs (English online help)
SITEST user interface:
German and English are included on the software DVD.
Installation Manual, Station Software Version 603.01 Issue 11/2006
3 Requirements
3.1 SIPLACE X series and D series software components
3.1.1 Station
The station uses the following operating system configuration:
Station computer: Microsoft Windows XP Professional
(including Service Pack 2 and most recent hotfixes)
- Machine controller: Microsoft Windows embedded XP (SP2)
3.1.2 Machine components
The following versions of other machine components are required for the station software to function
correctly:
Station computer SIPLACE Vision Machine controller SIPLACE Pro
Version 603.01 Version 331 Version 603.01 Version 4.1
Caution:
The functional statuses of the station computer, vision and machine controller software must
be compatible.
9 of 62
Installation Manual, Station Software Version 603.01 Issue 11/2006
10 of 62
3.1.3 Embedded software
Table still needs to be updated for the current versions and machine types!
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4 D1 D2 D3 D4
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.0A A031020A.bhx
X X X
Application 2 / X 02.45 X0320245.bhx
X X X
Gantry axes
A363
Application 2 / Y 02.45 Y0320245.bhx
X X X X X X X
BIOS 03.3F A040033F.BHX
X X X X X X X
Application 1 01.0C A041010C.bhx
X X X X X X X
Gantry axes
A 364
Application 2 04.66 A0420466.bhx
X X X X X X X
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.0A A031020A.bhx
X X X
Application 2 / star 02.45 S0320245.bhx
X X X
Application 2 / Z 02.45 Z0320245.bhx
X X X
Revolver head
axes
363
Application 2 / DP 02.45 D0320245.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X X X X X
Application 1 01.0C A041010C.bhx
X X X X X X X
Revolver head
axes
364
Application 2 04.66 A0420466.bhx
X X X X X X X
BIOS 02.00 A0300200.bhx
X X X
Application 1 02.00 A0300200.bhx
X X X
Application 2 / Z 02.0A A031020A.bhx
X X X
TWIN Head axes
A 363
Application 2 / DP 02.45
P0320245.bhx
X X X
BIOS 03.3F A040033F.BHX
X X X X
Application 1 01.0C A041010C.bhx
X X X X
Application 2 / Z 04.66 A0420466.bhx
X X X X
TWIN Head axes
A 364
Application 2 / DP 04.66 A0420466.bhx
X X X X
