8 . 3 "ACV Check Status" T ab Sheet This tab sheet is used to monitor the ACV check status and the read data, and set the parameters for manual checking. • Sheet Layout When the "ACV Check Status" tab…
• Feeder Type
Select one of the following buttons to specify the feeder type.
[8 mm] , [12 mm] , [16 mm] , [24 mm] , [32 mm] , [44 mm] , [Ref
Cur Prgm]
When the [Ref Cur Prgm] button is selected, the tape
width of the specified feeder can automatically be re-
ferred to.
(2) Press the [ENABLE] button in 2 seconds after the [Move Fdr Crg to
adjustment position] button and the [ON] button (entitled "Move").
The specified feeder moves to the position where the data can be
read.
(3) Press the [ENABLE] button in 2 seconds after the [ACV data read]
button and the [ON] button (entitled "Move").
The ACV data is read and the result appears in the "Read Result"
text box (located at the upper right field of the tab sheet).
(4) Press the [ENABLE] button in 2 seconds after the [Move Fdr Crg to
origin] button and the [ON] button (entitled "Move"). The feeder car-
riage starts moving to its origin.
8.2 "ACV Set" Tab Sheet
Note
0310-001 14 AIP01EGP
8.3 "ACV Check Status" Tab Sheet
This tab sheet is used to monitor the ACV check status and the read
data, and set the parameters for manual checking.
• Sheet Layout
When the "ACV Check Status" tab is pressed in the "RECOVERY"
window (submenu), the following tab sheet appears inside the win-
dow.
Fig. 6
*1 "Feeder #1", "Feeder #2", "Feeder #3", and "Feeder #4" Tabs
Each tab represents the corresponding feeder carriage.
*2 Fdr. No. (Actual Fdr No.)
Displayed are the feeder Nos. used for the current program and the
actual feeder Nos. in ( ).
*3 Component ID
Displayed are the component IDs of the placement feeder location
data related to the feeder No.
The displayed parameters are not those read from the Tag
memory.
8.3 "ACV Check Status" Tab Sheet
*1 *2 *3 *4
*5
*6
Note
0310-001 15 AIP01EGP
*4 ACV Check Status
Displayed is the ACV check status.
Table 5
Items Status
Not check The ACV checking is not being made.
Finished Check The component ID identical to the information in the ACV line server
was detected during the ACV checking.
Comp Empty A component shortage error was detected during the ACV checking.
It is required to register the component.
Out of NC FDR The component ID nonidentical to the information in the ACV line server
was detected during the ACV checking.
Not Register A feeder provided with components not registered in the ACV line server
was detected.
Not Use Not used in the pattern program.
*5 [ ] and [ ] Buttons
The up or the down arrow can be pressed to scroll up or down the
tab sheet to expose hidden items.
*6 [Screens] Button
When this button is pressed, another tab sheet appears.
8.3 "ACV Check Status" Tab Sheet
0310-001 16 AIP01EGP
