Adjus t ment In str uc tio ns SI PLA CE HS- 50 3 Test Equipment Edition 12/00 3.10 Gauge for Z-A xis 67 * DXJHIRU = $[L V $SSOLFDWLRQ The gaug e is use d for the a djustmen t of the z-axis stop on the top.
3 Test Equipment Adjustment Instructions SIPLACE HS-50
3.9 Calibration Tool for the Collect & Place Head Edition 12/00
66
&DOLEUDWLRQ7RROIRUWKH&ROOHFW3ODFH+HDG
Gauge for the star, item no: 00326164-01
Parallel pin 1.4 mm, item no: 00326160-
01
Parallel pin 1.5 mm, item no: 00326161-
01
Parallel pin 1.6 mm, item no: 00326162-
01
Parallel pin 1.3 mm item no: 00326163-01
0HDVXULQJWRROV 8VDJH
Gauge for the star Adjustment of zero point correction star
Parallel pin 1.4 mm
Adjustment of distance between read head of dp - station to glass
pane of sleeve
Parallel pin 1.5 mm
Parallel pin 1.6 mm
Parallel pin 1.3 mm Adjustment of distance light barrier z-axis bottom to sleeve
Distance gauge Adjustment of the distance between valve plunge and star
Adjustment Instructions SIPLACE HS-50 3 Test Equipment
Edition 12/00 3.10 Gauge for Z-Axis
67
*DXJHIRU=$[LV
$SSOLFDWLRQ
The gauge is used for the adjustment of the z-axis stop on the top.
3 Test Equipment Adjustment Instructions SIPLACE HS-50
3.10 Gauge for Z-Axis Edition 12/00
68
