MODEL TCM-3000Z-2 0108-001 209 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 11 - 11 1 630 094 6161 BOX 1 628DD-03V-001 2 630 051 6173 HANDLE 1 628DD-03D-018 3 41 1 141 4503 W ASHER V 8X17X1.6 2 F W 8 4 41 1 141 3100…
MODEL TCM-3000Z-2
0108-001
208
ELECTRICAL SECTION
Fig.11-11
Rear Operation Panel
31
32
32
10
6
8
7
1
2
29
3
4
5
30
A
43
44
45
46
47
49
48
52
53
54
B
47
46
45
44
42
42
41
41
50
50
51
55
56
57
57
42
B
DETAIL"A"
11
11
12
12
13
13
.
.
24
25
.
21
22
.
16
16
17
17
.
18
23
19
20
.
27
27
28
28
14
14
Fig.11-11
TCM-3000Z-2
MODEL TCM-3000Z-2
0108-001
209
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
11-11
1 630 094 6161 BOX 1 628DD-03V-001
2 630 051 6173 HANDLE 1 628DD-03D-018
3 411 141 4503 WASHER V 8X17X1.6 2 FW8
4 411 141 3100 WASHER SPR 8 2 SW8
5 630 000 8005 BOLT,HEX-SCT 2 M8X16
6 630 094 4877 UNIT,DISPLAY 1 #GM-1000RJ C 628DD-03D-014
7 630 094 2972 PANEL 1 628DD-03V-008
8 411 140 8304 SCR BIN 4X10 8 M4X10 BIN
10 630 058 5728 PANEL 1 628DD-03V-002
11 630 033 4609 SWITCH,BUTTON 1 PB2 628DD-03D-001
12 630 033 4586 DISPLAY ELEMENT 1 LED8 628DD-03D-002
13 630 033 4593 ACCESSORY,SW 1 628DD-03D-003
14 630 066 7042 SWITCH,BUTTON 1 PB4 628DD-03D-004
16 630 000 2713 SWITCH,BUTTON 1 PB14(LED9) 628DD-03D-006
17 630 000 0382 ACCESSORY,SW 1 628DD-03D-009
18 630 000 2515 SWITCH,BUTTON 2 PB18, PB19 628DD-03D-005
19 630 000 2713 SWITCH,BUTTON 2 PB15(LED10), PB22(LED11)
628DD-03D-006
20 630 000 0382 ACCESSORY,SW 2 628DD-03D-009
21 630 000 2508 SWITCH,BUTTON 2 PB16, PB17 628DD-03D-012
22 630 000 0382 ACCESSORY,SW 2 628DD-03D-009
23 630 007 6066 SWITCH,BUTTON 1 PB20 628DD-03D-007
24 630 007 6066 SWITCH,BUTTON 1 PB21 628DD-03D-007
25 630 000 0382 ACCESSORY,SW 1 628DD-03D-009
27 630 000 2744 SWITCH,BUTTON 1 PB23(LED12) 628DD-03D-008
28 407 035 4704 LED SLP-721F 1 LED13 628DD-03D-011
29 411 140 8304 SCR BIN 4X10 5 M4X10 BIN
30 630 000 5059 COUNTER 1 MCT 628DD-03D-013
31 630 085 7566 COVER 1 628DD-03V-006
32 411 113 9109 SCR TRS 5X10 9 M5X10 TRS
41 630 057 8010 SUPPORT 1 628DD-03V-004
42 630 051 6180 BUSH,BEARING 2 628DD-03D-015
43 630 052 3041 BRACKET 1 628DD-03V-003
44 630 051 5923 PIN,LOCATE 2 628DD-03V-005
45 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
46 411 141 3001 WASHER SPR 6 4 SW6
47 630 000 7886 BOLT,HEX-SCT 4 M6X16
48 630 051 6166 MECH PARTS(DRYMET WASHER) 1 628DD-03D-016
49 630 051 6159 MECH PARTS(7LOBE KNOB) 1 628DD-03D-017
50 630 041 6770 COLLAR 1 628DD-03V-007
51 630 000 8944 SET SCREW 1 M5X6 SET
52 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
53 411 141 3001 WASHER SPR 6 4 SW6
54 630 000 7886 BOLT,HEX-SCT 4 M6X16
55 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
56 411 141 3001 WASHER SPR 6 4 SW6
57 630 000 7893 BOLT,HEX-SCT 4 M6X20
MODEL TCM-3000Z-2
0108-001
210
ELECTRICAL SECTION
Fig.11-12
1 Miscellaneous Parts-1
E
E
4
3
2
10-1
10-5
10-5
10-1
10-6
10-2
10-2
10-3
10-4
19-4
19-4
19-3
19-3
19-2
19-2
56
56
66
61
65
65
62
63-1
63-1
62-1
61-1
61-1
58
58
59
59
57
57
19-6
19-1
19-1
19-1
68
68
1
19-5
18
18
17
17
16
16
15
15
11-3
11-3
14
13
12
11-2
14
14
13
13
12
12
11-1
11-1
69-3
69-3
69-2
69-2
69-1
69-1
69
A
50
50
49
49
48
48
47
41
50
50
49
49
48
48
46
46
45
51
44
43
55
55
52
54
54
53
53
42
21
29
28
28
27
32
31
30
30
22
23
32
26-1
31
30
24
25
1
2
4
3
72
A
71
71
73
73
73
95
See Fig.11-14
See Fig.11-14
Key No.7
96
97
91
91
87
87
92
93
93
93
92
89
89
88
88
30
31
32
24
24
25
25
23
23
22
22
21
21
26
32
32
31
30
29
28
27
27
10-2
10-1
10-5
10-5
10-1
10-6
10-3
10-4
67
64
64
63
104
103
102
101
B
C
D
14
14
13
13
12
12
D
B
C
7
6
8
9
7
5
8
9
Fig.11-12
