3 7 Stopper Conveyor Unit KW8-080422 Main Stopper Sub Stopper EXIT Stopper 21 16 22 15 21 17 18 19 32 27 32 24 34 26 23 30 25 20 21 20 19 33 31 29 28 3,4 6,7 8 10 9 1 12 2 5 1 1 14 13 13 14 1 1 No. Part No. Part Name Q&a…
2
7
Locate Pin
Conveyor Unit
KW8-080422
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KG2-M9211-03X PISTON
2
/
2 KG2-M9212-00X GUIDE
2
A
3 KL0-M9213-00X CYLINDER
1
B
4 KW8-M9214-00X PLATE 1 LOCATE PIN
1
/
5 KG2-M9215-03X HOLDER
1
L /
6 KG2-M9216-03X HOLDER
1
R /
7 KG2-M9217-02X NUT HOLDER
2
/
8 KW8-M9218-00X PLATE 2 LOCATE PIN
1
/
9 KG2-M9219-00X JOINT CYLINDER
1
/
10 $SL4-M5 JOINT
2
/
11 91317-03008 BOLT HEX.SOCKET HEAD
10
/
12 91317-03030 BOLT HEX.SOCKET HEAD
2
/
13 91317-05012 BOLT HEX.SOCKET HEAD
4
/
14 KG2-M9275-01X SPG .
2
/
15 91317-03006 BOLT HEX.SOCKET HEAD
2
/
3
7
Stopper
Conveyor Unit
KW8-080422
Main Stopper
Sub Stopper
EXIT Stopper
21
16
22
15
21
17
18
19
32
27
32
24
34
26
23
30
25
20
21
20
19
33
31
29
28
3,4
6,7
8
10
9
1
12
2
5
11
14
13
13
14
11
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KG2-M9181-01X CYLINDER MAINSTOPPER 2 MAIN B
2 KG2-M9186-01X GUIDE MAIN STOPPER 2 B
3 KW8-M9182-00X BASE,STOPPER 2 R>L /
4 KW8-M9182-10X BASE,STOPPER 2 L>R /
5-1 KW8-M9183-00X ARM STOPPER 2 /
5-2 KW8-M9183-01X ARM STOPPER 2 2000/10/19 /
6-1 KW8-M9184-00X LEVER,STOPPER 2 /
6-2 KW8-M9184-01X LEVER,STOPPER 2 R>L 2000/10/19 /
7 KW8-M9184-10X LEVER,STOPPER 2 L>R (2000/10/16) /
8-1 KG7-M9163-00X STOPPER 2 /
8-2 KW8-M9189-00X STOPPER 2 2000/10/19 /
9 KW8-M9185-01X STOPPER,GUIDE 2 (2000/9/25) OK /
10 KW8-M9186-01X BRKT.,STOPPER 2 (2000/9/21) OK /
11 $BF4BU JOINT 4 /
12 KW8-M9188-00X COLLAR 1 2000/10/19 /
13 92990-03200 WASHER PLAIN 4 /
14 95302-03700 NUT HEXAGON 4 (2006/1/16) OK /
15 KV1-M9271-00X PLATE,EXIT STOPPER 1 EXIT /
16 KV7-M9282-00X STOPPER,SUB 1 /
17 KV7-M9283-00X CYL. 1 YMDA16X35 B
18 KV1-M912A-00X BRACKET,SENSOR 1 (2000/9/1) OK /
19 KU0-M655F-20X SENSOR,1-3 2 L=1400 /
20 $SL4-M5 JOINT 2 /
21 91317-03006 BOLT HEX.SOCKET HEAD 8 /
22 91317-04008 BOLT HEX.SOCKET HEAD 2 /
23-1 KV7-M9281-10X PLATE-2,SUB STOPPER 1 SUB /
23-2 KGD-M9271-00X PLATE-2,SUB STOPPER 1 2002/3/15 /
24 KV7-M9282-00X STOPPER,SUB 1 /
25 KV7-M9283-00X CYL. 1 YMDA16X35 B
26 90990-41J104 COLLAR 2 (2008/4/11) OK /
27 KGD-M912A-00X BRACKET,SENSOR 1 (2001/10/22) OK /
28 KV7-M9284-10X NUT PLATE,SENSOR 2 /
29 KM0-M655F-10X SENSOR 1-3 2 L=1150 /
30 $SL4-M5 JOINT 2 /
31 91312-03005 BOLT HEX.SOCKET HEAD 4 (2006/1/16) OK /
32 91317-03012 BOLT HEX.SOCKET HEAD 4 /
33 91317-04008 BOLT HEX.SOCKET HEAD 2 /
34 91317-04040 BOLT HEX.SOCKET HEAD 2 /
4
7
Clamp Board
Conveyor Unit
KW8-080422
12
12
2
6
4
5
1
6
7
15
9
12
9
3
13
5
1
6
12
9
16
10
13
5
2
6
7
8
11
9
14
13
17
8
11
14
13
5
No. Part No. Part Name Q'ty Remarks Date of change Compati. Rank Level
1 KG2-M9261-02X HOLDER 1,GUIDE 4 /
2 KG2-M9262-02X HOLDER 2,GUIDE 4 /
3 KW8-M9263-01X PLATE 1,SLIDE 1 (2000/10/18) OK /
4 KW8-M9264-00X PLATE 2,SLIDE 2 /
5 K98-M9237-00X BALL SLIDE 8 BSR1530 B
6 KG2-M9276-02X SPRING 8 /
7 KG2-M9277-02X SPACER 4 /
8 KG2-M9279-02X CYLINDER 8 BDA6X10 B
9 92903-03600 WASHER,PLAIN 16 (2001/12/19) OK /
10 91317-03012 BOLT HEX.SOCKET HEAD 2 /
11 91317-03014 BOLT HEX.SOCKET HEAD 8 /
12 91317-04010 BOLT HEX.SOCKET HEAD 8 /
13 98907-03006 SCREW BINDING HEAD 8 /
14 $BF4BU JOINT 4 /
15 KG2-M9283-00X AIR HOSE 2 SPS-4-10 /
16 $UT4M JOINT 2 /
17 KM5-M8504-00X REGULATER 2 RVUM4-4 2001/6/4 /
