1012-008 93 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 1 6301544595 FRAME 1 804PD-1 10-001 210B4142 2 6301335346 ASSY ,COVER 1 804PD-1 10-002 01 1A0013 3 6301308319 COVER(D) 1 804PD-1 10-003 21 1A91 1 1 4 …

100%1 / 98
0909-004
92
10
10
3
1
See Fig.P-1
Key No.2
7
8
9
6
4
See Fig.P-1
Key No.47
See Fig.P-5
Key No.445
16
18
2
17
.
12
.
11
13
15
14
20
19
21
継ぎ目検出ユニット
JOINT DETECTION UNIT
DS-24320 DS-24320
Fig. PD-1
24,32mm
幅テープフィーダ用
FOR 24,32mm TAPE FEEDER
1012-008
93
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301544595 FRAME 1 804PD-110-001 210B4142
2 6301335346 ASSY,COVER 1
804PD-110-002 011A0013
3 6301308319 COVER(D) 1
804PD-110-003 211A9111
4 6301335230 PLATE 1
804PD-110-004 211DA221
6 6301289021 SENSOR,PHOTO 1
B01 804PD-110-006 23G10090
7 4110392604 SCR PAN 2X6 2
804PD-110-007 221E0483
8 4111412509 WASHER SPR 2 2
804PD-110-008 221H0276
9 4111413605 WASHER V 2X5X0.3 2
804PD-110-009 221H0307
10 4110335700 SCR FLT 2.5X6 4
804PD-110-010 221D0261
11 6300007664 BOLT,HEX-SCT 2
M4X18 804PD-110-011 221A0021
12 4111412905 WASHER SPR 4 2
804PD-110-012 221H0284
13 4111414008 WASHER V 4X9X0.8 2
804PD-110-013 221H0315
14 0804000C NAME PLATE,INDEX 1 804PD-110-014 0804000C
15 0804000B NAME PLATE,INDEX 1 804PD-110-015 0804000B
16 6301614670 MACHINE SCREW 1
M3X6 PAN+SW+W SUS
804PD-110-016 221D0195
17 6301335223 PLATE 1
804PD-110-017 211DA220
18 4110022600 SCR FLT 3X6 2
804PD-110-018 221D0216
19 6301366753 PLATE 1
804PD-110-019 211DA550
20 4111134708 SCR FLT 4X10 2
804PD-110-020 221D0219
21 6301578477 GUIDE 1
804PD-110-021 212A2468
DS-24320
PD-1
0909-003
94
10
10
3
1
7
8
9
6
4
16
18
2
17
.
12
.
11
13
20
19
See Fig.Q-1
Key No.2
See Fig.Q-1
Key No.445
See Fig.Q-1
Key No.47
15
14
21
継ぎ目検出ユニット
JOINT DETECTION UNIT
DS-44560 DS-44560
Fig. QD-1
44,56mm
幅テープフィーダ用
FOR 44,56mm TAPE FEEDER
