附录 11 外观图 附 18 附录 11 外观图 211 mm 329 mm 215 mm 75.5 mm 80 mm 32.5 mm 34 mm 23 mm 20.5 mm
附录
10
支架安装
附 17
附
录
1 拆下主机底面的支撑脚和侧面盖子的螺丝
（正面两侧 4 个）。
2 将垫片放入主机侧面两侧，然后用
M4 × 10 mm 螺丝固定支架安装件。
在支架上安装时，请使用市售的底座进行增
固。
M4 × 6 mm
M3 × 6 mm
M4 × 10 mm
垫片
支架安装件
附录
11
外观图
附 18
附录 11 外观图
211 mm
329 mm
215 mm
75.5 mm
80 mm
32.5 mm
34 mm
23 mm
20.5 mm
