Dual conveyor fixed side right
Page 41 / 44 22.11.2021
Pos. Item no. Description Part marking
689 00845017-01 HEXAGON SOCKET HEAD CAP
SCREW
690 00317730-01 PRESSURE SPRING 1,2*13*57,7 V2A SPARE PART
691 00300558-01 DP4- DISC SPARE PART
692 00317683-02 BEARING AXIS 2
693 00095319-01 SLOTTED COUNTERSUNK HEAD
SCREW
694 00317682-01 COUNTERHOLDER SPARE PART
695 24000053-01 BALL-BEARING WEAR PART
696 00331106-01 ADJUSTING SHIM
697 00309054-01 PARALLEL PIN
698 00200195-01 WASHER SPARE PART
699 00095304-01 COUNTERSUNK SCREW
DIN965-M3X6-4.8
700 00200334-01 NEEDLE SLEEVE WEAR PART
701 00098614-01 DEEP-GROVE BALL BEARING 4*13*5
624-2Z
Wear Part
702 00317684-01 BEARING AXIS SPARE PART
703 00301555-01 DIN 988-4X8X0.1-ST 2 K 50 STANDARD PARTS
705 00317680-03 ROCKING LEVER RIGHT Spare Part
708 00302493-01 HEXAGON SOCKET HEAD CAP
SCREW
709 00317676-03 SIDE PART:F,LONG Spare Part
710 00325888-01 GUIDE COLUMN F. DUAL-CONVEYOR
711 00046020-01 DU BUSH
712 00303193-01 DIN912-M3 X 8-A2-70
713 00200320-01 DU-STRIP
714 00303193-01 DIN912-M3 X 8-A2-70
715 00303193-01 DIN912-M3 X 8-A2-70
716 00303193-01 DIN912-M3 X 8-A2-70
717 00200321-01 DU-STRIP
718 00303193-01 DIN912-M3 X 8-A2-70
719 00303193-01 DIN912-M3 X 8-A2-70
720 00845015-01 HEXAGON SOCKET HEAD CAP
SCREW M3 X 10-8.8
721 00324405S02 MOTOR WITH SYNCHRONIZING
GEAR
SPARE PART
Dual conveyor fixed side right
Page 42 / 44 22.11.2021
Pos. Item no. Description Part marking
722 00326052-01 CABLE MOTOR INPUT BELT 2
724 00201462-01 DIN912-M3 X 10-A2-70
725 00303193-01 DIN912-M3 X 8-A2-70
726 00303193-01 DIN912-M3 X 8-A2-70
727 00303193-01 DIN912-M3 X 8-A2-70
728 00303193-01 DIN912-M3 X 8-A2-70
729 00200322-01 DU-STRIPES SPARE
730 00317681-03 ROCKING LEVER LEFT SPARE PART
731 00326144-02 REINFORCING RAIL,RIGHT SIDE
FIXED
SPARE PART
732 00845027-01 HEXAGON SOCKET HEAD CAP
SCREW M4 X 16-8.8
733 00303193-01 DIN912-M3 X 8-A2-70
734 00303193-01 DIN912-M3 X 8-A2-70
735 00200319-01 DU-STRIP
736 00324405S02 MOTOR WITH SYNCHRONIZING
GEAR
SPARE PART
737 00326053-02 CABLE MOTOR CENTER BELT 2
739 00325510-02 SIDE PART: B,LONG
740 00200196-02 TOOTH BELT WEAR PART
741 00095304-01 COUNTERSUNK SCREW
DIN965-M3X6-4.8
742 00200195-01 WASHER SPARE PART
743 00200194-01 SYNCHRONIZING DISK AL13T5/13-0 SPARE PART
744 00200334-01 NEEDLE SLEEVE WEAR PART
745 00300558-01 DP4- DISC SPARE PART
746 00303193-01 DIN912-M3 X 8-A2-70
747 00200185-02 FLANGE SPARE PART
748 00200198-01 DU-WASHER SPARE PART
749 00095488-01 RETAINING RING
750 00200337-01 BALL BEARING 12*21*5 61801-2Z WEAR PART
751 00200193-02 SYNCHRONIZING GEAR SPARE PART
752 00200183-01 WASHER SPARE PART
754 00098617S01 BALL BEARING Wear Part
755 00200191-02 SYNCHRONIZING GEAR SPARE PART
758 00200192S02 SYNCHRONIZING GEAR SPARE PART
Dual conveyor fixed side right
Page 43 / 44 22.11.2021
Pos. Item no. Description Part marking
759 00303193-01 DIN912-M3 X 8-A2-70
760 00200181-01 BOLT SPARE PART
761 00095485-01 RETAINING RING
762 00200338-01 BALL BEARING 9 * 26 * 8 629-2Z WEAR PART
763 00327902-01 DU STRIP 1MM THICKNESS
764 00095304-01 COUNTERSUNK SCREW
DIN965-M3X6-4.8
765 00317679-04 RETAINER - LEFT SIDE B SPARE PART
766 00325773-02 DRIVE SHAFT Spare Part
767 00317678-04 HOLDING-DOWN DEVICE RIGHT SPARE PART
768 00200305-01 BLOCK SPARE
769 00095304-01 COUNTERSUNK SCREW
DIN965-M3X6-4.8
770 00200342-01 COMPRESSION SPRING VD-125 SPARE PART
771 00200347-01 PARALLEL PIN
772 00326041-01 SONAR PROXIMITY SWITCH INPUT
BELT 2 3RGX
Spare Part
775 00327615-02 CONTROL UNIT SPARE PART
776 00325579S03 DOUBLE PULSE MOTOR PC-BOARD SPARE PART
777 00325580-01 BACKPLANE FOR DUAL STEPPER
MOTOR BOARD
778 00325460-01 HALF BRIDGE RECTIFIER PC-BOARD Spare Part
779 00326061-01 CABLE STEPPING M. LIFTING TABLE
1 - CON
780 00326062-01 CABLE STEPPING M. LIFTING TABLE
2 - CON
781 00326063-01 CABLE POWER SUPPLY - STEPPING
MOTOR CON
782 00326064-01 CABLE SIGNALS LIFTING T. 1 -
CONV. BOARD
783 00326065-01 CABLE SIGNALS LIFTING T. 2 -
CONV. BOARD
784 00331297-01 CABLE: I/O CONVEYOR BELTS
30-POLE
785 00326067-01 CABLE POWER SUPPLY - HALF
BRIDGE
786 00325948-01 HOUSING F. DUAL-CONVEYOR
CONTROLLER
787 00318131-02 FAN FOR BOARD-HANDLING Spare Part
