Installation Manual for Windows XP (unattended setup) 11/2007 US+DE
Installationsanleitung für Windows XP (unattended setup)
10 / 58
4.2 Required configuration parameters
For the installation procedure, please note the following information:
• 1
User Name
• 2
Company Name
• 3
IP address of the station computer (Default: 172.22.100.100)
• 4
IP address of the programming system (Default: 172.22.100.102)
• 5
IP address of the default gateways (Optional, if no Remote Support was installedÆ no entry.
Default: no entry)
• 6
Subnet mask of the local IP network
Installation Manual for Windows XP (unattended setup) 11/2007 US+DE
Installationsanleitung für Windows XP (unattended setup)
11 / 58
5 Hotfixes
The hotfixes for Windows XP Service Pack 2 have been removed from the installation CD-ROM.
Apply hotfixes from the latest delivered Windows XP SP 2 Hotfix-CD.
Installation Manual for Windows XP (unattended setup) 11/2007 US+DE
Installationsanleitung für Windows XP (unattended setup)
6 Installation
Note:
In the general part of the setup, you have to answer with “Yes” or “No”. In the second part you
can switch between the wizard dialogs with “Next” or “Back” buttons.
With the “Cancel” button you can abort the whole installation procedure.
6.1 Hardware specific requirements and restrictions
6.1.1 SCENIC C 610
If you connect your keyboard via USB interface, you have to ensure the “legacy USB” option in the System BIOS to
be enabled. To do this:
→ Press the F2 key at boot time.
→ Navigate to the “Advanced” menu.
The following settings are displayed:
Advanced
Peripheral Configuration
------------------------------------------------
Serial 1: [Enabled]
Serial 1 Address: [3F8h, IRQ 4]
Serial 2: [Enabled]
Serial 1 Address: [2F8h, IRQ 3]
Parallel: [Enabled]
Parallel Mode: [Printer]
Parallel Address: [378h, IRQ 7]
USB Host Controller: [Enabled]
USB 2.0 Host Controller: [Enabled]
USB Legacy Support: [Disabled]
Serial ATA Configuration
Diskette Controller: [Enabled]
Mouse Controller: [Enabled]
LAN Controller: [Enabled]
LAN Remote Boot: [Disabled]
Audio Controller: [Disabled]
Item Specific Help
-----------------------------------
F1 Info
12 / 58
→ To activate the option “USB Legacy Support”, navigate to it and press the space bar.
