Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE MODEL TPM-1 10F/R-C 0509-002 55 1 630 091 2470 MOTOR,STEPPING 1 MPM031, B2086-D01ASM 748FB-310-001 2 630 088 3558 COUPLING 1 SFC-020WD 5B-8B 748FB-310-002 3 630 005 1353 B…
MODEL TPM-110F/R-C
0211-001
54
61
7
68
72
73
78
77
74
74
77
78
11
A
10
9
77
78
26
63
64
65
67
72
73
24
71
2
68
4
27
62
16
1
73
3
68
17
5
69
18
73
72
67
20
6
61
66
19
76
77
78
See Fig.FA-1
Key No.22
15
72
68
75
79
22
75
70
A
72
73
13
12
14
25
27
スクリーン認識部
SCREEN RECOGNITION SECTION
Fig. FB-1
スクリーン認識
X
部
Screen Recognition X Section
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
MODEL TPM-110F/R-C
0509-002
55
1 630 091 2470 MOTOR,STEPPING 1 MPM031, B2086-D01ASM
748FB-310-001
2 630 088 3558 COUPLING 1 SFC-020WD 5B-8B 748FB-310-002
3 630 005 1353 BEARING,UNIT 1 WBK10-11 748FB-310-003
4 630 088 2964 GUIDE,LINEAR 1 748FB-310-004
5 630 088 5125 BALL SCREW 1 748FB-310-005
6 630 088 3602 SENSOR,PHOTO 1 BPH314, PM-F54 748FB-310-006
7 630 088 3640 SENSOR,PHOTO 1 BPH311, PM-Y54 748FB-310-007
9 630 088 3701 MECH PARTS 1 748FB-310-009
10 630 088 3688 MECH PARTS 1 748FB-310-010
11 630 088 3695 MECH PARTS 1 748FB-310-011
12 630 118 4821 UNIT,CAMERA 1 B003, #KP-MC2AN-S2
748FB-310-012
13 630 089 2673 SCOPE UNIT 1 #LA-001-16-32-L39 748FB-310-013
14 630 114 6546 LIGHTING UNIT 1 E06E, #8S162 748FB-310-014
15 630 088 0359 BRACKET 1 748FB-310-015
16 630 091 0100 PLATE 1 748FB-310-016
17 630 088 0458 BLOCK 1 748FB-310-017
18 630 088 0410 BLOCK 1 748FB-310-018
19 630 088 0427 PLATE 1 748FB-310-019
20 630 088 0434 BRACKET 1 748FB-310-020
22 630 088 0472 BLOCK 1 748FB-310-022
24 630 102 5407 BRACKET 1 748FB-310-024
25 630 102 5391 STAY 1 748FB-310-025
26 630 115 0918 STAY 1 748FB-310-026
27 630 088 3886 PIN,LOCATE 2 748FB-310-027
61 411 041 7208 SCR PAN 3X5 4 748FB-310-061
62 411 034 7208 SCR FLT 3X8 4 748FB-310-062
63 630 000 7565 BOLT,HEX-SCT 4 748FB-310-063
64 411 141 2806 WASHER SPR 3 4 748FB-310-064
65 411 141 3902 WASHER V 3X7X0.5 4 748FB-310-065
66 630 000 8920 SET SCREW 2 748FB-310-066
67 630 000 7619 BOLT,HEX-SCT 4 748FB-310-067
68 630 000 7626 BOLT,HEX-SCT 23 748FB-310-068
69 630 000 7640 BOLT,HEX-SCT 4 748FB-310-069
70 630 000 7657 BOLT,HEX-SCT 4 748FB-310-070
71 630 000 7718 BOLT,HEX-SCT 4 748FB-310-071
72 411 141 2905 WASHER SPR 4 16 748FB-310-072
73 411 141 4008 WASHER V 4X9X0.8 16 748FB-310-073
74 630 000 7749 BOLT,HEX-SCT 4 748FB-310-074
75 630 000 7763 BOLT,HEX-SCT 6 748FB-310-075
76 630 000 7787 BOLT,HEX-SCT 2 748FB-310-076
77 411 141 6705 WASHER SPR 5 8 748FB-310-077
78 411 141 4107 WASHER V 5X10X1 8 748FB-310-078
79 630 000 7893 BOLT,HEX-SCT 1 748FB-310-079
FB-1
MODEL TPM-110F/R-C
0509-002
56
82
35
82
13
15
33
A
68
31
78
80
79
37
73
76
25
72
23
1
B
11
4
5
79
80
76
73
74
75
67
70
69
70
69
36
79
80
78
64
3
12
85
11
2
85
12
65
B
12
85
80
78
79
34
A
32
81
24
90
85
30
10
66
14
84
20
19
89
88
74
75
71
21
69
70
61
26
70
66
69
8
87
9
87
7
88
89
83
79
6
38
28
29
6
69
70
62
27
6
79
92
93
91
39
C
C
基板認識部
P.E.C. RECOGNITION SECTION
Fig. G-1
基板認識
X
軸
P.E.C. Recognition X Axis
