EJM9BE-AL-00W-00_N7205A058E03 - 第263页
I/O MAP NPM Bi t Contents ID CHECK Name Address 入力/IN 1 基板検出 PCB Detect B1130 1 基板検出 PCB Detect B1131 1 基板検出 PCB Detect B1132 1 基板検出 PCB Detect B1133 1 基板検出 PCB Detect B1134 1 基板検出 PCB Detect B1135 1 基板検出 PCB Detect B113…
I/O MAP NPM
Bi
t
Contents ID CHECKNameAddress
入力/IN 1異常
Trouble
1異常
Trouble
* 状態ﾋﾞｯﾄ
Status
* 状態ﾋﾞｯﾄ
Status
0異常
Trouble
0開
Open
0開
Open
入力/IN 1 接続
Connected
1 接続
Connected
1 基板検出
PCB Detect B1112
1 基板検出
PCB Detect B1113
1 基板検出
PCB Detect B1114
1 基板検出
PCB Detect B1115
1 基板検出
PCB Detect B1116
1 基板検出
PCB Detect B1117
入力/IN 1 基板検出
PCB Detect B1120
1 基板検出
PCB Detect B1121
1 基板検出
PCB Detect B1122
1 基板検出
PCB Detect B1123
1 基板検出
PCB Detect B1124
1 基板検出
PCB Detect B1125
1 基板検出
PCB Detect B1126
1 基板検出
PCB Detect B1127
No. 内 容 個数 日付 設計 検印 図名 ﾊﾟﾅｿﾆｯｸﾌｧｸﾄﾘｰ ﾍﾟｰｼﾞ
改 I/O MAP ｿﾘｭｰｼｮﾝｽﾞ(株）
訂機種
5
12
KZIL110-16B
7
F 左待機 基板検出ｾﾝｻ2
F left standby Board stop sensor2
8
F 左待機 基板検出ｾﾝｻ1
F left standby Board stop sensor1
5
基板検出ｾﾝｻｰ4(実装位置#2)
Board stop sensor 4(The mounting position #2)
6
基板検出ｾﾝｻｰ3(実装位置#2)
Board stop sensor 3(The mounting position #2)
3
基板検出ｾﾝｻｰ4(実装位置#1)
Board stop sensor 4(The mounting position #1)
4
基板検出ｾﾝｻｰ3(実装位置#1)
Board stop sensor 3(The mounting position #1)
#1_0042 F right standby Board stop sensor2
2
F 右待機 基板検出ｾﾝｻ1
1
F 右待機 基板検出ｾﾝｻ2
F right standby Board stop sensor1
7
R 基板検出ｾﾝｻ(右延長ｺﾝﾍﾞｱ)
R Board stop sensor (Right Ext conveyor)
8
基板検出ｾﾝｻ5(実装位置#2)
Board stop sensor 5(The mounting position #2)
5
F 基板検出ｾﾝｻ(右延長ｺﾝﾍﾞｱ)
F Board stop sensor (Right Ext conveyor)
6
基板検出ｾﾝｻ5(実装位置#1)
Board stop sensor 5(The mounting position #1)
3
基板検出ｾﾝｻｰ2(実装位置#1)
Board stop sensor 2(The mounting position #1)
4
基板検出ｾﾝｻｰ2(実装位置#2)
Board stop sensor2 (The mounting position #2)
#1_0041 F Tray&Cart connected confirmation
2
R ﾄﾚｲor台車 接続確認
1
F ﾄﾚｲor台車 接続確認
R Tray&Cart connected confirmation
7
R ﾌｨｰﾀﾞｰｶﾊﾞｰ
R Feeder cover detect
8
搬送予備入力
Spare Output
5
架台下FANｱﾗｰﾑ
The base under Fan Alarm
6
F ﾌｨｰﾀﾞｰｶﾊﾞｰ
F Feeder cover detect
3
D後工程同期確認信号
Synchronous D post-processing confirmation signal
4
D中間待機確認信号
D middle standby confirmation signal
#1_0040 Vacuum Pump Thermal Trip1
2
真空ﾎﾟﾝﾌﾟ温度異常2
1
真空ﾎﾟﾝﾌﾟ温度異常#1
Vacuum Pump Thermal Trip2
I/O MAP NPM
Bi
t
Contents ID CHECKNameAddress
入力/IN 1 基板検出
PCB Detect B1130
1 基板検出
PCB Detect B1131
1 基板検出
PCB Detect B1132
1 基板検出
PCB Detect B1133
1 基板検出
PCB Detect B1134
1 基板検出
PCB Detect B1135
1 基板検出
PCB Detect B1136
1 基板検出
PCB Detect B1137
入力/IN 0 ILK
ILK B1140
0 ILK
ILK B1141
* 状態ﾋﾞｯﾄ
Status B1142
* 状態ﾋﾞｯﾄ
Status B1143
* 状態ﾋﾞｯﾄ
Status B1144
* 状態ﾋﾞｯﾄ
Status B1145
* 状態ﾋﾞｯﾄ
Status B1146
* 状態ﾋﾞｯﾄ
Status B1147
No. 内 容 個数 日付 設計 検印 図名 ﾊﾟﾅｿﾆｯｸﾌｧｸﾄﾘｰ ﾍﾟｰｼﾞ
改 I/O MAP ｿﾘｭｰｼｮﾝｽﾞ(株）
訂機種
6
12
KZIL110-16B
8
7
6
5
4
3
2
1
8
D前工程 搬送ｾﾝｻｰ状態検出
D Pre-processing transportation sensor state detection
7
S前工程同期確認信号
S synchronous pre-process confirmation signal
5
S後工程同期確認信号
Synchronous S post-processing confirmation signal
6
S後工程中間待機確認信号
S Pre-pro middle standby confirmation signal
3
D前工程同期確認信号
D synchronous pre-process confirmation signal
4
D後工程 搬送ｾﾝｻｰ状態検出
D post-process transportation sensor state detectio
#1_0044 PCB Support Change ILK (position1)
2
基板下受け交換ILK(実装位置#2)
1
基板下受け交換ILK(実装位置#1)
PCB Support Change ILK (position2)
7
基板検出ｾﾝｻｰ1(実装位置#2)
Board stop sensor 1(The mounting position #2)
8
R 基板検出ｾﾝｻ(左延長ｺﾝﾍﾞｱ)
R Board stop sensor (Left Ext conveyor)
5
基板検出ｾﾝｻｰ1(実装位置#1)
Board stop sensor 1(The mounting position #1)
6
F 基板検出ｾﾝｻ(左延長ｺﾝﾍﾞｱ)
F Board stop sensor (Left Ext conveyor)
3
R 左待機 基板検出ｾﾝｻ2
R left standby Board stop sensor2
4
R 左待機 基板検出ｾﾝｻ1
R left standby Board stop sensor1
#1_0043 R right standby Board stop sensor2
2
R 右待機 基板検出ｾﾝｻ1
1
R 右待機 基板検出ｾﾝｻ2
R right standby Board stop sensor1
I/O MAP NPM
Bi
t
Contents ID CHECKNameAddress
出力/OUT 1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
1 teaching
teaching
出力/OUT 1起動
Start
1起動
Start
1起動
Start
1起動
Start
1起動
Start
1起動
Start
出力/OUT 1起動
Start
1起動
Start
1起動
Start
1起動
Start
* 状態ﾋﾞｯﾄ
Status
* 状態ﾋﾞｯﾄ
Status
* 状態ﾋﾞｯﾄ
Status
* 状態ﾋﾞｯﾄ
Status
No. 内 容 個数 日付 設計 検印 図名 ﾊﾟﾅｿﾆｯｸﾌｧｸﾄﾘｰ ﾍﾟｰｼﾞ
改 I/O MAP ｿﾘｭｰｼｮﾝｽﾞ(株）
訂機種
7
12
KZIL110-16B
7
後工程 隣接安全装置出力
Post Process adjacent safety device OUT
8
後工程 搬送ｾﾝｻｰ状態出力
Post Process transfer sensor OUT
5
前工程 隣接安全装置出力
Preceding Process adjacent safety device OUT
6
前工程 搬送ｾﾝｻｰ状態出力
Preceding Process transfer sensor OUT
3
F 左延長ｺﾝﾍﾞｱ起動
F Left Ex Conv
4
R 左延長ｺﾝﾍﾞｱ起動
R Left Ex Conv
#1_0062 F Right Ex Conv
2
R 右延長ｺﾝﾍﾞｱ起動
1
F 右延長ｺﾝﾍﾞｱ起動
R Right Ex Conv
7
R 左待機ｴﾘｱｺﾝﾍﾞｱ起動/Stop
R Left Standby Conv
8
ﾃﾞｭｱﾙConv予備出力
Dual Conv reserve output
5
R 右待機ｴﾘｱｺﾝﾍﾞｱ起動/Stop
R Right Standby Conv
6
R 実装ｴﾘｱｺﾝﾍﾞｱ起動/Stop
R Mount Conv
3
F 左待機ｴﾘｱｺﾝﾍﾞｱ起動/Stop
F Left Standby Conv
4
ﾃﾞｭｱﾙConv予備出力
Dual Conv reserve output
#1_0061 F Right Standby Conv
2
F 実装ｴﾘｱｺﾝﾍﾞｱ起動/Stop
1
F 右待機ｴﾘｱｺﾝﾍﾞｱ起動/Stop
F Mount Conv
7
ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ (右延長ｺﾝﾍﾞｱ)
Sensor remote teaching (Left Ext conveyor)
8
ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ (左延長ｺﾝﾍﾞｱ)
Sensor remote teaching (Left Ext conveyor)
5
R ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ(右待機､実装位置2)
R Sensor remote teaching ( Right Wait Mount posi 2)
6
R ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ (左待機)
R Sensor remote teaching (Left Wait)
3
F ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ (右待機､実装位置1)
F Sensor remote teaching( Right Wait Mount posi 1)
4
F ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ (左待機)
F Sensor remote teaching (Left Wait)
#1_0060 Sensor remote teaching ( Mount posi 1)
2
ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ(実装位置2)
1
ｾﾝｻ ﾘﾓｰﾄﾃｨｰﾁﾝｸﾞ(実装位置1)
Sensor remote teaching ( Mount posi 2)
