MODEL TCM-3100J 981 1-001 1 1-13 Key No. PART No. PART NAME Q'ty REMA RK S 1 630 062 0689 PLATE 1 659FB-03V-007 2 630 059 2207 STAY 4 659FB-03V-011 3 630 062 0696 PLATE 1 659FB-03V-008 4 411 141 4107 W ASHER V 5X10X…
MODEL TCM-3100J
9811-001
電気制御部 ELECTRICAL SECTION
Fig.11-13機械廻り 2 (ベース上面部） Miscellaneous Parts-2
6-2
98
92
97
96
91
93
94
95
109
104
103
102
101
105
109
109
106
108
107
1
71
72
73
21
23
22
24
25
121
122
123
124
3
6-1
109
See Fig.1-1
Key No.13
A
42
43
44
45
129
128
127
120
121
126
125
11
12
13
16
15
14
7
8
9
10
17
18
19
84
83
82
82
83
84
77
81
78
79
80
85
86
87
88
89
90
117
116
114
113
112
115
111
A
2
26
31
32
33
30
41
51
52
53
54-3
54-4
54-5
54-6
54-6
49
48
29
28
27
46 47
.
.
50
134
133
132
131
136
135
131
54-1
54-2
6-2
140
29-1
6
5
4
70
TCM-3000S-002
MODEL TCM-3100J
9811-001
11-13
Key No. PART No. PART NAME Q'ty REMARKS
1 630 062 0689 PLATE 1 659FB-03V-007
2 630 059 2207 STAY 4 659FB-03V-011
3 630 062 0696 PLATE 1 659FB-03V-008
4 411 141 4107 WASHER V 5X10X1 3 FW5
5 411 141 6705 WASHER SPR 5 3 SW5
6 630 000 7756 BOLT,HEX-SCT 3 M5X12
6 -1 411 140 7307 SCR FLT 5X12 3 M5X12 FLT
6 -2 411 036 8609 SCR PAN+SW+W 5X12 2
7 630 051 6555 UNIT,DRIVER 2 659FB-03D-018
8 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
9 411 008 1706 WASHER SPR 4 4 SW4 F
10 411 042 3001 SCR PAN 4X10 4 M4X10 PAN
11 630 075 0447 UNIT,DRIVER 2 659FB-03D-026
12 630 059 2214 PLATE 2 659FB-03V-012
13 411 035 2707 SCR FLT 4X8 4 M4X8 FLT
14 411 141 4008 WASHER V 4X9X0.8 2 FW4
15 411 141 2905 WASHER SPR 4 2 SW4
16 630 000 7619 BOLT,HEX-SCT 2 M4X8
17 411 119 2104 WASHER V 4X9X0.8 4 FW4 F
18 411 008 1706 WASHER SPR 4 4 SW4 F
19 411 043 5004 SCR PAN 4X8 4 M4X8 PAN
21 630 058 0181 ACCESSORY,P.C.B 8 659FB-03D-116
22 630 052 3010 P.C.B,MOUNT(MEKAHAI) 2 659FB-03U-001
23 411 119 1909 WASHER V 3X7X0.5 8 FW3 F
24 411 086 4408 WASHER SPR 3 8 SW3 F
25 411 054 6809 NUT HEX 3 8 M3 F
26 630 062 0702 BRACKET 1 659FB-03V-010
27 411 141 4008 WASHER V 4X9X0.8 3 FW4
28 411 141 2905 WASHER SPR 4 3 SW4
29 630 000 7633 BOLT,HEX-SCT 3 M4X12
29 -1 411 114 7807 SCR PAN+SW+W 4X10 1
30 630 058 1386 UNIT,I/O 1 659B--03H-006
31 411 141 4008 WASHER V 4X9X0.8 4 FW4
32 411 141 2905 WASHER SPR 4 4 SW4
33 630 000 7626 BOLT,HEX-SCT 4 M4X10
41 630 062 0719 BRACKET 1 659FB-03V-029
43 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
44 411 008 1706 WASHER SPR 4 2 SW4 F
45 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
46 630 052 3539 ACCESSORY,WIRING 1
47 630 052 3621 COUNTER 1 659FB-03D-091
48 630 049 2064 SOCKET 1 659FB-03D-094
49 630 052 4727 RELAY 1 659FB-03D-093
50 630 000 1051 BRACKET,WIRING 1
51 411 141 4107 WASHER V 5X10X1 2 FW5
52 411 141 6705 WASHER SPR 5 2 SW5
53 630 000 7756 BOLT,HEX-SCT 2 M5X12
70 411 036 8609 SCR PAN+SW+W 5X12 1
71 411 141 4107 WASHER V 5X10X1 4 FW5
72 411 141 6705 WASHER SPR 5 4 SW5
NOTE
MODEL TCM-3100J
9811-001
11-13
Key No. PART No. PART NAME Q'ty REMARKS
73 630 000 7749 BOLT,HEX-SCT 4 M5X10
77 630 057 9017 SUPPORT 1 659FB-03V-004
78 411 141 4107 WASHER V 5X10X1 2 FW5
79 411 141 6705 WASHER SPR 5 2 SW5
80 630 000 7756 BOLT,HEX-SCT 2 M5X12
81 630 057 9758 BRACKET 1 659FB-03V-013
82 411 141 4107 WASHER V 5X10X1 4 FW5
83 411 141 6705 WASHER SPR 5 4 SW5
84 630 000 7756 BOLT,HEX-SCT 4 M5X12
85 630 052 3010 P.C.B,MOUNT(MEKAHAI) 1 659FB-03U-001
86 411 119 1909 WASHER V 3X7X0.5 4 FW3 F
87 411 086 4408 WASHER SPR 3 4 SW3 F
88 411 162 1604 SCR PAN 3X20 4 M3X20 PAN
89 630 049 8448 COVER 1 659FB-03V-014
90 411 051 2804 SCR TRS 4X8 4 M4X8 TRS
91 630 051 2243 BRACKET 1 659FB-03V-015
92 630 064 0038 UNIT,DRIVER 1 659FB-03D-020
93 411 141 4008 WASHER V 4X9X0.8 4 FW4
94 411 141 2905 WASHER SPR 4 4 SW4
95 630 000 7619 BOLT,HEX-SCT 4 M4X8
96 411 141 4107 WASHER V 5X10X1 4 FW5
97 411 141 6705 WASHER SPR 5 4 SW5
98 630 000 7756 BOLT,HEX-SCT 4 M5X12
101 630 051 2199 BRACKET 1 659L--03B-033
102 411 141 4107 WASHER V 5X10X1 2 FW5
103 411 141 6705 WASHER SPR 5 2 SW5
104 630 000 7756 BOLT,HEX-SCT 2 M5X12
109 411 113 9109 SCR TRS 5X10 11 M5X10 TRS
111 630 060 5662 FILTER,NOISE 1 659FB-03D-135
112 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
113 411 008 1706 WASHER SPR 4 2 SW4 F
114 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
115 630 060 7420 ROD 4 659FB-03V-026
116 630 061 3902 COVER 1 659FB-03V-027
117 411 051 1708 SCR TRS 4X6 4 M4X6 TRS
120 630 058 8569 BRACKET 1 659FB-03V-016
121 630 051 5763 WIRE PARTS 2 659FB-03D-101
122 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
123 411 008 1706 WASHER SPR 4 2 SW4 F
124 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
126 411 036 8609 SCR PAN+SW+W 5X12 11
127 411 141 4107 WASHER V 5X10X1 2 FW5
128 411 141 6705 WASHER SPR 5 2 SW5
129 630 000 7756 BOLT,HEX-SCT 2 M5X12
131 630 051 5763 WIRE PARTS 2 659FB-03D-101
132 411 119 2104 WASHER V 4X9X0.8 2 FW4 F
133 411 008 1706 WASHER SPR 4 2 SW4 F
134 411 043 5004 SCR PAN 4X8 2 M4X8 PAN
136 411 036 8609 SCR PAN+SW+W 5X12 6
140 411 036 8609 SCR PAN+SW+W 5X12 1
NOTE
