MODEL TCM-3100J 981 1-001 3- 5 Key No. PART No. PART NAME Q'ty REMA RK S 3 630 001 0237 W ASHER 1 659KB-03H-110 4 630 048 4847 PIN,GUIDE 1 659KB-03B-019 5 630 049 3016 SPRING,COM P 1 659KB-03B-033 6 630 060 6706 ASS…
MODEL TCM-3100J
9811-001
ヘッド駆動部 HEAD DRIVING SECTION
Fig. 3-5 カム軸−1 レバー Cam Shaft-1 Lever
6-3
6-2
6-66-6
25
24
23
3131
77
2828
2929
3030
12
13
14
15
2222
2121
2020
1919
3636
3737
3838
26-4
6-3
26-3
26-3
26-2
26-6
5
4
3
1111
2727
10
9
8
32
35
4242
4141
4040
3939
34
33
See Fig.2-1
Key No.1
26-1
26-126-1
26
6-1
6
6-46-4
26-5
16
17
18
6-5
MODEL TCM-3100J
9811-001
3- 5
Key No. PART No. PART NAME Q'ty REMARKS
3 630 001 0237 WASHER 1 659KB-03H-110
4 630 048 4847 PIN,GUIDE 1 659KB-03B-019
5 630 049 3016 SPRING,COMP 1 659KB-03B-033
6 630 060 6706 ASSY,LEVER(CZ) 1
6 -1 630 056 8097 LEVER (CZ) 1 659KB-03B-001
6 -2 630 048 2195 COLLAR 1 659KB-03B-003
6 -3 630 001 1449 BEARING,RADIAL 2 659KB-03H-001
6 -4 630 048 2201 COLLAR 1 659KB-03B-004
6 -5 630 048 2188 PIN,GUIDE 1 659KB-03B-002
6 -6 630 048 7404 BEARING,PARTS 1 659KB-03H-004
7 630 048 9934 CAM FOLLOWER 1 659KB-03H-002
8 411 141 4800 WASHER V 12X24X2.5 1 FW12
9 411 141 3308 WASHER SPR 12 1 SW12
10 630 050 1056 NUT 1 659KB-03H-023
11 630 003 4271 GREASE NIPPLE 1 659KB-03H-022
12 630 007 2501 CAM FOLLOWER 1 659KB-03H-003
13 411 141 4503 WASHER V 8X17X1.6 1 FW8
14 411 141 3100 WASHER SPR 8 1 SW8
15 411 141 0901 NUT HEX 8 1 M8
16 411 141 4305 WASHER V 6X12.5X1.6 3 FW6
17 411 141 3001 WASHER SPR 6 3 SW6
18 630 000 7886 BOLT,HEX-SCT 3 M6X16
19 630 056 8868 BOX 1 659KB-03B-140
20 411 141 4008 WASHER V 4X9X0.8 2 FW4
21 411 141 2905 WASHER SPR 4 2 SW4
22 630 000 7626 BOLT,HEX-SCT 2 M4X10
23 630 001 0237 WASHER 1 659KB-03H-110
24 630 048 4847 PIN,GUIDE 1 659KB-03B-019
25 630 049 3030 SPRING,COMP 1 659KB-03B-035
26 630 060 6713 ASSY,LEVER(MZ) 1
26 -1 630 056 8103 LEVER (MZ) 1 659KB-03B-011
26 -2 630 048 2195 COLLAR 1 659KB-03B-003
26 -3 630 001 1449 BEARING,RADIAL 2 659KB-03H-001
26 -4 630 048 2201 COLLAR 1 659KB-03B-004
26 -5 630 048 2263 PIN,GUIDE 1 659KB-03B-012
26 -6 630 048 7404 BEARING,PARTS 1 659KB-03H-004
27 630 048 9934 CAM FOLLOWER 1 659KB-03H-002
28 411 141 4800 WASHER V 12X24X2.5 1 FW12
29 411 141 3308 WASHER SPR 12 1 SW12
30 630 050 1056 NUT 1 659KB-03H-023
31 630 003 4271 GREASE NIPPLE 1 659KB-03H-022
32 630 007 2501 CAM FOLLOWER 1 659KB-03H-003
33 411 141 4503 WASHER V 8X17X1.6 1 FW8
34 411 141 3100 WASHER SPR 8 1 SW8
35 411 141 0901 NUT HEX 8 1 M8
36 411 141 4305 WASHER V 6X12.5X1.6 3 FW6
37 411 141 3001 WASHER SPR 6 3 SW6
38 630 000 7886 BOLT,HEX-SCT 3 M6X16
39 630 056 8875 BOX 1 659KB-03B-141
40 411 141 4008 WASHER V 4X9X0.8 2 FW4
NOTE
MODEL TCM-3100J
9811-001
3- 5
Key No. PART No. PART NAME Q'ty REMARKS
41 411 141 2905 WASHER SPR 4 2 SW4
42 630 000 7626 BOLT,HEX-SCT 2 M4X10
NOTE
