MODEL TCM-3100J
9811-001
ヘッド駆動部 HEAD DRIVING SECTION
Fig. 3-16テープ送り部 1 Tape Feed-1
21
21-1
21-2
21-3
21
21-1
21-2
21-3
21
21-1
21-2
21-3
22
12
11
11-1
11-3
15
16
17
11-2
20
19
18
21
21-1
21-2
21-3
25-1
26
27
28
29
33
32
31
30
13
14
10
23
24
25-4
29
28
27
26
31
32
33
30
25-2
31
32
33
29
28
27
26
30
51-1
56
57
58
59
47
55
52
52
53
54
50
49
48
42
43
44
45
46
41
41-1
41-2
41-3
41
41-1
41-2
41-3
51
33
25-3
26
27
28
29
32
31
30
A
A
MODEL TCM-3100J
9811-001
3-16
Key No. PART No. PART NAME Q'ty REMARKS
630 060 6720 ASSY,BRACKET,LOCATE(PF) 1
10 630 056 9230 BRACKET,LOCATE 1 659KB-03B-126
11 630 048 7473 GUIDE,LINEAR 1 659KB-03H-101
11 -1 630 048 3215 COLLAR 1 659KB-03B-122
11 -2 630 048 3222 COLLAR 1 659KB-03B-123
11 -3 630 049 3047 SPRING,COMP 1 659KB-03B-134
12 411 140 8007 SCR TRS 5X6 1 M5X6 TRS
13 630 000 8937 SET SCREW 1 M4X12 SET
14 411 141 0307 NUT HEX 4 1 M4
15 630 049 0015 COLLAR 1 659KB-03B-133
16 630 000 8883 SET SCREW 2 M3X4 SET
17 630 048 3192 SHAFT 1 659KB-03B-120
18 411 141 4305 WASHER V 6X12.5X1.6 1 FW6
19 411 141 3001 WASHER SPR 6 1 SW6
20 411 141 0703 NUT HEX 6 1 M6
21 630 048 7480 GUIDE,LINEAR 4 659KB-03H-102
21 -1 630 048 3208 COLLAR 4 659KB-03B-121
21 -2 630 048 3222 COLLAR 4 659KB-03B-123
21 -3 630 049 3054 SPRING,COMP 4 659KB-03B-135
22 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
23 630 000 8937 SET SCREW 4 M4X12 SET
24 411 141 0307 NUT HEX 4 4 M4
25 -1 630 056 9513 BLOCK 1 659KB-03B-115
25 -2 630 056 9506 BLOCK 1 659KB-03B-114
25 -3 630 056 9520 BLOCK 1 659KB-03B-116
25 -4 630 056 9490 BLOCK 1 659KB-03B-113
26 630 007 2457 CAM FOLLOWER 4 659KB-03H-108
27 411 141 4305 WASHER V 6X12.5X1.6 4 FW6
28 411 141 3001 WASHER SPR 6 4 SW6
29 411 141 0703 NUT HEX 6 4 M6
30 411 000 7102 RING C 10 4 659KB-03H-107
31 411 141 4107 WASHER V 5X10X1 4 FW5
32 411 141 6705 WASHER SPR 5 4 SW5
33 630 000 7763 BOLT,HEX-SCT 4 M5X16
41 630 059 5604 GUIDE,LINEAR 2 659KB-03H-103
41 -1 630 048 3208 COLLAR 2 659KB-03B-121
41 -2 630 059 5635 COLLAR 2 659KB-03B-142
41 -3 630 059 5628 SPRING,COMP 2 659KB-03B-136
42 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
43 630 057 9741 PLATE,LOCATE 1 659KB-03B-117
44 630 001 0237 WASHER 2 659KB-03H-110
45 411 141 3001 WASHER SPR 6 2 SW6
46 630 000 7886 BOLT,HEX-SCT 2 M6X16
47 630 048 3239 PIN,GUIDE 1 659KB-03B-124
48 411 141 4107 WASHER V 5X10X1 1 FW5
49 411 141 6705 WASHER SPR 5 1 SW5
50 411 141 0505 NUT HEX 5 1 M5
51 630 048 7503 GUIDE,LINEAR 1 659KB-03H-104
51 -1 630 048 3208 COLLAR 1 659KB-03B-121
52 411 140 8007 SCR TRS 5X6 2 M5X6 TRS
NOTE
MODEL TCM-3100J
9811-001
3-16
Key No. PART No. PART NAME Q'ty REMARKS
53 630 000 8937 SET SCREW 1 M4X12 SET
54 411 141 0307 NUT HEX 4 1 M4
55 630 049 3078 SPRING,COMP 1 659KB-03B-137
56 630 059 5611 BLOCK 1 659KB-03B-112
57 411 141 4107 WASHER V 5X10X1 2 FW5
58 411 141 6705 WASHER SPR 5 2 SW5
59 630 000 7763 BOLT,HEX-SCT 2 M5X16
NOTE
