Boar d 4 Ass’y - 4 -
Board 3 Ass'y
NO. RART NO. RART NAME Q'TY TYPE REMARK
1
J1201030 CPU BOARD 1 MVME-162-220
2
J9060051A DSP BOARD 1 DSP BOARD REV 1.0
3
J9060052A ADDA BOARD 1 ADDA BOARD REV 1.0
4
J9060053A BASE BOARD 1 BASE BOARD REV 1.0
5
J9060058B AXIS(3) BOARD ASS'Y 1 REV 2.0
6
J9800388 VME AXIS(2) BOARD ASS'Y 3 C30-Z2-103-00-20/PS
7
J9801192 BOARD ASS'Y 1 LIGHT-CONTROL
8
J9800390 VME I/O DPRAM Ver.2 BOARD 1 C30-Z2-107-00-20/PS
9
J1200814 EPROM 1 TMS27C040-12
10
J1202055
RS232 MODULE
1 JP-OCTAL1232
11
J9801586 VME RACK 1 RACK-DEV-33L II
12
J1201601 PCB VME BACK PLANE 1 RBP-J112
13
J1201240
VME J2 BACK PLANE 3SLOT
1 KVME-3J2
14 J2100587 J2 DATA CABLE 1 CB-J2-DATA
15
16
17
18
19
20
21
22
23
24
25
26
27
-1-
Board 4 Ass’y
- 4 -
Board 4 Ass'y
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
J9070028A DRIVERS BRACKET 1 J9070028A
2
J4802004A GRAPHIC CARD 1 TRIDENT[9680-1]
3
J5001003A MODULE RAM 2 SIMM 72P 16MB NP
4
J4901002A CPU [PENTIUM 166MHZ WITH MMX] 1 PENTIUM 166MHZ WITH MMX
5
J4801008A MOTHER BOARD 1 SL-54U5
6
7
J9800397 POWER GOOD Ver.2 BOARD 1 C30-Z2-208-00-20/PS
8
J2100365 PC ISA BUS I/F BOARD ASS'Y 1 C30-Z2-107-00-20/PS
9
J7060030A RACK PART 1 PC BASE BRACKET
10
J5103002A CD-ROM DRIVER 1 48X SAMSUNG
11 J5101010A HARD DISK DRIVER 1 10.2GB
12
J5401004A
HARD RACK [RH-36]
1 RH-36
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
-1-
