KKD_KKJ_YS12P(F)_PL
P AR TS LIST Y S12P / 12F KKD/KKJ-0903(PL) Compact Economy Modular
Contents
1 Base Section
Base .....................................................................1-1
Sub Assy ..............................................................1-2
2 Cover Section
Top Cover .............................................................2-1
Acryl Door .............................................................2-2
Base/Conveyor/CE Cover ....................................2-3
3 Feeder Holder Section
Feeder Holder 60..................................................3-1
Feeder Holder 24..................................................3-2
Reel Holder ...........................................................3-3
Feeder Set Sensor ...............................................3-4
4 Moving-axis Section
X-axis 1 .................................................................4-1
X-axis 2. ................................................................4-2
X-axis-Sub Assy ...................................................4-3
Y-axis 1 .................................................................4-4
Y-axis 2 .................................................................4-5
5 Head Section
Head/Vision
(YS12P / Before Dec. 2009 for YS12F)
.....................5-1
Head/Vision
(After Jan. 2010 for YS12F)
...................................
5-2
Body Head Sub ....................................................5-3
Shaft Head Sub Assy. ...........................................5-4
Ejector ..................................................................5-5
Z-axis. ...................................................................5-6
ScanCamera .........................................................5-7
6 Nozzle Section
Nozzle ...................................................................6-1
Nozzle Changer 1
(YS12P / Before Dec. 2009 for YS12F)
.........6-2
Nozzle Changer 2
(YS12P / Before Dec. 2009 for YS12F)
.........6-3
Nozzle Changer 3
(After Jan. 2010 for YS12F)
....................6-4
Nozzle Changer 4
(After Jan. 2010 for YS12F)
....................6-5
7 Conveyor Unit Section
Push-Up ................................................................7-1
Stopper (Exit/Sub/Main) .......................................7-2
Clamp Board .........................................................7-3
Main Conveyor 1 ..................................................7-4
Main Conveyor 2 ..................................................7-5
Sensor ..................................................................7-6
8 Camera Section
Multi Camera & Light Assy
(YS12)
...........................8-1
Multi Camera & Light Assy
(YS12F)
.........................8-2
9 Blow Station Section
Blow Station 1
(YS12P / Before Dec. 2009 for YS12F)
...............9-1
Blow Station 2
(After Jan. 2010 for YS12F)
..........................9-2
Contents
10 Tape Cutter Section
Main Cutter Assy 720 (Before 2010 / May) ........10-1
Main Cutter Assy 720 (After 2010 / Jun) ............10-2
Cutter Valve/Slope/Safty Cover Assy (Before 2010 / May)
...10-3
Cutter Valve/Slope/Safty Cover Assy (After 2010 / Jun)
......10-4
Main Cutter Assy 288 (Before 2011 / Dec) .........10-5
Main Cutter Assy 288 (After 2011 / Dec) ............10-6
Cutter Valve/Slope/Safty Cover Assy (Befor 2011 / Dec)
.....10-7
Cutter Valve/Slope/Safty Cover Assy (After 2011 / Dec)
......10-8
Non Tape Cutter
(Old Type)
.....................................10-9
Non Tape Cutter
(New Type)
................................. 10-10
11 FDR Section
Set Up ST on MC ...............................................11-1
FDR Power ST ...................................................11-2
FDR Stand. .........................................................11-3
Dust Box. ............................................................11-4
12 Controller Section
Control Box .........................................................12-1
13 Exterior, etc Section
Exterior, etc 1 ......................................................13-1
Exterior, etc 2. .....................................................13-2
