KKD_KKJ_YS12P(F)_PL - 第10页
2 3 Feeder Holder (24) Feeder Holder KKD/KKJ-1203 32 42 30 42 39 22 24 51 51 23 23 54 48 37 17 46 57 3 17 54 48 56 50 37 31 24 7 4>3 56 59 29 42 28 28 44 39 44 27 26 44 6 5 49 38 41 46 18 49 37 20 51 20 19 53 9 NON T …
1
3
Feeder Holder (60)
Feeder Holder
KKD/KKJ-1203
10
9
9
10
8
8
23
34
40
5
43
31
4
29
37
1
38
38
40
30
12
15
48
48
47
31
2
35
45
47
6
6
7
44
13
13
20
7
11
15
32
32
39
47
48
44
16
36
41
28
33
46
48
47
31
3>2
35
45
28
17
18
21
33
46
22
43
38
52
51
37
19
49
39
29
29
50
14
14
38
24
26
27
25
42
37
19
42
49
39
42
OLD
19
Fig 2
Fig 1
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M3401-01 PLATE,FEEDER 60 1
2
KHY-M3405-S0 STAND, 1/2 SET 1 OK MG30148-2010/4/5
KHY-M3405-01 STAND 1 1 OK MF00034-2009/11/10
KHY-M3405-00 STAND 1 1
3
Delete OK MG30148-2010/4/5
KHY-M3406-01 STAND 2 1 OK MF00034-2009/11/10
KHY-M3406-00 STAND 2 1
4 KHY-M340C-01 PLATE,FRONT 2
5 KHY-M371R-00 RAIL GUIDE 12P 5
6 KHY-M340F-00 BRACKET,BOARD 2
7 KHY-M4476-16 FDR.CTRL.BOARD ASSY 2
8 KHY-M37E1-00 LIGHT GUIDE 4
9 KHY-M37E1-10 LIGHT GUIDE,L 2
10 KHY-M37E1-20 LIGHT GUIDE,R 2
11 KHY-M340G-00 SHAFT GUIDE 2
12 KHY-M340H-01 PLATE,INDICATOR 1
13 KHY-M349J-40 LABEL,INDICATOR 1 1-30
14 KHY-M379L-00 LABEL,LED 2
15 KHY-M379K-01 LABEL,LED POSI. 2
16 KHY-M340J-00 PLATE,CONNECTOR 1
17 KHY-M66TE-00 HNS,F.CTRL - FDR. 60
18 KHY-M372M-00 SCREW,STAD 120
19
KHY-M340K-03 BRACKET,MANIFOLD 1 NG MH60104-2011/8/22
KHY-M340K-02 BRACKET,MANIFOLD 1 Fig 2 NG MG30164-2010/4/7
KHY-M340K-01 BRACKET,MANIFOLD 1 Fig 1
20 KHY-M372R-00 GUIDE,FEEDER UNDER 5
21 KHY-M372P-00 SUPPORT,LEVER 60
22 KHY-M372S-01 SPRING,SUPPORT 60
23 KHY-M340N-01 COVER,BOARD 2
24
Delete MG30164-2010/4/7
KHY-M3411-00 MANIFOLD 1
25
Delete MG30164-2010/4/7
K40-M8598-00 PLUG 1 1
26
Delete MG30164-2010/4/7
$TSH8-01 JOINT 1
27
Delete MG30164-2010/4/7
$TSS4-01 JOINT 6
28 KHY-M34J1-00 BLOCK,FEEDER POSI. 2
29 KHY-M3430-10 LABEL,FEEDER 60-12P 1 1-60
30 99480-06020 PIN,PARALLEL 4
31 99480-06012 PIN,PARALLEL 4
32 99480-04012 PIN,PARALLEL 2
33 91312-08020 BOLT HEX.SOCKET HEAD 6 M8X20
34 91312-06020 BOLT HEX.SOCKET HEAD 4 M6X20
35 91312-06018 BOLT HEX.SOCKET HEAD 4 M6X18
36
91312-06012 BOLT HEX.SOCKET HEAD 4 M6X12 OK MG20132-2010/3/3
91312-06016 BOLT HEX.SOCKET HEAD 4 M6X16
37 91312-06012 BOLT HEX.SOCKET HEAD 18 M6X12
38 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
39 91312-03018 BOLT HEX.SOCKET HEAD 16 M3X18
40 91312-03016 BOLT HEX.SOCKET HEAD 12 M3X16
41 91312-03010 BOLT HEX.SOCKET HEAD 4 M3X10
42 91312-03006 BOLT HEX.SOCKET HEAD 12 M3X6
43 98702-03006 SCREW FLAT HEAD 90
44 98902-03006 SCREW BINDING HEAD 16
45 92902-06200 WASHER PLAIN 4
46 92902-08600 WASHER PLAIN 6
47 $NK-3N NYLON CLIP 4
48 90990-11J003 SCREW,PAN HEAD W/W 4
49 KHY-M6187-00 FAN MOTOR ASSY 4
50 90990-42J047 JOINT 2 MG30164-2010/4/7
51 $UBD6-4 JOINT 1 MG30164-2010/4/7
52 $USD8-6 JOINT 1 MG30164-2010/4/7
2
3
Feeder Holder (24)
Feeder Holder
KKD/KKJ-1203
32
42
30
42
39
22
24
51
51
23
23
54
48
37
17
46
57
3
17
54
48
56
50
37
31
24
7
4>3
56
59
29
42
28
28
44
39
44
27
26
44
6
5
49
38
41
46
18
49
37
20
51
20
19
53
9
NON Tape Cutter
40
21
9
8
56
50
56
59
10
35
1
38
OLD
47
45
13
14
15
16
30
63
58
63
36
9
60
61
62
43
36
Fig. 1
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KJH-M3401-01 PLATE, FEEDER 12-24 1 NG MF70166-2009/7/28
KJH-M3401-00 PLATE, FEEDER 12-24 1
2
3
KKJ-M3405-S1 STAND ,1/2 SET 1 OK MHX0080-2011/12/5
KKJ-M3405-S0 STAND ,1/2 SET 1 OK MG30148-2010/4/5
KKJ-M3405-01 STAND 1 1 NG MF70166-2009/7/28
KKJ-M3405-00 STAND 1 1
4
Delete MG30148-2010/4/5
KKJ-M3406-01 STAND 2 1 NG MF70166-2009/7/28
KKJ-M3406-00 STAND 2 1
5
KJH-M340F-02 BRACKET, BOARD 1 NG MF70166-2009/7/28
KJH-M340F-01 BRACKET,BOARD 1
6
KJH-M340H-02 PLATE,INDICATOR 1 NG MF70166-2009/7/28
KJH-M340H-01 PLATE,INDICATOR 1
7 KJH-M340J-00 PLATE, CONNECTOR 1
8
Delete MF10094-2009/2/2
KJH-M340K-01 BRACKET,MANIFOLD 1
9
KJH-M340K-02 BRACKET,MANIFOLD 1 NG MG30164-2010/4/7
KJH-M340K-10 BRACKET,MANIFOLD 1
10
KJH-M340N-02 COVER,BOARD 1 NG MF70166-2009/7/28
KJH-M340N-01 COVER,BOARD 1
11
12
13
Delete MG30164-2010/4/7
KJH-M3411-00 MANIFOLD 1
14
Delete MG30164-2010/4/7
K40-M8598-00 PLUG 1 1
15
Delete MG30164-2010/4/7
$TSH8-01 JOINT 1
16
Delete MG30164-2010/4/7
$TSS4-01 JOINT 3
17 KHY-M34J1-00 BLOCK, FEEDER POSI. 2
18 KHY-M371A-01 PLATE, FRONT 1
19 KHY-M371B-00 SHAFT GUIDE 1
20 KHY-M371R-00 RAIL GUIDE 12P 2
21 KHY-M372M-00 SCREW, STAD 48
22 KHY-M372P-00 SUPPORT, LEVER 24
23 KHY-M372R-00 GUIDE,FEEDER UNDER 2
24 KHY-M372S-01 SPRING, SUPPORT 24
25
26 KHY-M379K-01 LABEL,LED POSI. 1
27 KHY-M379L-00 LABEL,LED 1
28 KHY-M37E1-00 LIGHT GUIDE 3
29 KHY-M4476-06 FDR.CTRL.BOARD ASSY 1
30 KHY-M6187-00 FAN MOTOR ASSY 2
31 KHY-M66TE-00 HNS, F. CTRL - FDR. 24
32 KV8-M3758-00 SEAL DUMP 1
35 99480-04012 PIN, PARALLEL 1
36
KHY-M3T25-10 VALVE COVER 2 1 2 hole addition NG MH30095-2011/4/18
KJJ-M3T25-11 VALVE COVER 2 1 non 2 hole addition NG MF70173-2009/8/3
KJJ-M3T25-10 VALVE COVER 2 1 Fig 1
37 99480-06012 PIN, PARALLEL 3
38 99480-06020 PIN, PARALLEL 4
39 91312-03006 BOLT HEX. SOCKET HEAD 14
40
91312-03006 BOLT HEX. SOCKET HEAD 2 OK MG80103-2010/9/9
91312-03010 BOLT HEX. SOCKET HEAD 2
41 91312-03016 BOLT HEX. SOCKET HEAD 6
42 91312-03018 BOLT HEX. SOCKET HEAD 14
43 91312-04006 BOLT HEX. SOCKET HEAD 4
44 91312-04008 BOLT HEX. SOCKET HEAD 10
45 KHY-M349J-40 LABEL,INDICATER 1
46 91312-06012 BOLT HEX. SOCKET HEAD 9
47 KHY-M3430-00 LABEL,FEEDER 24-12P 1
48 91312-06018 BOLT HEX. SOCKET HEAD 4
49 91312-06020 BOLT HEX. SOCKET HEAD 12
50 91312-08030 BOLT HEX. SOCKET HEAD 4
51 98702-03006 SCREW, FLAT HEAD 36
52 98902-03004 SCREW, BINDING HEAD 12
53 98902-03006 SCREW, BINDING HEAD 6
54 92902-06200 WASHER, PLAIN 4
55 92902-04600 WASHER, PLAIN 4
56 92902-08600 WASHER, PLAIN 6
57 91312-06016 BOLT HEX.SOCKET HEAD 4
58 KJH-M340M-00 COVER,PLATE 1 1 MFY0118-2009/12/24
59 91312-08060 BOLT HEX. SOCKET HEAD 2
60 90990-42J047 JOINT 2 MG30164-2010/4/7
61 $UBD6-4 JOINT 1 MG30164-2010/4/7
62 $USD8-6 JOINT 1 MG30164-2010/4/7
63 90990-12J001 SCREW BIN.HEAD W/W 7
3
3
Reel Holder
Feeder Holder
KKD/KKJ-1203
7
8
8
8
8
4
20
23
22
1
3
2
20
23
22
19
19
9
10
20
23
19
19
19
32
27
32
24
22
20
23
10
12
11
12
17
18
12
12
14
13
13
16
21
21
15
32
27
28
31
30
29
26
25
32
28
31
33
30
6
6
5
24>35
22>34
4
5
24
22
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M3S00-00 REEL HOLDER 60 ASSY 1
2 KHY-M3R01-00 SIDE PLATE,R 1
3 KHY-M3R02-00 SIDE PLATE,L 1
4
KHY-M3S06-04 STOPPER PLATE 1 Hole position cheange NG MGY0030-2011/3/10
KHY-M3S06-03 STOPPER PLATE 1 NG MF00041-2009/10/14
KHY-M3S06-02 STOPPER PLATE 1
5
KHY-M3S0A-01 STAY,SHAFT 2 NG MF00041-2009/10/14
KHY-M3S0A-00 STAY,SHAFT 3
6 KHY-M3S07-01 TRIM 2
7 KHY-M3S08-00 UNDER COVER 1
8 KHY-M3S09-00 SHAFT,ROLLER 4
9 KHY-M3R10-02 REEL PUT 30
10
KHY-M3R14-01 COLLAR 2 φ30 NG MGY0030-2011/3/10
KHY-M3R14-00 COLLAR 2 φ21
11
KHY-M3R14-11 WASHER 32 φ21 NG MGY0030-2011/3/10
KHW-M1385-00 SPACER 32 φ18
12 KHY-M3R15-00 ROLLER 98
13 KHY-M3S15-00 ROLLER 2 2
14 KHY-M3R16-00 PARTITION 15
15 KHY-M3R22-00 GUIDE,PARTITION 7
16 KHY-M3S22-00 GUIDE 2,PARTITION 1
17 KHY-M3R23-00 COLLAR,PARTITION 29
18 KHY-M3S23-00 COLLAR 2,PARTITION 1
19 91312-06012 BOLT HEX.SOCKET HEAD 8
20 91312-04008 BOLT HEX.SOCKET HEAD 6
21
91312-03012 BOLT,HEX.SOCKET HEAD 16 OK MGX0083-2010/11/22
91312-03014 BOLT,HEX.SOCKET HEAD 16
22 91312-03005 BOLT HEX.SOCKET HEAD 12
23 92902-04200 WASHER PLAIN 6
24 92902-03200 WASHER PLAIN 8
25 KHY-M3S20-00 RH. FRAME ASSY 1
26 KHY-M3S20-S1 RH. FRAME SUB ASSY 1
27 KHY-M374C-00 CASTER 2
28 KM0-M3741-00 CASTER 63 2
29 KHY-M373C-10 CHAIN ASSY 1
30 90172-00J040 WASHER,EXTL.TOOTHED 17
31 91312-04008 BOLT HEX.SOCKET HEAD 17
32 91312-06008 BOLT HEX.SOCKET HEAD 16
33 92902-04200 WASHER PLAIN 16
34 91312-04008 BOLT HEX.SOCKET HEAD 4 MG10072-2010/1/19
35 92902-04600 WASHER PLAIN 4 MG10072-2010/1/19
